Seawolf The Best Imaging Night and Day October

Seawolf The Best Imaging Night and Day October 2011 The Best Imaging Night and Day

Seawolf Benefits § The best imaging night and day § Ideal color imaging for common lighting challenges § Dim, Mixed, Bright, Indoor § Black and white in very low light § Best all around performance § Highest total resolution § Horizontal x Vertical § Best compression § Global electronic shutter § Reduced motion artifacts

Common Lighting Challenges DIM DARK BRIGHT MIXED INDOOR CCD cameras struggle in challenging lighting

Common Lighting Challenges DARK DIM BRIGHT MIXED INDOOR Seawolf is the answer to challenging lighting

Lighting Challenges Everywhere GAS STATION WAREHOUSE INDUSTRIAL RETAIL BANKING CAMPUS

Seawolf The Answer to Dark Scenes The Best Imaging Night and Day

Dark Scenes Samsung SCB-3001 Seawolf Default Settings, WDR Mode Default Settings, WDR Normal Seawolf avoids hot spots and blooming in lowlight

Dark Scenes Samsung SCB-3001 Seawolf Default Settings, WDR Mode Default Settings, WDR Normal Seawolf captures accurate color in dark scenes

Dark Scenes Samsung SCB-3001 Seawolf Default Settings, WDR Mode Default Settings, WDR Normal Seawolf has less noise and accurate color in lowlight

Very Dark Scenes Samsung SCB-3001 Seawolf Default Settings, WDR Normal Seawolf wins in very dark black and white scenes

Very Dark Scenes Samsung SCB-3001 Seawolf Default Settings, WDR Mode Default Settings, WDR Normal Seawolf is the answer to dark scenes

Seawolf The Answer to Dim Lighting The Best Imaging Night and Day

Dim Lighting Samsung SCB-3001 Seawolf Default Settings, DSS On Default Settings, WDR Normal CCD slow shutter modes blur critical detail in dim light

Dim Lighting Samsung SCB-3001 Seawolf Default Settings, WDR Mode Default Settings, WDR Normal Seawolf captures true color in dim light

Dim Lighting Samsung SCB-3001 Seawolf Default Settings, WDR Mode Default Settings, WDR Normal Seawolf offers best anti-blooming in dim light conditions

Dim Lighting Samsung SCB-3001 Seawolf Default Settings, WDR Mode Default Settings, WDR Normal Seawolf captures accurate color in dim light

Dim Lighting Samsung SCB-3001 Seawolf Default Settings, WDR Mode Default Settings, WDR Normal Seawolf is the answer to dim lighting

Seawolf The Answer to Mixed Lighting The Best Imaging Night and Day

Mixed Lighting

Mixed Lighting Samsung SCB-3001 Seawolf Default Settings, WDR Mode Default Settings, WDR Normal Seawolf captures accurate detail and color in mixed lighting

Mixed Lighting Samsung SCB-3001 Seawolf Default Settings, WDR Mode Default Settings, WDR Normal Seawolf captures critical detail in mixed lighting

Mixed Lighting Samsung SCB-3001 Seawolf Default Settings, WDR Mode Default Settings, WDR Normal Seawolf’s WDR is the answer to backlit scenes

Mixed Lighting Samsung SCB-3001 Seawolf Default Settings, WDR Mode Default Settings, WDR Normal Seawolf captures critical detail

Mixed Lighting Samsung SCB-3001 Seawolf Default Settings, WDR Mode Default Settings, WDR Normal Seawolf is the answer to mixed lighting

Seawolf The Answer to Bright Lighting The Best Imaging Night and Day

Bright Lighting Samsung SCB-3001 Seawolf Default Settings, WDR Mode Default Settings, WDR Normal Seawolf produces better video in bright lighting

Bright Lighting CCD Camera Seawolf Default Settings, WDR Normal Seawolf outperforms the competition in backlit scenes

Bright Lighting CCD Camera Seawolf Default Settings, WDR Normal Seawolf eliminates glare in the brightest light

Bright Lighting CCD Camera Seawolf Default Settings, WDR Normal Seawolf is the answer to bright lighting

Seawolf The Answer to Indoor Lighting The Best Imaging Night and Day

Indoor Lighting Samsung SCB-3001 Seawolf Default Settings, WDR Normal Seawolf color and white balance beats the competition

Indoor Lighting CCD Camera Seawolf Default Settings, WDR Normal Seawolf eliminates glare in high-contrast indoor scenes

Indoor Lighting Samsung SCB-3001 Seawolf Default Settings, WDR Normal Seawolf is the answer to indoor lighting

Resolution The Best Imaging Night and Day

Highest Total Resolution = Horizontal x Vertical 300, 000 690 HTVL-E 650 HTVL-E 250, 000 630 HTVL-E 600 HTVL-E 540 HTVL-E 200, 000 150, 000 100, 000 50, 000 Seawolf 690 HTVL-E Sony 650 HTVL CCD Samsung A 1 SCC-B 2335 Techwin Winner 5 SDC-435 Panasonic SD 5 WV-CP 504 Bosch Dinion 2 X LTC 0490/21

Highest Total Resolution Interline CCD Interlaced Capture Seawolf Progressive Capture 540 HTVL Total 480 lines Resolution 540 HTVL 360 VTVL 480 VTVL Total Resolution Lost Resolution Seawolf preserves the maximum VTVL resulting in higher total resolution. CCD cameras throw away 25%!

Progressive vs. Interlace Capture Pixim Seawolf Full Resolution Image Progressive Image Capture Image Processing Progressive or Interlaced Output Full Resolution Image Full Resolution Maintained Interline Transfer CCD Full Resolution Image Interlaced Image Capture Image Processing Progressive or Interlaced Output Resolution Reduced by 25% Reduced Resolution Image

HTVL-E is Effective Resolution § HTVL-E can readily be used by end users § Easily displayed on LCD monitors § Easily recorded on standard DVRs § Accepted Industry Wide § Endorsed by industry analysts § Seawolf provides the highest usable resolution

Industry Support for HTVL-E “The HTVL Effective specification is a much more relevant and accurate indication of the actual, useable resolution of CCTV cameras. The standard is simple to measure on any CCTV camera using any type of image sensor, whether progressive scan or interlaced, thus Frost & Sullivan encourages its broad use within the video security industry. " Sandeep Maheshwari Vice President, Frost and Sullivan “We finally have a specification that takes into consideration total captured resolution, both horizontal and vertical. Prior to this new specification, the critical contribution of vertical TV lines to high resolution CCTV video has been ignored. However, video monitors and DVRs commonly used in millions of CCTV installations fully support enhanced VTVL. ” Michelle Abraham Principal Analyst, In-Stat

Seawolf Advantages The Best Imaging Night and Day

Compression Advantage Wasted Disk Space Pixim Seawolf Samsung W 5 ACTi video streamer - MB/hour

Costly Noise CCD Camera Seawolf Competition: 3, 484 MB Pixim: 1, 191 MB CCD video requires up to 3 x DVR space. Note: actual compression results will vary.

Global Shutter Advantage Skew is a common artifact of a rolling shutter. Seawolf’s global shutter solves this difficult problem.

Competitive Advantage HTVL-E Dark BW Dim Light Color Mixed Light Bright Light Indoor Light Compression Global Shutter Seawolf W 5 Effio-E HQ 1 690 Best Best Yes 600 Good Avg Poor Good No 650 Good Avg Poor Good Poor No 540 Poor Avg Poor No Seawolf delivers the Best Imaging Night and Day

Seawolf Benefits § The best imaging night and day § Ideal color imaging for common lighting challenges § Dim, Mixed, Bright, Indoor § Black and white in very low light § Best all around performance § Highest total resolution § Horizontal x Vertical § Best compression § Global electronic shutter § Reduced motion artifacts

Image Quality Tester The Best Imaging Night and Day

Image Quality Tester § Portable § Easy to carry, fits in airplane overhead bin § Durable § Solid plastic shock resistant case § Easy set-up § Install lights, apply power, align and focus cameras § Easy to compare all cameras § CCTV, IP, SD, Mpixel, etc. Size ~22 x 18 x 13. 5 Inches

IQ Tester Images Blooming Losing steps Color Bleeding Grainy Artifacts Sony HCB-J 5 FD (Effio Chipset) Seawolf Default Settings, WDR Normal Seawolf image quality is superior to CCD

IQ Tester Images Samsung A 1 Default Settings, WDR Mode Seawolf Default Settings, WDR Normal Samsung A 1 has major image artifacts including blooming, vertical smear, color bleed, highlight saturation, low WDR

Pixim Support § Sales and Technical Training § Sales Support § Demonstrations to End Users, Security Shows, Conferences Joe Peery Director, Financial Business Development (513) 310 -2300 Cell (513) 360 -2868 Ohio Office jpeery@pixim. com
