Sean Ferguson Product Manager ATLANTIS ATLANTIS update Gold

Sean Ferguson Product Manager ATLANTIS™

ATLANTIS™ update • Gold shaded titanium growth • Sim. Plant® 16 Featuring ATLANTIS™Abutment • Intraoral Scanning for ATLANTIS™ abutments with i. Tero • ATLANTIS™ Conus abutment • ATLANTIS™ ISUS

Materials – gold shaded titanium rising 18% 17. 4% 16% 15. 0% 15% 14% 12% GH 12% Zr 10% 8% 6% January February March April May June July August September October November December

ATLANTIS™ abutments Digital Open Solutions

Sim. Plant® 16 Featuring ATLANTIS™Abutment

Intraoral scanning for ATLANTIS™ Abutments • Increased connectivity for ATLANTIS Abutments by adding the intraoral scanning option • Starting with i. Tero Increased connectivity

Workflow

ATLANTIS™ IO FLO • Indications – For all positions in the mouth – Clinical invasive • Intended use – The ATLANTIS IO FLO (body and screw) should be used by clinicians during digital impression taking on implant level. – The ATLANTIS IO FLO should be used to transfer implant position(s) in the patient’s mouth to a digital model. FOR INTERNAL USE ONLY

Intraoral scanning for ATLANTIS™ Abutments • Target groups – Dental clinics with access to i. Tero intraoral scanner • Existing ATLANTIS Abutments customers • Potential ATLANTIS Abutments customers – Dental laboratories working together with Dental clinics with i. Tero access Increased connectivity

Intraoral scanning for ATLANTIS™ Abutments with i. Tero • Schedule ‒ Beta II start in NA Feb 2014 ‒ Announcement – Chicago Midwinter Meeting and AO Seattle ‒ April 2014 • NA Pre-launch ‒ Goal is to activate 10 clinical customers per month from Pre-Launch (April) until Global Launch - EAO 2014 ‒ Global Launch – EAO 2014

ATLANTIS™ Conus abutments

ATLANTIS Conus abutment – overdenture What is ATLANTIS™ Conus abutment? ATLANTIS™ Conus Abutment is a uniquely designed conical shaped abutment that incorporates a friction fit implant born prosthesis while being removable like an overdenture. This innovative conical telescopic coping technique allows optimal access for oral hygiene while providing the patient a cost effective treatment option.

ATLANTIS Conus abutment – overdenture Features ‒ Simplified restorative procedure ‒ No adaptation of stock components ‒ Freedom of implant connections, products and material

ATLANTIS Conus abutment – overdenture Benefits ‒ Time saving - increased profitability ‒ Reduce chair time ‒ For the major implant systems, a wide flexibility in therapy and design options ‒ Implant born prosthesis not tissue born

ATLANTIS™ Conus abutments for attachment-retained restorations New ATLANTIS solution ATLANTIS™ Conus Abutment -overdenture ATLANTIS™ Conus Abutment -custom For removable overdentures designed to fit ANKYLOS Syn. Cone caps For removable bridges/ overdentures with more individual design options

Standardized conus solution with ANKYLOS tapered cap for Syn. Cone • ATLANTIS Conus Abutment - overdenture core is designed to match ANKYLOS Syn. Cone 4º caps • Caps and polymerization sleeves will not be orderable via ATLANTIS Web. Order. Customer orders caps/sleeves from local DENTSPLY Implants Representative ‒ Syn. Cone 4º caps –Ref #31021889 ‒ Polymerization sleeve – Ref #31021890 • Refer to ”The Syn. Cone concept, ” ID 32670028 -USX • Scientific highlight available: ANKYLOS Syn. Cone – long term clinical follow-up, ID 79641 -USX

ATLANTIS Conus Abutment overdenture • Parallel, one-size abutments for removable prostheses (recommended for full arch overdenture restorations) • Milled to fit Syn. Cone 4°caps (ordered separately) Copings can also be produced manually by the customer • The position of the abutments will be in relation to the space needed for the final restoration and a diagnostic tooth set-up is always required • Abutments will be placed with margin levels as close to soft tissue level as possible

Design options Capture of ANKYLOS Syn. Cone Cap 1. Immediate restoration (intra oral) chair side - pick up of copings to an existing denture. 2. Indirect (laboratory process) with or without a framework. Fabricated by the laboratory in an existing or new denture. - Without framework - for temporary solutions

ANKYLOS® - Syn. Cone® Immediate, temporary restoration Attaching ANKYLOS® Syn. Cone® tapered caps with retention and polymerization sleve Preparing the prosthesis Inserting the prosthesis For more information, visit www. dentsply-friadent. com Polymerization phase Inserting the prosthesis

Attaching ANKYLOS Syn. Cone tapered caps with retention and polymerization sleeve Preparing the prosthesis And inserting the prosthesis

Polymerization phase Inserting the prosthesis

79682 -US-1309 ATLANTIS™ ISUS - Products and Services

- patient-specific CAD/CAM prosthetics for all major implant systems ATLANTIS™ abutments ATLANTIS™ ISUS

What is ATLANTIS™ ISUS ? ATLANTIS ISUS, a full range of implant suprastructures for fixed and removable dental implant prostheses. Available for all major implant systems, ATLANTIS ISUS bars, bridge and hybrid solutions are produced using the latest developments in CAD/CAM technologies, and supported by computer-based industrial and medical device expertise. ™ ™ *Terms and conditions apply

ATLANTIS™ ISUS Features – Available in titanium or cobalt-chrome – Precise, tension-free fit – Available for all major implant systems – Comprehensive 10 -year warranty* Titanium *Terms and conditions apply Cobalt-chrome

ATLANTIS™ ISUS Benefits – Wide flexibility in therapy and design for partially- and fully- edentulous patients – Implant- and/or abutment-level placement* – Fit tested by manufacturer using Sheffield fit test *Terms and conditions apply

Removable Restorations Restoration produced With Denture Materials (Acryllic and Denture Teeth) Fixed Restorations Restoration produced with Crown & Bridge Materials

Engineering: Load tests

Engineering: Load tests • “Static” and “dynamic” load testing is used to determine: – Optimal geometry of bar profiles – Maximum survivable length of extensions • Occlusal forces = bite + chewing (forces) – Max. bite force is 220 N/single tooth – Max. chewing force is 50 N/single tooth Jig that holds the bar in place

Customer order Order entry Shipping ATLANTIS™ ISUS Viewer Scanning Verification CAD design CAM manufacturing <DRAFT - INTERNAL USE ONLY> Workflow

ATLANTIS™ ISUS Options - implant/ abutment level Implant* level – with or without internal connection Combination of abutment and implant* level *Implant-level placement is not recommended on ASTRA TECH Implant System™ and contraindicated on ANKYLOS®. Available on abutment-level only in North America. Abutment level

ATLANTIS™ ISUS Prosthetic Screws • One prosthetic screw is included per implant site • Order up to one additional screw via ATLANTIS™ Web. Order • For full compatibility information, view the ATLANTIS™ ISUS systems compatibility chart – Implants and abutments
