SCANDINOVA IN UPPSALA SWEDEN DESIGN ASSEMBLY TESTING ASSEMBLY
SCANDINOVA IN UPPSALA, SWEDEN
DESIGN, ASSEMBLY & TESTING
ASSEMBLY AREA
TESTING AND PACKAGING
DELIVERY
SUMMARY • • • Established in 2001 Unique reliable solid state technology invented 1995 Uppsala based. Close to the University. 1500 m 2 production space. Focus on Klystron and Magnetron modulators Most customers in the scientific community. NEXT
ESTABLISHED APPLICATIONS MEDICAL • RADIOTHERAPY INDUSTRIAL • E-BEAM PROCESSING • CARGO INSPECTION • PEF PROCESSING • CALIBRATION DEFENSE • RADAR RESEARCH • SYNCHROTRON LIGHT SOURCE • FREE ELECTRON LASER • CRYSTALOGRAPHY
SOME ON-GOING PROJECTS • 6 x K 2 -system 262 -410 k. V / 270 -330 A to PSI • K 2 -system 450 k. V/330 A to CERN / CEA-Saclay • K 2 -system 420 k. V/320 A to Lawrence Livermore NL • 7 x K 2 -system 250 k. V/250 A to Canadian Light Source • 2 x K 2 -system 240 k. V/215 A to AES • K 2 -system 265 k. V / 265 A to DESY • K 2 -system 370 k. V / 380 A to INFN Frascati • 2 x K 1 -system 195 k. V/148 A to AES • K 1 -system 125 k. V/80 A to MIT • M 1 -system 45 k. V / 111 A to ADAM • M 1 -system 38 k. V / 90 A to Intra. Op • M 2 -system 65 k. V /110 A to Singapore • E 1 -system 90 k. V / 1 A to Helmholtz Zentrum
Basic schematic of the Scandinova modulator N = number of primary circuits R = Klystron Resistance NT= Transformer ratio (Has to be compensated for with N) C Transformer Klystron PS Switch C PS Switch
Droop ESS preliminary parameters Parameter Value P peak 6, 2 MW P mean 248 k. W t pulse 2, 0 ms T period 50 ms t rise 50 us t fall 50 us Klystron voltage 135 k. V Klystron current 46 A Pulse droop 3% Overshooot 2% N=42 C= 2000 u. F NT=130 Ecap=1, 4 k. J Etot= 60, 5 k. J Vdc= 1200 V
Tuning Transformer C Tuning PS Switch Rt = Tuning resistance Lt= Tuning inductance Klystron
Tuning on PSB When applying To ESS Rt = 1 ohm Lt = 0. 7 m. H
Safety aspects • Paralell operation – A switch failure will only dump one 42 th of the total stored energy. – Off the shelf capacitors will be used. – A failed module could be deconnected and the loss is 1/42 of the total power capacity • • All High voltage inside the tank Primary circuit <1400 V Pulse over current respond time 2 us. DC-Voltage discharge time within 10 sec
Front view
Rear view
Tehnology advantage • • Very small footprint Reliable operation Pulse width possible to change. Limited impact at failures Solid state technology. Low maintenance cost. Short installation time. High personal safety.
THANK YOU!
