Scale Model Tower Activity

Types of engineers Structural Engineer Civil Engineer Mechanical Engineer Electrical engineer Aeronautical engineer Chemical engineer Bio molecular engineer

Definition Structural engineer

Definition Structural Engineer

Definition Structural Engineering The engineering of structures that support or resist structural loads.

Definition Structural Engineer

Definition Infra (Interior) Structure

Definition EXO (Exterior) Structure

Definition Super (? ? ? ) Structure

Definition Super (ABOVE) Structure • Burj Khalifa • Dubai, United Arab Emirates • 2, 722 feet tall

location Dubai, United Arab emirates

Definition Sub ? ? ? (below) Structure

Forces u. Force - Anything that produces motion or stops an object in motion

Newton’s first law of motion u. An object at rest will remain at rest, uan object at motion will remain in motion uunless acted upon by another force.

Gravity u. The force which pulls objects together. This is anything with mass.

Tension u. A pulling force produced on an object when a pair of forces move in opposite directions

Compression A crushing force produced on an object when a pair of forces move toward each other

Shearing u. A cutting force produced when a pair of forces moving towards an object just miss each other.

Torsion (Torque) u. A twisting force on an object when a pair of forces rotate away from each other. u. Example: u Opening a soda bottle

Compression Shearing Tension Torsion

Identify the Force u. COMPRESSION

Identify the Force u. TORSION

Identify the Force u. TENSION

Identify the Force u. SHEARING

Building with Shapes u. COMPRESSION FAILURE Circle

Building with Shapes u. TENSION u. COMPRESSION Square

Building with Shapes u. SHEARING FAILURE Triangle

Building with Shapes u. TORSION I-Beam

Truss u. A triangular shape structure used by engineers because of its proven strength.

Truss STRONGEST STRUCTURE !!!!! Truss
