SAP HANA – Data Provisioning for Replication with SAP and Non-SAP Applications

Disclaimer This presentation outlines our general product direction and should not be relied on in making a purchase decision. This presentation is not subject to your license agreement or any other agreement with SAP has no obligation to pursue any course of business outlined in this presentation or to develop or release any functionality mentioned in this presentation. This presentation and SAP's strategy and possible future developments are subject to change and may be changed by SAP at any time for any reason without notice. This document is provided without a warranty of any kind, either express or implied, including but not limited to, the implied warranties of merchantability, fitness for a particular purpose, or non-infringement. SAP assumes no responsibility for errors or omissions in this document, except if such damages were caused by SAP intentionally or grossly negligent. © 2012 SAP AG. All rights reserved. 2

Content SAP HANA Data Provisioning - Positioning SAP HANA Data Provisioning - Options § SAP LT Replication Server (SLT) § SAP Data Services (DS) § SAP Direct Extractor Connection (DXC) SAP HANA Data Provisioning – What’s new in SAP HANA SPS 05? © 2012 SAP AG. All rights reserved. 3

SAP HANA SPS 04: Data Provisioning Positioning SAP LT Replication Server (SLT) is positioned for real-time data replication from SAP and non-SAP sources (SAP supported data bases only) -> Mainly recommended for real time data replication business scenario SAP Data Services (DS) is positioned for batch load-based data replication from non-SAP sources and SAP sources (with complex ETL requirements) -> Mainly recommended for batch type data replication business scenarios SAP HANA Direct Extractor Connection (DXC) DXC is available as a simple option in batch mode for data replication from existing SAP Data Source extractors (ERP) into SAP HANA. -> Mainly recommended for batch type data replication for stand alone HANA business scenarios Other Data Provisioning Options Sybase Event Stream Processor (ESP) * : will be available for replicating real time event streams from Sybase ESP (CEP) into SAP HANA * Planned to be available as part of SAP HANA SPS 05 and Sybase ESP 5. 1 -SP 1 © 2012 SAP AG. All rights reserved. 4

Data Provisioning with SAP HANA 1. 0 SAP Business. Objects tools SAP Business Suite SAP LT Replication Server Trigger Based, Real Time ETL, Batch SAP BW Log Based, Real Time Extractor Batch Trading & Order Event Streams Real Time Data Sources © 2012 SAP AG. All rights reserved. SQL BICS SQL MDX SAP In-Memory Computing Studio SAP Data Services Sybase Replication Server Non-SAP Data Sources Management Systems DB Connection Other query tools SAP HANA Direct Extractor Connection** Sybase Event Stream Processor * * Sybase ESP 5. 1 -SP 1, Q 4 -2012 ** SAP ERP & BW Extractors ODBC SAP In-Memory Database ECDA/ODBC Http/Https ODBC Calculation and Planning Engine Row & Column Storage In memory DSO Activation Queue XS Engine SAP HANA 5

SAP HANA Data Provisioning Options: 1. SAP LT Replication Server does not have to be a separate SAP system and can run on any SAP system with SAP Net. Weaver ABAP stack 7. 02 or higher with SAP Kernel 7. 20 (or higher) HANA Studio Application Table Trigger Based Delta Recording Replication Configuration RFC Connection Replication Engine DB Connection Application Table SAP source system SAP LT Replication Server Connection(s) between source system and SAP HANA system are defined as “Configuration” on the SAP LT Replication Server © 2012 SAP AG. All rights reserved. SAP HANA system Data load and replication are triggered via SAP HANA Studio 6

LT Replication Concept: Trigger-Based Approach Architecture and key building blocks Read module RFC Connection Structure mapping & Transformation Write module Application table Logging table DB Connection Application table DB trigger SAP source system Efficient initialization of data replication based on DB trigger and delta logging concept (as with near zero-downtime approach) © 2012 SAP AG. All rights reserved. SAP LT Replication Server Flexible and reliable replication process, incl. data migration (as used for TDMS and SAP LT) SAP HANA system Fast data replication via DB connection LT replication functionality is fully integrated with HANA Modeler UI 7

LT Replication Concept: Trigger-Based Approach Replication from non-SAP sources DB Connection Read module Structure mapping & Transformation Application table Logging table DB trigger Non SAP source system Write module DB Connection Application table SAP LT Replication Server SAP HANA system SAP LT replication server transfers in a first step all metadata table definitions from the non-SAP source system to the SAP HANA system into the tables DD 02 L and DD 02 T. Read module now has to reside on LT replication server as it requires an ABAP stack. NOTE: For non-SAP source systems, the customer database license needs to cover a permanent database connection with 3 rd party products like LT replication server. © 2012 SAP AG. All rights reserved. 8

SAP HANA Data Provisioning Options: 2. SAP Data Services 4. 1 High Performance Highly-scalable engine to move large volumes of data into HANA n Integrated with HANA’s bulk-load interfaces SAP Business Suite SAP HANA DB In-Memory Wide Connectivity n n Data and Metadata connectivity to all major enterprise data sources Native, fast connectivity to Applications, RDBMS, Files, Text Powerful Transformations SAP HANA Studio n SAP HANA Appliance SAP BW *1 SAP Data Services 4. 1 Structured/Text Data Sources n Built-in transformations for data quality (*) n Support for non-relational data formats including text and XML © 2012 SAP AG. All rights reserved. (*) = Requires additional licenses 9

NEW in SAP Data Services 4. 1* Data Services Workbench for data loading into SAP HANA New, Eclipse-based user interface design for Data Services A simple wizard to replicate data and metadata (table definitions) from 3 rd party databases into SAP HANA. In 3 easy simple steps, you can replicate large data sets from any source to your SAP HANA target: Set up connections to source and target system Select the required tables from the source (or simply select all tables) Generate and execute the job to move all data with one mouse click Once the wizard exits, more additional features can be added: Filters, complex data mappings (expressions and functions) Load options, delta loading strategy, etc. *SAP Data Services 4. 1 - RTC in June 2012 © 2012 SAP AG. All rights reserved. 10

SAP Data Services 4. 1 – Workbench Design Replication job HANA (8 selected tables) Step 1: Select source and target connections (database or SAP application). Step 2: Select tables for replication, target tables will be generated automatically. Step 3: Deploy your Data Services job and execute. © 2012 SAP AG. All rights reserved. 11

SAP Data Services 4. 1 – Workbench Monitor job run Built-in capabilities to monitor the data loading Compare historic load times See load progress in real-time © 2012 SAP AG. All rights reserved. 12

SAP HANA Data Provisioning Options: 3. SAP HANA Direct Extractor Connection (DXC) Leverage pre-existing foundational data models of SAP Business Suite entities for use in SAP HANA data mart scenarios § § Significantly reduces complexity of data modeling tasks in SAP HANA Speeds up timelines for SAP HANA implementation projects Provides Semantically Rich Data from SAP Business Suite to SAP HANA § § Ensures data appropriately represents the state of business documents from ERP Application logic to “make sense of the data” already built into many extractors Simplicity / Low TCO § § Re-uses existing proprietary Extraction, Transformation, and Load mechanism built into SAP Business Suite systems, over a simple http(s) connection to SAP HANA No additional server or application needed in system landscape Change Data Capture (delta handling) § § Efficient data acquisition – only bring new or changed data into SAP HANA DXC provides a mechanism to properly handle data from all delta processing types © 2012 SAP AG. All rights reserved. SAP HANA SAP ERP Embedded BW Info. Cubes In memory DSO Data Store Objects Info. Objects PSA Data. Source http Activation Active version Queue generic data transfer Data. Source (flat structure) Activation Processing Extractor Status ERP data 13

SAP HANA Direct Extractor Connection: Details - 1 SAP HANA Direct Extractor Connection (DXC) § Utilizes the Data Source extractors that exist in SAP Business Suite systems § Originally, those were developed for use with BW § DXC is for use in SAP HANA standalone scenarios (data mart); BW on SAP HANA is a separate topic. DXC utilizes the embedded BW § Starting with Net. Weaver 7. 0, (embedded) BW has been part of Net. Weaver ABAP § In typical SAP Business Suite systems, the embedded BW is not utilized § customers used to run separate BW systems § Most customers already have the Support Package level needed on source SAP Business Suite system, e. g. SAP NW 7. 0 Support Package Stack 19 – first available Nov 2008 § DXC uses the embedded BW system to enable extraction towards SAP HANA and monitoring § DXC mainly requires applying SAP note 1583403 Note: Modeling in the embedded BW is not part of the DXC solution. An architectural variation is available, which uses a “sidecar” BW instead of the embedded one. © 2012 SAP AG. All rights reserved. 14

SAP HANA Direct Extractor Connection: Details - 2 The extraction from the SAP Business Suite system is controlled by the Data Warehousing workbench inside the embedded BW § When data is extracted from, the SAP Business Suite system, it is not loaded into the PSA of the embedded BW it is redirected instead and sent to SAP HANA § it gets loaded into in-memory DSO’s activation queue - and then gets activated into the active table of the in-memory § However, in the data load monitor of the embedded BW, the data load into the activation queue in the DSO in SAP HANA appears like data is loading into the PSA of the embedded BW Delta processing (aka “change data capture”) § Works the same for DXC as it would if BW is the receiving system § If the Data. Source is delta enabled, then delta-data is available with SAP HANA Direct Extractor Connection, too DXC internally in HANA uses § The ICM (Internet Connectivity Manager) receives XML packages over the http(s) connection § A mechanism written on the XS Engine (special runtime component for SAP HANA) § receives data packages from ICM, converts format § inserts the records into the activation queue of the in-memory DSO § activation processing -> records go into the active table in proper sequence § Both the ICM and XS Engine components must be enabled in SAP HANA to utilize DXC © 2012 SAP AG. All rights reserved. 15

SAP HANA Data Provisioning: What’s new in SAP HANA SPS 05* Sybase ESP-5. 1 Integration with SAP HANA 1. 0 INPUT STREAMS Studio (Authoring) Sensor data Transactions ? SAP Sybase Event Stream Processor ESP-5. 1 Dashboard Application Message Bus Database Events ODBC** • High speed smart capture: SAP Sybase ESP can apply logic to transform, filter, aggregate, enrich incoming event streams and capture data in SAP HANA • SAP Sybase ESP can query SAP HANA database to provide context for processing incoming events SAP HANA 1. 0 SAP HANA Studio Database * SAP HANA SPS 05, RTC Q 4 2012 ** Sybase ESP 5. 1 SP 1 - ODBC Adapter, RTC Q 4 2012 Note: This is the current state of planning and it may be changed by SAP at any time © 2012 SAP AG. All rights reserved. 16

SAP HANA Data Provisioning: What’s new in SAP HANA SPS 05* with SAP LT Replication Server § § Technical readiness for replication of SAP Business Suite on SAP HANA SLT for SAP BW: ready for proof-of-concepts and prototyping projects Integrated use of SLT by ERP and other SAP HANA Application Accelerators Improved usability § Help Center with detailed context-related documentation § Advanced status tracking (when using Access Plan / Range Calculation) § Improved stability § Eliminate manual steps on SLT system after implementing a note or support package § Support related expert functions streamlined § New and improved performance options § Data load using ROW ID approach with reading type 4 § Optimized job management: free-up background jobs and resources for tables with low change rates * SAP HANA SPS 05, RTC Q 4 2012 Note: This is the current state of planning and it may be changed by SAP at any time © 2012 SAP AG. All rights reserved. 17
