Sales Guide for DGS-3620 Series L 3 Stackable Gigabit x. Stack Switch Feb 2011 D-Link HQ
Agenda Product Overview Target Market and Applications Technology Briefing Competitive Comparison & Analysis • Positioning Highlight • Key Comparison • Art of the War Appendix
Product Overview D-Link Gigabit Managed Switch Product Portfolio Next Generation DGS-3600 DGS-3620 L 3 Support VRRP, OSPF, IGMP, BGP, Q in Q, PIM, IPv 6 tunneling, MPLS 1 DGS-3420 DGS-3400 Support RIP, Y. 1731, 802. 1 ag, 802. 3 ah OAM, NLB, 10 G uplink DGS-3120 L 2 DGS-3100 Support Stacking, SIM, Static Route, ERPS, IMPB Note: 1. DGS-3620 will support MPLS in R 2 2. DGS-3420 FCS: Jun/2011
Product Overview Product Position DGS-3620 Series (Compared to DGS-3600) Feature • Egress ACL • Flexible for uplink or stacking (4 10 GE SFP+ ports) • External SD card support • Po. E+ Support (802. 3 at & 802. 3 af) • Smart Fan • SI/EI features 802. 3 af DGS-3620 EI EI Support IPv 6 Tunneling, BGP, RIPng(IPv 6), OSPFv 3, BGP+, PIM SM v 6, DVMRP v 3, CFM 802. 3 at DGS-3620 SI DGS-3600 P r i c e SI: Standard Image EI: Enhanced Image
Product Overview DGS-3620, the next generation D-Link x. Stack L 3 Gigabit Switch Model DGS-3620 -28 TC-DC DGS-3620 -28 SC-DC H/W Configuration 20 10/1000 Base-T ports + 4 Combo 10/1000 Base. T/SFP ports + 4 10 GE SFP+ ports 20 10/1000 Base. T ports + 4 Combo 10/1000 Base. T/SFP ports + 4 10 GE SFP+ ports 20 SFP ports + 4 Combo SFP/10/1000 Base -T ports + 4 10 GE SFP+ ports 20 SFP ports + 4 Combo SFP/10/1000 B ase-T ports + 4 10 GE SFP+ ports Power AC Power DC power Model DGS-3620 -28 PC DGS-3620 -52 T DGS-3620 -52 P H/W Configuration 20 10/1000 Po. E ports + 4 Combo 10/1000 Base-T Po. E/SFP ports + 4 10 GE SFP+ ports 48 10/100/1000 Base. T Po. E ports + 4 10 GE SFP+ ports Power AC Power
Product Overview Premium Offerings of DGS-3620 x. Stack Switches Investment Protection • Multiple functions (L 3 routing, high port density, security and Po. E) in a single device, eliminating the needs of purchasing multiple router and switches • Future-proofing IPv 6 features Ultra High Performance • Up to 4 10 G uplink ports allow maximum 40 G backbone bandwidth Maximized Network Uptime • Resilient switching & routing technologies (OSPF, VRRP, MSTP, ERPS, LACP. . ) • Physical stacking architecture avoids single point of failure • Redundant power supply design Application Awareness • Vo. IP-enabled network by Voice VLAN, which auto recognizes Vo. IP devices & prioritizes their traffic • • Po. E models available for easy deployment of Vo. IP networks Committed bandwidth for mission critical applications
Product Overview Premium Offerings of DGS-3620 x. Stack Switches Comprehensive Security • A variety of Endpoint Security features (authentication & attack mitigation, etc) • Not only as a core/aggregation switch, but allows for endpoint connections Ease of Management • DGS-3620’s Web GUI supports FULL SET of features, good for first timer • 12 DGS-3620 devices can be stacked as a single unit, easing the management effort • Virtually stacks with other D-Link switches, providing Single IP Management for small business • Works in concert with D-View network management software for larger deployment Green • Various green features that can minimize the power usage, saving the earth
Product Overview Product Briefing Advanced hardware design with excellent performance. Support 802. 3 af (Po. E) and 802. 3 at (Po. E Plus) for all ports 1 High uplink/stacking bandwidth 4 10 GE SFP+ ports provide up to 40 G bandwidth. It provides high flexibility for physical stacking or uplink application use. Enlarge MAC address table to 32 K (DGS-3600 series is 16 K) Smart Fan Power saving: Internal heat sensor monitors switch’s temperature and adjusts the fan speed accordingly. Improve the MTBF with slower fan speed and reduce the noise 2 External SD Card Easy to store and restore file with portable SD card (like FW, configuration file, boot image, syslog or other files). External Alarm Port 3 Provides digital I/O design on external alarm port. It can provide better security protection. With digital in, DGS-3620 can receive events detected by external sensors (eg. temperature, smoking or anti-theft sensor). The switch can send a trap/log out to report the issue. With digital out, DGS-3620 can activate external air-conditioner/fan or ring the bell based on the condition customer defined.
Product Overview Product Briefing Advanced L 3 Features Provides advanced L 3 features including IPv 4/v 6 routing, Packet routing and protocol filtering/inspection, which make the Switch act even as a Layer 4 switches Comprehensive IPv 6 support Provides comprehensive IPv 6 support including IPv 6 Tunnel, ICMPv 6, IPv 6 Neighbor Discovery (ND), DHCPv 6, RIPng and OSPFv 3 IPv 6 Ready Logo Phase I and Phase II High availability, security and reliability Rich AAA, access control features help administrators well-manage the visitors of the networks Various attack prevention features and redundancy protocols D-link Green Ethernet Technology First L 3 Gigabit Switch provides advanced Power Saving, Smart Fan, Time based Po. E
Agenda Product Overview Target Market and Applications Technology Briefing Competitive Comparison & Analysis • Positioning Highlight • Key Comparison • Art of the War Appendix
Target Market and Applications Core for SMB Enterprise Network DFL-2560 10 G DGS-3120 DGS-3620 1 G DGS-3120 1 G Copper 10 G SFP+ DGS-3120
Target Market and Applications Aggregation for Campus Network OSPF Campus Backbone Dormitory 1 … DGS-3120 … VRRP DGS-3120 DGS-3620 Series … Dormitory 2 DGS-6600 DGS-3120 VRRP College 3 DGS-3620 Series College 2 College 1 DGS-8000/ DES-7200 … … DGS-3620 DGS-6600 DGS-3120 1000 Copper 10 G Fiber DGS-3120
Target Market and Applications Enterprise Routers for Remote Sites in Large Enterprise Larger routing table provides the capability for a large-scale enterprise Border Gateway Protocol (BGP) allows central routing management of all remote sites regardless of physical connections DGS-3620 CPE RIP OSPF BGP VP VP N Branch N Internet CPE DGS-3620 VPN CPE BGP RIP OSPF DGS-3620 RIP OSPF HQ Branch
Target Market and Applications Aggregation solution for service provider network DES-3200 DGS-3620 DES-3200 DGS-3620 DES-3200
Agenda Product Overview Target Market and Applications Technology Briefing Competitive Comparison & Analysis • Positioning Highlight • Key Comparison • Art of the War Appendix
Technology Briefing SFP+ Interface Benefits 10 Gigabit Ethernet Interface Evolution Small size and High port density SFP+ Interface Benefits Lowe power consumption Interchangeable Module Type: Directed Attach Copper (Passive/Active), Optical SR/LRM/LR
Technology Briefing MPLS* provides the “Best-effort Delivery”. It speeds up the data delivery, improves the packet Qo. S and solves the burden of IP routing MPLS adopted the core idea of ATM. It locates itself between IP layer and data link layer and takes the responsibility of carrying any traffic over itself What MPLS learns from ATM: • Thinking of label switching • Using Local Label instead of global IP address 3 1 40 3 1 47. 350 3 47. 1 2 1 47. 2 2 IP 47. 1. 1. 1 Note: DGS-3620 will support MPLS in the future
Technology Briefing MPLS L 3 VPN MPLS VPN: Allows Service Provider to to plan, provision, and manage for IP VPN service on the fast switching MPLS network MPLS L 3 VPN = VPN + BGP + MPLS BGP to exchange VPN and label info 10. 10. 10. 0/24 CE 1 Customer A VRF 1 PE 1 CE 2 10. 10. 0/24 Customer B VRF 2 MPLS tag switching Customer A 10. 10. 0/24 VRF 1 P CE 3 PE 2 VRF 2 MPLS tag switching CE 4 10. 10. 0/24 MPLS Network Customer routing information is exposed to Service Provider VRF(VPN Routing & Forwarding Instance): routing table instance for each customer Customer B 10. 10. 0/24
Technology Briefing MPLS L 2 VPN: VPWS & VPLS VPWS (Virtual Private Wire Services) is point-to-point. VPLS (Virtual private LAN service) is multipoint. Carrier Ethernet logically connects to MPLS core via Q-tag, Q-in-Q or simple p 2 p MPLS tunnels MPLS core carries pure Ethernet over MPLS without customer Layer 3 routing control Customer routing information is NOT exposed to Service Provider
Technology Briefing Ethernet Ring Protection Switching (ERPS) First industry standard (ITU-T G. 8032) on Ethernet ring protection switching Support interconnected ring or multiple rings application Best case: 50 ms recovery time for 16 -node ring with <1, 200 Km circumference STP RSTP ERPS Topology Type Any Topology Ring / Multiple Ring Convergence Time 30 -50 seconds 1 second 50 -200 ms! Aggregation Ring Master Link Down! Master Access Ring Disable Blocking Link Down!
Technology Briefing Bandwidth Control & 3 Color Marker Single user/service per port, with bandwidth limit (Port Bandwidth Control) Multiple users/services per port, with bandwidth limit (Flow-based Bandwidth Control) Multiple users/services per port, with bandwidth limit and guaranteed bandwidth (Three Color Marker & Policing) • Committed Information Rate (CIR): Guarantees the bandwidth of each service by limiting the bandwidth of each other. • Peak Information Rate (PIR): Allows services take the unused bandwidth for better bandwidth usage. • Traffic Policing: Drops or remarks the packet Vo. IP priority tag for traffic exceeding CIR. Doing CIR best-effort forwarding when peak of each PIR service are conflicted. Data Total UNI (User Network Interface) Bandwidth IPTV R CI R PI PIR CIR
Technology Briefing Traffic Shaping To provide better quality of service, DGS-3620 supports some advanced features: • Reserve buffer memory for important services • Configurable buffer size for each important service - Excess Burst Size (EBS) - Peak Burst Size (PBS) - Committed Burst Size (CBS) PIR/EIR Drop No reservation for Data exceeding PIR CBS for Data Buffer Memory CIR Store to PBS/EBS Data EBS for IPTV bps Max. Switching Capacity Store to CBS PIR/EIR Guaranteed Forwarding CIR CBS for IPTV Overall Output Delay Forwarding Time
Technology Briefing OAM ISP Cloud VPN Service Local ISP Cloud Link OAM … … Link OAM Local ISP Cloud … … Link OAM Service OAM for customer level Service OAM for ISP level Service OAM for local ISP Link OAM • Check the link status hop-by-hop • IEEE 802. 3 ah • Live & death check • Failure indication (Power, link, critical events) • Discovery Service OAM for local ISP Service OAM • Check the channel status of different service levels • IEEE 802. 1 ag, ITU-T Y. 1731 • Live & death check • Performance Monitoring • Management Operation • Test Operation
Technology Briefing ITU-T Y. 1731 is a super set of IEEE 802. 1 ag, providing better OAM control for customers Both Y. 1731 and 802. 1 ag support: • Continuity Check Message (CCM): Loss of connectivity defect detection • Loopback Message (LBM): Defect localization • Link Trace Message (LTM): Verification of network configuration Y. 1731 also support: • Alarm Indication Signal (AIS): Alarm suppression of server (customer) layer • Locked (LCK): Indication of service unavailability due to maintenance activities • Test: Throughput, frame loss and bit error measurement • Loss measurement (LM): Frame loss measurement • Delay measurement (DM): Frame delay measurement • Maintenance Communication Channel (MCC) • Experimental OAM (EXP) • Vendor Specific OAM (VSP)
Agenda Product Overview • Target Market and Applications • Product Position Technology Briefing Competitive Comparison & Analysis • Positioning Highlight • Key Comparison • Art of the War Appendix
Agenda Product Overview • Target Market and Applications • Product Position Technology Briefing Competitive Comparison & Analysis • Positioning Highlight • Key Comparison • Art of the War Appendix
Appendix D-Link Metro Product Portfolio ISP Core • MPLS • BGP DGS-3620 Series DES-7200 Series DGS-8000 Series Aggregation • • DGS-3120 DGS-3700 Y. 1731 OAM DGS-3710 AC/DC DGS-3400 Combo Design DGS-3420 ERPS Mobile Backhaul • IEEE 1588 DGS-3620 Series • MPLS • Y. 1731 OAM L 3 ETTx Access Series Series* • Y. 1731 OAM • Adv. Qo. S • MPLS/BGP DES-3810 Series DGS-3620 Series L 2 ETTx Access VDSL PON • Y. 1731 OAM • ERPS • Adv. Qo. S DES-3528/52 Series DES-3200 Series DGS-3120 Series DGS-3400 Series DGS-3420 Series DES-1100 Series Home CPE
