SAKI Automatic Optical Inspection System Presented by: 傅楸善 & 顏慕帆 0933 373 485 r 94922113@ntu. edu. tw 指導教授: 傅楸善 博士
Company Profile DC & CV Lab. CSIE NTU http: //www. sakicorp. com/index. html
Market Share l l l 1996年的2% 2001年的15% 2003年成為世界市場佔有率第 2 (第一: OMRON ) DC & CV Lab. CSIE NTU
Competitor l l l Omron SAKI Orbotech Teradyne (泰瑞達) Agilent (安捷倫) DC & CV Lab. CSIE NTU
Automatic Optical Inspection l BF (B? ? ? F? ? ? )-Planet. X standard model (250 mmx 330 mm) l BF-Frontier LL (Large) size (460 mmx 500 mm) model l BF-Tristar high resolution model DC & CV Lab. CSIE NTU
BF-Planet. X DC & CV Lab. CSIE NTU
Working Theory l Line Scan Technology DC & CV Lab. CSIE NTU
Working Theory l Multi Lighting Technology CCD: Charge-Coupled Device DC & CV Lab. CSIE NTU
Advantage l High-Resolution Imaging System 10 um, 20 um, 40 um with color line CCD l High Accuracy The Telecentric Lens The Automatic Digital Shading System Ball Screw Table Scan l Industry-Leading High Throughput The Alternate Color Digital Scanning System l Accurate Inspection Results The Multi Lighting Technology l Real Time SPC Information SPC: Statistical Process Control DC & CV Lab. CSIE NTU
Reference l l SMT之家論壇, “SMT之家論壇, ” http: //bbs. smthome. net/simple/f 83. html, 2006. Saki, “Saki, ” http: //www. sakicorp. com/index. html, 2006. DC & CV Lab. CSIE NTU
