RTX 4100 WiFi Module Energy Micro Atheros 1

RTX 4100 Wi-Fi Module (Energy Micro & Atheros) 1

QCOM Partnership Signed 2

RTX Wi. Fi Modules Self-contained sensor platform for the “internet of things” MODULES TO ADDRESS DIFFERENT MARKETS § Home automation / Home Security, Medical, Simple Sensors § Industrial, Medical, Smart Appliances, Building Automation, Security Applications § Larger applications (including MMI), Multi-input sensors § Rapid Application Development support through embedded Virtual Machine / Eclipse IDE § Disposable / Li-On battery support § Days to years of operation time § Solder-down and connectorized versions 3

RTX 4100 Wi-Fi Module KEY FEATURES § Ultra Low Power Wi. Fi (802. 11 b/g/n) § Designed for years of battery life § Very fast sleep to wake-up, and visa versa § FCC Certified §Antenna on-board, with external antenna connector option § All Wi. Fi-related firmware included on Module § No ”drivers needed; Host is on-board § UART, SPI, I 2 S interfaces § Application framework, tools, and memory space for embedded user applications § Multiple sensor interfaces and ADC/DAC ports § Very small: only 18 mm x 30 mm, including antenna 4

RTX 41 xx Module Roadmap Self-Contained Wi-Fi sensors for the “internet of things” High-End w. Connector SDK Based Mid-End Solder-On SDK Based Low End Solder-On EVK based RTX 4140 Connector Antenna: Both In/Ext 36/4 k. B App space RTX 4100 -EXT Solder On Antenna: External RTX 4100 -IN Solder On Antenna: Internal RTX 4120 -IN Solder On Antenna: Internal Module Demonstrator RTX 4100 -SDK V 2 Over-the-Air FWU Firewall access RTX 4120 -EVK UART / SPI control or Small sensor app Q 1 -2013 SDK Software RTX 414 x-SDK Virtual Machine RTX 4141 -SDK SEP 2. 0 Co. AP, Security RTX 4100 -SDK Co. AP Cloud Support Q 3 -2012 Module MP Availability RTX 4141 LCD controller Antenna: Both In/Ext 256/16 k. B App space EVK Software (Host based) RTX 4100 -SDK V 3 Virtual Machine RTX 4121 -IN Solder On Antenna: Internal Cost / Size Reduction RTX 4102 Solder On Cost Reduction RTX 4121 -EVK UART / SPI control or small sensor applications Q 3 -2013 5

RTX Modules Self-contained Wi-Fi sensors for the “internet of things” Battery Sensor TYPICAL SENSOR ARCHITECTURE Low Power Wi-Fi link 2 -layer Carrier Board Device Manufacturer simply adds inexpensive carrier board holding sensor HW and Battery 6

Rtx 4100 low power Wi-Fi module FUNCTIONALITY AT A GLANCE Dimensions & Power Connectivity • Small size: 30 x 18 mm • 3. 2 – 4. 6 V supply voltage • 5 – 500 u. A typical power consumption (Qo. S dependent) • • MCU Features • Energy Micro G 230 • ARM Cortex M 3 (<160 u. A / MHz), up to 40 MHz • 5 low power modes • Ultra fast wake-up • IEC 60335* safety standard support • • 802. 11 b/g/n @ 2. 4 GHz WEP / WPA 2 / WPS Direct Wi-Fi support FCC Certified (PCB / on-board antenna) • Low-cost mounting and soldering side connector Full IPv 4 / IPv 6 stack Security Modules Low Power RTOS SEP 2. 0 / Co. AP Web server with remote access Remote FWU Complete application on-chip 7

Low Power Leader 8

RTX 4100 low power Wi-Fi module FLEXIBILITY THROUGH RICH I/O INTERFACE Pin Connections (30) Dimensions: 30 x 18 mm Solder pad pitch: 2 mm 1 x Vdd (3. 2 – 4. 6 V) 4 x Ground 2 x UART 2 x I 2 C 1 x SPI 8 x GPIO 2 x ADC (16 bit) 2 x DAC (12 bit) Debug and Development Ports 9

RTX 41 xx MODULES Mid Range: Surface Mount, 36/4 k. B App Space • SKU: RTX 4100 -IN • SKU: RTX 4100 -EX • SKU: RTX 4100 -EC Sampling now Production Aug/Sept > 1 k: Tape-and-Reel (490) High End: Connector, 256/64 k. B App Space • • • SKU: RTX 4140 -IN SKU: RTX 4140 -EX SKU: RTX 4140 -EC EVAL KITS SOFTWARE DEV Evaluation Kit: SKU: RTX 4100 -EVK Software Development Kit: SKU: RTX 4100 -SDK Box Content: • 1 Wireless Sensor App Board (WSAB) containing RTX 4100 -IN • 1 USB-UART Cable (FTDI) • 1 Adaptor to WSAB • 3 x AAA cells • Documentation Box Content: • 1 Docking Station for WSAB • 1 USB cable (power + download) • Software Development Kit (SW) • Demo Applications as source • Documentation Functionality: • Control of RTX 4100 over simple terminal app • Demonstration of RTX 4100 • Full API over UART (optional) for external MCU Functionality: • Development of user applications to run directly on module • No external MCU required Availability: Contact RTX Low End: Surface Mount, API over UART/SPI • SKU: RTX 4120 -IN Availability: Contact RTX 1 x Stand-alone WSAB: Wireless Sensor Application Board containing RTX 4100 -IN SKU: RTX 4100 -WSAB Packaging: ESD Bag JTAG Debugger RTX Unity-II SKU: RTX-UNITY-II Functionality: JTAG debugging of RTX 4100 -EVK and RTX 4100 -SDK Packaging: Box + SW

Wireless Sensor Application Board (WSAB) 11

Amelie Wi-Fi module software Software architecture & programming models 12

Co-located Application Blocks 13

Amalie 1. 0 Firmware Blocks 14

Amalie 1. 0 Firmware Blocks 15
