National Kentucky Height Modernization Program

National Height Modernization Program • Significant time savings in field surveying using GPS Height Modernization • Accurate determination of floodplain boundaries will provide accurate, reliable heights using GPS leveling. • Precise control for with digitaltraditional ortho imagery • Accurate control for reliable Digital Elevation Models Facilitate mapping and for • Improved elevation control for planning GIS base maps • Floodplain management • Subsidence monitoring in mining and karst regions • Homeland Defense • Economic Development • Infrastructure monitoring (e. g. dam and floodwall) Falmouth, KY - 1997 The Cincinnati Enquirer

National Height Modernization Program FY 06 funding

Kentucky Height Modernization Program 10, 461 benchmarks remain in NGS database 20 % reported “not found” or in “poor condition” 23 % in last 25 years were reported as “good” Only 12 % reported as “good” in last 10 years NSRS benchmarks in Kentucky

Kentucky Height Modernization Program

Kentucky Height Modernization Program Congressman Hal Rogers October 25, 2004 "I am pleased to announce today that Kentucky will receive funding for Height Modernization in NOAA’s fiscal 05 budget. " and in FY 06 too!

Kentucky Height Modernization Program The goal of the Kentucky Height Modernization Program is to bring accurate and reliable heights to any location in the Commonwealth at any time. The realization of this goal has three Phases: 1. Establishment of geodetic control to improve the regional geoid model and provide a reference frame for surveying and remote sensing measurements. 2. Development of an accurate Digital Elevation Model (DEM) from data collected by Light Detection and Ranging (LIDAR) and calibrated to the geodetic control. 3. Creation of products which make the geodetic control and DEM accessible to a broad range of users, by packaging it with statewide digital orthophotography.

Kentucky Height Modernization Program H = Orthometric Height (elevation) h = Ellipsoidal Height (from GPS) N = Geoid Height (from Geoid model) H h N Ellipsoid GRS 80 Geoid 03 N H=h-N Topographic Surface

Kentucky Height Modernization Program Kentucky regional geoid model

Kentucky Height Modernization Program FY 2005 Appropriation $492, 829 Responsibility split between National Geodetic Survey & Morehead State University KY Div of Geographic Information Kentucky Transportation Cabinet CORS antenna poured concrete post mount

Kentucky Height Modernization Program Division of Responsibilities Morehead State University 1. 2. 3. Grant recipient from NOAA. Submit application and project reports for Grant, Develop Kentucky CORS Data Archive Center. KY Division of Geographic Information 1. 2. 3. Provide overall Height Modernization Project management Develop project charters, plans and agreements, Coordinate with related organizations such as the flood map modernization committee. Kentucky Transportation Cabinet 1. 2. Install and provide ongoing support of the CORS sites (to be located at Highway District Offices) Manage the award of contracts and oversight of the work. CORS antenna building wall mount

Kentucky Height Modernization Program

Kentucky Height Modernization Program National CORS Morehead State U. CORS (National CORS in December 2005) KY Transportation Cabinet CORS (KY-HMP FY 05)

Kentucky Height Modernization Program in FY 2006 $498, 101 Begin leveling to FBN and CORS

Kentucky Height Modernization Program in FY 2006 Begin leveling to FBN and CORS

Kentucky Height Modernization Program in FY 20? ? LIDAR and it’s Products DEM - Digital Elevation Model
