Road Weather Information Systems RWIS Snow Conference Saskatoon

Road Weather Information Systems (RWIS) Snow Conference, Saskatoon September 2018 Ted Reeler P. Eng. woodplc. com

wood plc Wood is a global leader in technical, engineering and project services over 160 years of experience around $10 BN revenue 55, 000 people, 60 countries, 400+ offices worldwide 2 A presentation by Wood.

Met-Ocean Services A Team of Meteorologists, Scientists and Technologists 20 meteorologists 20 information management staff 10 staff scientists 10 equipment service technicians • • Primary Business Lines • • • Road Weather Forecasting Energy Forecasting Marine Forecasting Climate Consulting Instrumentation services Information management services Mississauga Ottawa Halifax St. John’s 3 A presentation by Wood.

Road Weather Information Systems 450 RWIS Sites in 7 Canadian Provinces monitored in real time 15 Years RWIS 4 Monitoring and Analysing Pavement Condition Temperature Models

What is RWIS - Road Weather Information Systems Wind Speed/Direction 30 foot roadside meteorological folding tower Traffic Camera Air Temperature / Pressure Snow Depth Sensor RWIS Processing Unit RPU Tipping Bucket Rain Gauge Road Surface Sensor 5 A presentation by Wood. RWIS helps Provinces and Municipalities to Keep Winter Roads Safe RWIS tells them: • When will the Pavement Freeze? caption over • When. Add will chemicals be required? • Whencoloured to clear the Winter Roads? rectangle on detailed images.

RWIS Weather Web Portal Add caption over coloured rectangle on detailed images. 6 A presentation by Wood.

Radar Precipitation Types Add caption over coloured rectangle on detailed images. 7 A presentation by Wood.

Atmospheric Forecasts Atmospheric Local Area Forecast 8 A presentation by Wood.

Pavement Temperature Forecasts Pavement Temperature Forecast 9 A presentation by Wood.

Smartphone Formats Local Area Forecast and Pavement Temperature Forecast for Smartphones 10 A presentation by Wood.

Data Accessibility Add caption over coloured rectangle on detailed images. 11 A presentation by Wood.

Maintenance Decision Support (MDSS) Add caption over coloured rectangle on detailed images. 12 A presentation by Wood.

Mini RWIS Stations As a supplement to the Full RWIS Network Ø Ø Ø Providing Additional Data, Cameras and Forecasting Potential low cost; basic instrumentation; include a camera; polled only once per hour; air temperature; non invasive pavement temperature; relative humidity; dew point; at locations in remote areas with no power (solar powered); at temporary locations and/or for a lower cost (potentially movable). Add caption over coloured rectangle on detailed images. 13 A presentation by Wood.

Mini RWIS Stations Add caption over coloured rectangle on detailed images. 14 A presentation by Wood.

Mobile RWIS 15 A presentation by Wood.

Mobile RWIS 16 A presentation by Wood.

Virtual RWIS Additional pavement temperature forecasts Ø Ø Ø along critical sections of highway; showing differences for localized micro climates; interpolated between 2 or more existing RWIS stations; monitored by mobile RWIS to improve the quality; mobile data is collected (light and dark blue); pavement temperature profiles are developed over time; cold patches are identified along the highway in different weather conditions; localized micro climates are analyzed in more detail. Add caption over coloured rectangle on detailed images. 17 A presentation by Wood.

Roads Structural Integrity 18 A presentation by Wood.

Road Condition Warning System (RCWS) Specialized RWIS Instrumentation Specialized Weather Models for Micro Climates Dynamic Message Signs activated Alerts Sent to Authorities Highways Closed 19 A presentation by Wood. Vaisala Visibility Sensor

Tantramar Marsh RCWS between New Brunswick and Nova Scotia 20 • Whiteout conditions closed the Trans Canada Highway for 12+ hours in February 2015 • A collaborative warning system was developed for the Sackville to Amherst corridor A presentation by Wood.

Public Facing 511 Interactive Map Based on Severe Weather Forecasts with Thresholded Values Ø Ø 21 A presentation by Wood. Interactive map available on line Alerts the public of any inclement weather affecting driving conditions Based on severe weather forecasts with thresholded values Categorized Driving Conditions; Good / Fair / Caution / Poor

Winter Severity Index Calculation of winter severity by area: 22 Ø based on precipitation (snow, freezing rain), freeze thaw cycles, wind (blowing snow); Ø accumulating values over the winter season; Ø tailored for Performance Based Snow Clearing Contracts. A presentation by Wood.

Road Weather Forecasting for Truck Companies Ø Transportation Companies deploy their vehicles on cross country trips Ø Forecast Freezing Roads, High Winds and Low Visibility along road segments Ø Thresholded to Corporate Safety Standards Add caption over coloured rectangle on detailed images. 23 A presentation by Wood.

Dashboards Showing Hazards Ø Specialized Alerting based on specific concerns Ø Industries and Organizations have their own safety thresholds Add caption over coloured rectangle on detailed images. 24 A presentation by Wood.

Questions Ted Reeler P. Eng. Senior Project Manager Wood Environment & Infrastructure Solutions Ottawa, Ontario, Canada 613 -727 -0658 ext. 2365 ted. reeler@woodplc. com
