RFID Laboratory in ISU Dr. Wei-Cheng Lin 2007/5/10 The Advanced Digital System Research Center
產學合作團隊 • 億威電子 http: //www. emmt. com. tw與AWID http: //www. awid. com – Full Spectrum Readers and Tags Provider in RFID Industry • 雲義科技http: //www. unipattern. com. tw – 開發提升企業經營效率之智慧型軟體解決方案 • 精技電腦ADC事業群http: //www. unitech. com. tw – 訂制型軟體開發以及系統整合服務提供者 7
Demonstration Scenario • RFID System: – Passive Tag + Fixed Reader + Multi-Antenna + Ethernet – Passive Tag + Handheld Reader + Bluetooth • Scenario 1: Range Extension by Antenna Array – 4 m/MPR 2012 BN 4. 5 m~8. 5 m/MPR 3014 WF • Scenario 2: Data Read/Write for Passive Tag – Read: 60 cm, Write: 35 cm/MPR 1610, EPC C 1 G 2) – Multi-Communication Media 11
天線陣列式乙太網路RFID系統 MPR 3014 WF Ethernet Internet/Intranet Router Po. E-TCPIP Coax Cable 1 m Max. TCPIP Interface Console MPR-2012 BN MPR-2012 ANT External Exp. Antenna Customized Software Antenna Array Inlet 12
行動式藍芽RFID系統 Bluetooth Software HF Handheld Reader MPR-1610 Bluetooth USB RS 232 Console Inlet 13 Customized Software
