Review of Underwater Vehicles Module 1 Section 1
- Slides: 27
Review of Underwater Vehicles Module 1, Section 1
Types of Underwater Vehicles Insert Fig. 1. 3 from text book
Types of Underwater Vehicles n Manned Vehicles n Unmanned Vehicles n Non-Vehicles
Manned Vehicles n Submarines n Atmospheric Diving Suit
Submarines Military n Research n Tourist n
Military Submarines Classified by Propulsion System: n Nuclear n Diesel-Electric Classified by Mission n Attack n Missile
Research Submarines Submersibles n Smaller n Carries 2 to 3 scientists n
Tourist Submarines
Atmospheric Diving Suit Resemble space Suits n One person Submersible n Expensive to maintain n
Ocean. Works Atmospheric Diving Suit (ADS) The best current example of nonhyperbaric underwater intervention. The secret is in the pressure balanced joints. Note claws and limited visibility.
Unmanned Vehicles n ROVs n AUVs n Hybrid Vehicles
ROVs Free-Swimming n Bottom Crawling n Structurally Reliant n
Free Swimming ROVs n n All are tethered Tether provides, power and data Equipped with video/TV Cameras Highly maneuverable
Free Swimming ROVs n n Heavy Duty Work Class High-Capability Electric Small (electric) ROV Observation Class
Heavy Work Class They primarily service the oil and gas industry n 225 Horsepower - 2900 pounds of vertical lift n Multiple heavy tools n
Work Class Electro-Hydraulic 100 -200 HP n Millennium Drilling support, Construction, Pipeline or Inspection
High-Capability Electric n n n Compact work class system Not as powerful as hydraulic 2000 -4000 lbs Payload 220 -440 lbs Depth capacity to approximately 3, 000’
Small (electric) ROV (Observation Class) n n n Lower Cost Usually less than 10 HP Used for inspection Observation Search and Rescue Scientific Exploration
Bottom Crawling ROVs Large n Heavily Weighted n Used for trenching and burying cable n 500 Horsepower Cable and Pipeline, Trencher
Structurally Reliant ROVs Attached to various types of underwater structures n Used for cleaning or inspecting structure they are attached to n
AUVs Autonomous Underwater Vehicles n n n Tether less Carries own power No pilot Pre-Programmed Easy Launch and Recovery
Gliders n Require less stored energy
Hybrid Vehicles n n n Nereus Can be operated as an ROV or as an AUV http: //www. whoi. ed u/home/interactive/ nereus/
Non-Vehicles n Underwater n Tow Habitats fish n Anchored Platforms
Underwater Habitats
Tow fish
Anchored Platforms
