Recap QUANTITIES Taking out quantities WHY do we

Recap QUANTITIES Taking out quantities

WHY do we need quantities?

3 WAYS 1. Based on m 2 price of building type 2. Based on m 2 of building component 3. Based on detailed calculations of Materials, Manpower, Machinery

Today you will use 1. Based on m 2 price of building type 2. Based on m 2 of building component 3. Based on detailed calculations of Materials, Manpower, Machinery

PRICE In order to CALCULATE THE PRICE of a building you need to know the quantities of: • • • Building Materials Man Power Machinery / Equipment

TYPE OF WORK (TRADES OR PROFESSIONS) • • SOIL WORK (construction worker) SEWER (auth. construction worker) CONCRETE (concreter) BRICKWORK (bricklayer) CARPENTRY WORK (carpenter) DEKORATION (painter) INSTALLATION (plumber, electrician, etc. ) How many do you have?

YOUR JOB To take out quantities for: • Concrete Works • Masonry Works • Concrete Element works

2 WAYS To take out quantities: • MARK THE AMOUNT ON DRAWING PRINTOUTS AND CALCULATE QUANTITIES • EXTRACT QUANTITIES DIRECTLY FROM REVIT MODEL

WBS ”Breakdown of the total project into trades, building components or other units”

OPEN REVIT FILE: Take out quantities for your trade. Calculate the price an fill it in the Bidding form

BID ”An offer to the client to make a job for a certain payment”

DEADLINES FOR QUANTITIES/PRICE: FRIDAY AT 08: 00 THE 3/3 2017
