EFW Organization RBSP Project Office APL RBSP SWG EFW PI John Wygant UMN EFW Co-I team EFW PM Keith Goetz UMN LASP lead Bob Ergun LASP UCB lead John Bonnell UCB LASP PM Mary Bolton LASP UCB PM John Bonnell UCB DFB SE Susan Batiste LASP Mechanical Paul Turin UCB Goetz EFW CAM Kim Cooper APL SE Michael Ludlam UCB SMA Ron Jackson UCB Finance Kate Harps UCB Electrical Michael Ludlam UCB Flight Software Peter Harvey UCB Ground SW Will Rachelson UCB RBSP/EFW CDR 2009 9/30 -10/1 290
Communication • • Weekly APL-EFW telecon Weekly EFW team telecon – Alternating electrical and mechanical emphasis • • • Weekly PM-CAM telecon Weekly burn-down tracking of near-term deliverables Bi-weekly SWG telecon Bi-weekly RBSP all hands telecon Bi-weekly RBSP PI/PM telecon Monthly Risk board telecon Monthly schedule/cost/EV telecon Quarterly RBSP project reviews Other telecons scheduled as needed APL RBSP forum – https: //sd-forum. jhuapl. edu/RBSP-IT • EFW ftp archive – ftp: //apollo. ssl. berkeley. edu/pub/RBSP • More complete and frequent communication than previous projects Goetz RBSP/EFW CDR 2009 9/30 -10/1 291
Review History • • • RBSP Mission Concept Review RBSP Requirements & Mission Definition Review RBSP/EFW Preliminary Design Review (w/ SOC) RBSP Mission Preliminary Design Review RBSP/EFW Peer Reviews – – AXB, SPB, IDPU structure PRE, BEB, DCB electronics, backplane, harness DCB FPGA, DCB FSW DFB electronics, DFB FPGA 30 -31 January 2007 2 -4 October 2007 3 -4 September 2008 14 -16 October 2008 28 July 2009 2 September 2009 3 September 2009 10 September 2009 • RBSP/EFW Critical Design Review 30 September 2009 • • RBSP Mission Critical Design Review RBSP/EFW SOC Critical Design Review 1 -3 December 2009 28 January 2010 Goetz RBSP/EFW CDR 2009 9/30 -10/1 292
RFAs/AIs from earlier reviews • IPDR resulted in – – Total RFAs: EFW instrument RFAs EFW SOC RFAs Project RFAs 29 received 20 received 5 received 4 received 20 in 2 in 19 concurred 2 concurred • MPDR produced no EFW RFAs Goetz RBSP/EFW CDR 2009 9/30 -10/1 293
Sparing plan • In general, fully qualified flight spares are not required and are not being built for RBSP/EFW • Limited sparing is being done where it makes sense – A flight spare DFB board will be built – Flight spare electronic parts will be obtained but not assembled in the cases of the DCB, BEB and LVPS – Flight spare mechanisms will be built but not fully qualified in order to save money • Should spare or replacement components be needed, we would assemble and qualify as required Goetz RBSP/EFW CDR 2009 9/30 -10/1 294
Critical Facilities • Facilities at LASP – LASP cleanrooms, assembly and test areas are ready to go and will be available throughout the flight hardware fabrication program • Facilities at UCB – UCB cleanrooms, assembly and test areas are ready to go and will be available through the flight hardware fabrication, testing and qualification program • This includes appropriate vacuum chambers for all TV configurations – Vibration testing will be done at a contractor in the bay area – EMC testing will be done at a contractor in the bay area Goetz RBSP/EFW CDR 2009 9/30 -10/1 295
Staffing • Personnel at LASP – LASP personnel are certified as needed and ready to go throughout the fabrication and testing period • Personnel at UCB – UCB personnel are certified as needed and ready to go throughout the fabrication, testing and qualification program • Workforce risk – Both UCB and LASP have other programs ramping up in the near future – Other programs could infringe on EFW personnel making it difficult to find the appropriate skill mix at the required time – Mitigation has been to add personnel where possible – Mitigation is also to move forward with the fabrication of flight hardware well in advance of the mission CDR Goetz RBSP/EFW CDR 2009 9/30 -10/1 296
Deliverables • • • • • • Instrument Requirements Document – baseline (SE-001 C) Deviations/Waivers (CM-002 -004) Performance Assurance Matrix – update (MA-001 C) GSE Interface FMEA – baseline (MA-002 -007 A) Limited Life Items List – baseline (MA-002 -009 B) As-Designed Parts List (MA-005 -002 B) Spares List – baseline (MS-006 -001) Long Lead Items List – as applicable (MS-006 -002) CMD/TLM Definitions – preliminary (SE-005 -001 B) Instrument User’s Manual Information – preliminary (SE-006 -001 A) As-Designed Materials and Processes List – (SE-007 -009 B) Software Requirements Document – baseline (SW-002 -001 B) Software Integration, Verification and Test Plans – preliminary (SW-005) Instrument Verification & Validation Plan – preliminary (TE-001 -002 A) Test Plan Inputs for S/C I&T – baseline (TE-004 -001 B) Instrument Test and Calibration Plan – preliminary (TE-001 -002 A) Indentured Drawing List – baseline (CM-002 -001 B) Top Level Assembly Drawing – baseline (CM-002 B) Drawings & Schematics – baseline (CM-002 -003 B) Instrument to spacecraft ICD - draft (SE-002 -001 D) Contamination Control Plan (SE-008) Goetz RBSP/EFW CDR 2009 9/30 -10/1 297
Deliverables - Periodic • Monthly progress • Monthly schedules – EFW master integrates all activity • • Mechanical Electrical LASP I&T • Monthly financial (533 M & 533 Q) • Monthly EV tracking and analysis • Quarterly status Goetz RBSP/EFW CDR 2009 9/30 -10/1 298
Performance to Date • Phase C use of funding reserve – $1, 381 k was the EFW held reserve at the start of phase C • Project holds a similar amount on our behalf – Since then, we have made or will make use of some reserve funding • • • $140 k $53 k $20 k $120 k $20 k LVPS redesign Vibration force limiting LVPS parts DIN 96 replacement Frangibolt switches – $353 k of $1, 381 k which is 25% of local reserve Goetz RBSP/EFW CDR 2009 9/30 -10/1 299
Reserve to Delivery • • Reserve was set to 20 days and then increased to 46 (required) Reserve will not be touched… Slack is adjusted monthly to match critical path In April, issues pushed i. CDR out, reduced slack – LVPS – DIN 96 – AXB tuning Goetz RBSP/EFW CDR 2009 9/30 -10/1 300
Slack used to i. CDR • • Booms started out on the critical path LVPS issue developed in April, i. CDR slipped in May LVPS correction was slow through the summer AXB tuning used Boom slack in the summer Goetz RBSP/EFW CDR 2009 9/30 -10/1 301
Schedule • Into the future – Critical path going forward is AXB development • Due to a series of environmental tests – Following that, the SPB development is next on the CP • Long lead parts are mostly in hand – A few stragglers are due in December • Designs are in good shape • Drawings are being released for flight fab • EM development success will lead to FM development on time and on budget • Cost projections, based on past projects and the EFW EM program suggest we’re within our cost envelope – Original C/D EV budget was $12, 707 k – Current C/D EV EAC is $12, 593 k Goetz RBSP/EFW CDR 2009 9/30 -10/1 302
Schedules Axial Booms CP Goetz RBSP/EFW CDR 2009 9/30 -10/1 303
Schedules Spin Plane Booms Goetz RBSP/EFW CDR 2009 9/30 -10/1 304
Schedules UCB Electronics Goetz RBSP/EFW CDR 2009 9/30 -10/1 305
Schedules LASP electronics Goetz RBSP/EFW CDR 2009 9/30 -10/1 306
Schedules Integration & Test Goetz RBSP/EFW CDR 2009 9/30 -10/1 307
Fabrication Milestones • • • • • IDPU F 1 assembly complete IDPU F 2 assembly complete Boom PER Spin Plane Booms F 1/F 2 complete Axial Booms F 1/F 2 complete EFW full F 1 I&T starts EFW full F 2 I&T starts Instrument F 1 PER EFW F 1 Environments begin Instrument F 2 PER EFW F 2 Environments begin F 1 Completion (CBE) F 2 Completion (CBE) F 1/F 2 PSR (prior to reserve) Slack Reserve F 1/F 2 Delivery to APL Launch Goetz 25 Feb 2010 4 Apr 2010 7 Apr 2010 20 May 2010 6 July 2010 15 June 2010 7 July 2010 23 July 2010 26 July 2010 16 Aug 2010 17 Aug 2010 31 Aug 2010 17 Sept 2010 20 Sept 2010 (CP) 46 days 9 Feb 2011 18 May 2012 RBSP/EFW CDR 2009 9/30 -10/1 308
Risk Goetz RBSP/EFW CDR 2009 9/30 -10/1 309
Risk detail - page 1 Goetz RBSP/EFW CDR 2009 9/30 -10/1 310
Risk detail - page 2 Goetz RBSP/EFW CDR 2009 9/30 -10/1 311
Risk specifics • E-05 AXB Shadowing – We expect the aft AXB to be shadowed by the S/C body. Requirements allow this but science return would be improved if the AXBs can be in sunlight. To this end, we’ll be prepared to deploy up to 7 m of AXB if S/C stability observations allow it. • E-25 DFB FPGA Verification – Verification of the FPGA code has lagged. Manpower has been added. • E-23 LVPS Immature – LVPS implementation is new and not as far along as it could be. Added manpower has been focused on this issue. • E-18 NTE Power – CBE power estimates are edging up to NTE. Power uncertainty is not yet low enough to dismiss. Project accepts the likelihood of a small increase to our NTE. • E-14 Flight Hardware Delayed – Other SSL projects could make it hard to get the appropriate skill mix in the appropriate time frame for FM fabrication and I&T. Pushing forward to complete fabs. Adding manpower. • E-26 Peek Charging – Small amounts of peek are scattered throughout deployment mechanisms. If changes are needed, they must come soon. Goetz RBSP/EFW CDR 2009 9/30 -10/1 312
