Rad Hard Products for Satellites and Space ®

Rad Hard Products for Satellites and Space ®

QPRO for Avionics w Standard QPRO products immune to upsets in avionics environment w

QPRO for Avionics w Standard QPRO products immune to upsets in avionics environment w Extensive neutron SEU testing performed - Stability of device storage cells prevents upsets - Readback feature allows user to verify data in the configuration latches w No reported instance of alpha particle induced soft error - Polyimide coating provides effective barrier www. xilinx. com ®

Neutron Testing Results Single-Event Upset w Devices Tested XC 4010 E (5 V) XC

Neutron Testing Results Single-Event Upset w Devices Tested XC 4010 E (5 V) XC 4010 XL (3. 3 V) 178, 096 SRAM-bits 283, 376 SRAM-bits w Irradiated with 100 Me. V cyclotron neutron energy w SEU Rate at aircraft altitude (~30, 000 Ft. ) XC 4010 E: 1 bit error per 600, 000 flight hours (68. 5 years XC 4010 XL: 1 bit error per 125, 000 flight hours (14. 3 years w No Latch-up ® www. xilinx. com

Major Avionics Customer Conclusion “SRAM-based FPGAs (Xilinx XC 4000 series) show a low susceptibility

Major Avionics Customer Conclusion “SRAM-based FPGAs (Xilinx XC 4000 series) show a low susceptibility to single event upsets caused by high energy neutrons…… we conclude that these SRAM-based FPGAs can be used without limitation in the atmospheric radiation environment, contrary www. xilinx. com ®

Rad Hard Products w Only Re-Configurable Rad Hard FPGA w Manufactured on QML line,

Rad Hard Products w Only Re-Configurable Rad Hard FPGA w Manufactured on QML line, special epi process w Utilize same geometries as non-rad Hard QML devices to facilitate prototyping w Guaranteed radiation specs w Densities up to 1 M system gates with Virtex www. xilinx. com ®

IC Process w Advanced CMOS process enhanced with epitaxial layer – 0. 35 um

IC Process w Advanced CMOS process enhanced with epitaxial layer – 0. 35 um for XQR 4000 XL – 0. 22 um for Virtex – 7 um epitaxial substrate ® www. xilinx. com

Radiation Specifications w Total Ionizing Dose – XQR 4000 XL = 60 Krads(si) –

Radiation Specifications w Total Ionizing Dose – XQR 4000 XL = 60 Krads(si) – Virtex = 100 Krads(si) – QA monitor on every wafer lot w Latch-up Immune LETth >120 Me. V*cm 2/mg @ +125 o. C w Low Soft Upset Rates ® www. xilinx. com

Total Dose Testing w Testing performed at Mc. Clellan AFB, Sacramento, CA. – Cobalt-60

Total Dose Testing w Testing performed at Mc. Clellan AFB, Sacramento, CA. – Cobalt-60 source – Per MIL-STD-883, Method 1019. 5 – Dose rate of 50 rads/sec w Irradiated parts tested to full production test program ® www. xilinx. com

XQR 4000 XL Family Product Package. System Gates Available XQR 4013 XL-3 CB 228

XQR 4000 XL Family Product Package. System Gates Available XQR 4013 XL-3 CB 228 Now 10 K to 30 K XQR 4036 XL-3 CB 228 Now 20 K to 65 K XQR 4062 XL-3 CB 228 40 K to 130 K Now www. xilinx. com ®

Virtex Rad Hard Family Product Package System Gates Available XQVR 300 -4 Q 200

Virtex Rad Hard Family Product Package System Gates Available XQVR 300 -4 Q 200 CB 228 300, 000 XQVR 600 -4 Q 300 CB 228 600, 000 XQVR 1000 -4 CG 560 Q 200 www. xilinx. com 1, 000 ®

Rad Hard SPROMs ® www. xilinx. com

Rad Hard SPROMs ® www. xilinx. com

Radiation Hardened Product/Process Roadmap 13 K to 62 K Gates Product Introduced 0. 35

Radiation Hardened Product/Process Roadmap 13 K to 62 K Gates Product Introduced 0. 35 0. 25 XQR 4000 XL 62 K gates 150 K to +1 M Gates Radiation testing completed Introduction 2 Q 00 1 M gates Virtex XQVR 0. 18 1998 1999 >1 M gates Virtex E 2000 2002 ® www. xilinx. com

Space Programs Designed With QPRO Rad Hard Products w Litton Amecom w JPL (miniaturized

Space Programs Designed With QPRO Rad Hard Products w Litton Amecom w JPL (miniaturized satellite receiver) (Mars 2003 lander and rover vehicle) w Draper Labs program) (fault tolerant computer for Shuttle w Los Alamos Labs (reconfigurable computer) w Canadian Space Agency instrumentation) w Raytheon (satellite transponder) w Applied Physics Lab (reconfigurable instrumentation module) w Spar Aerospace w Alcatel (communications satellite) (communications www. xilinx. com satellite) ®
