Proving Triangles Congruent www assignmentpoint com The Idea
- Slides: 23
Proving Triangles Congruent www. assignmentpoint. com
The Idea of a Congruence Two geometric figures with exactly the same size and shape. F B A C E www. assignmentpoint. com D
How much do you need to know. . . about two triangles to prove that they are congruent? www. assignmentpoint. com
Corresponding Parts In Lesson 4. 2, you learned that if all six pairs of corresponding parts (sides and angles) are congruent, then the triangles are congruent. B 1. AB DE 2. BC EF 3. AC DF 4. A D A C ABC DEF 5. B E E 6. C F F D www. assignmentpoint. com
Do you need all six ? NO ! www. assignmentpoint. com SSS SAS ASA AAS
Side-Side (SSS) B E F A C 1. AB DE 2. BC EF D ABC DEF 3. AC DF www. assignmentpoint. com
Side-Angle-Side (SAS) B E F A C 1. AB DE 2. A D 3. AC DF D ABC DEF included angle www. assignmentpoint. com
Included Angle The angle between two sides G I www. assignmentpoint. com H
Included Angle Name the included angle: E Y S YE and ES E ES and YS S YS and YE Y www. assignmentpoint. com
Angle-Side-Angle (ASA) B E F A C 1. A D 2. AB DE D ABC DEF 3. B E included side www. assignmentpoint. com
Included Side The side between two angles GI HI www. assignmentpoint. com GH
Included Side Name the included angle: E Y S Y and E YE E and S ES S and Y SY www. assignmentpoint. com
Angle-Side (AAS) B E F A C 1. A D 2. B E D ABC DEF 3. BC EF Non-included side www. assignmentpoint. com
Warning: No SSA Postulate There is no such thing as an SSA postulate! E B F A C D NOT CONGRUENT www. assignmentpoint. com
Warning: No AAA Postulate There is no such thing as an AAA postulate! E B A C D NOT CONGRUENT www. assignmentpoint. com F
The Congruence Postulates F SSS correspondence F ASA correspondence F SAS correspondence F AAS correspondence F SSA correspondence F AAA correspondence www. assignmentpoint. com
Name That Postulate (when possible) SAS ASA SSS www. assignmentpoint. com
Name That Postulate (when possible) AAA ASA SAS www. assignmentpoint. com
Name That Postulate (when possible) Reflexive Property SAS Vertical Angles SAS Reflexive SAS Property www. assignmentpoint. com SSA
HW: Name That Postulate (when possible) www. assignmentpoint. com
HW: Name That Postulate (when possible) www. assignmentpoint. com
Let’s Practice Indicate the additional information needed to enable us to apply the specified congruence postulate. For ASA: B D For SAS: AC FE For AAS: A F www. assignmentpoint. com
HW Indicate the additional information needed to enable us to apply the specified congruence postulate. For ASA: For SAS: For AAS: www. assignmentpoint. com
