Protostellar jets and outflows what ALMA can achieve

Protostellar jets and outflows — what ALMA can achieve? — 平野 尚美 (Naomi Hirano) 中研院天文所 (ASIAA)

Back to 1980. . . Discovery of the bipolar molecular outflow from L 1551 IRS 5 Snell, Loren & Plambeck (1980)

A scenario of star formation

Why we study jets and outflows? Jets are ubiquitous from proto brown dwarfs (possibly proto planets), protostars, evolved stars, to active galactic nuclei Key words accretion, angular momentum, bipolar Jets from young stellar objects (protostars) spectroscopic observations allow us to study their kinematics → driving mechanism

Issues to be addressed ‣ Can we see the primary jet ejected from the star? CO outflows are likely to be swept-up ambient gas ≠ primary ejecta ‣ Are the jets and outflows transferring the excess angular momentum from accreting material? ‣ Roles of magnetic field Flow geometry v. s. magnetic field ‣ When and how jets and outflows start, and how they evolve?

Highly-collimated jet from HH 211 driving source: High velocity - narrow jet cold (Tbol ~ 33 K) and low luminosity (3. 6 Lsun) protostar CO J=2 -1 observed with the JCMT angular resolution: 20” Mc. Caughrean et al. (1994) CO J=2 -1 observed with the Pd. BI angular resolution: 1. 5” Gueth et al. (1999) Low velocity - a pair of cavities

Highly-collimated jet: an important link between the primary jet and entrained outflow HH 211 Green: H 2 in NIR, Blue & Red: Si. O J=5 -4 Hirano et al. (2006)

Current achievement with the SMA HH 211 Si. O J=8 -7 The innermost pair of knots ‣C-shaped bending ‣~4 sub-knots ‣transverse width < 40 AU 0. 46”x 0. 36” 0. 35”x 0. 23” 0. 24”x 0. 22” Lee et al. (2009)

Observations with ALMA — 1 Search for the evidence of jet ‣ rotation Theoretical prediction The jet is carrying out the excess angular momentum from accreting material ➡ The jet is spinning? ‣ Observationally, only one clear example has been known ‣ CO J=2 -1 jet in CB 26 • 1 Myr old star • much older than the protostars in main accretion phase (< 105 yr) Launhardt et al. (2009)

The velocity gradient across the Si. O jet in HH 211 — a hint of jet rotation? — - The NE side of the jet shows slightly larger velocity as compared to the SW side - The mean velocity gradient ~0. 5 km/s at ~10 AU (0. 035”) 0. 1” x 0. 1” 0. 24” x 0. 22” Lee et al. (2009)

The velocity gradient across the Si. O jet in HH 212 0. 1” x 0. 1” 0. 36” x 0. 33” SN: ~1 km/s @ 24 AU SS: ~1 km/s @ 73 AU Lee et al. (2008)

Search for the rotation in the HH 211 & HH 212 jets ‣ Targets: HH 211 & HH 212 - The axes of these jets are close to the plane of the sky ➡ suitable for searching the velocity gradient across the jets ‣ Lines: Si. O J=8 -7, SO NJ=89 -78, CO J=3 -2 ‣ 1 pointing centered at the protostelar positions ‣ Angular resolution: ~ 0. 1” - the jets need to be spatially resolved along their minor axes

Observations with ALMA — 2 Time variability of the jets

HH 211 jet in 2004 and 2008 beam size: 1. 28” x 0. 84” time interval: 3. 6 yrs proper motion: ~0. 13” ± 0. 04” per year transverse velocity: 170± 60 km/s The Si. O emission from the innermost knot pair has increased

Multi-epoch observations at ~01”resolution ‣ Targets: HH 211 & HH 212 ‣ Lines: Si. O J=8 -7, SO NJ=89 -78, CO J=3 -2 ‣ 1 pointing centered at the protostelar positions ‣ Angular resolution: ~ 0. 1” ‣ proper motion of the HH 211 knots (0. 13”per yr) can be detectable in 1 yr ‣ 3 -epoch observations separated by 1 yr ‣ Variation of the structure of the innermost knots (e. g. new ejection event) is expected

Observations with ALMA — 3 B-field geometry the jets Polarized CO J=2 -1 and dust continuum emission in NGC 1333 IRAS 4 Girart, Crutcher & Rao (1999) Girart, Rao, & Marrone (2006)

B-field measurements using the polarized molecular lines ‣ Targets: HH 211 & L 1448 C ‣ The Si. O emission is bright in these sources ‣ Lines: Si. O J=8 -7, SO NJ=89 -78, CO J=3 -2 ‣ 3 --5 pointings (cover the inner ~30”area) ‣ Angular resolution: ~ 0. 3”-- 0. 5” ‣ Polarization measurements ‣ High dynamic range of >50 is necessary ‣ B-field in the jet v. s. B-field in the disk (from dust continuum observations) ‣ B-field in the jet v. s. B-field in the outflow shell

Observations with ALMA — 4 Search for the highly-collimated molecular jets in protostellar ‣ ‣ outflows Highly-collimated jet like HH 211 is not common Only seen in the extremely young sources CO J=2 -1 outflow from B 335 Yen et al. (2010)

Search for the extremely high velocity jet in class 0 protostars ‣ Targets: Class 0 protostars without extremely high velocity jet ‣ First, try to start from B 335 ‣ Next, go to the various class 0 protostars ‣ Lines: CO J=3 -2 or CO J=2 -1 ‣ 1 pointing centered at the protostelar positions ‣ Angular resolution: ~ 1” ‣ High sensitivity is essential

Near future directions evolutionary sequence ~0. 5– 1” resolution outflows in various evolutionary stages -when and how the outflow starts? -when and how the EHV jet develops and disappears? outflow study with various lines ~0. 5– 1” resolution -shock chemistry -chemical evolution higher angular resolution -which line is suitable down to < 0. 1” for probing the primary well studied objects ejecta? -structure and kinematics near the base -jet rotation? , precession? -proper motion study -time variability study
