Proto DUNE SP Slow Control Status Giovanna Lehmann

Proto. DUNE SP – Slow Control Status Giovanna Lehmann – Xavier Pons CERN 19/10/2017 1

1 - Due to the urgent request for membrane signal monitoring, the final DCS controller has been installed in the rack 2 With its supervisor application. The system includes the absolute and differential pressure signal of the inner/outer side of the membrane to observe its status. Also we have included the environmental signals: Ambient temperature Ambient humidity Atmospheric pressure Awaiting the multiplexer card to read the membrane temperatures. The system is working and archiving data. 2

Main DCS controller Rack Coldbox Rack Main DCS controller installed, PLC type (Programmable Logic Controller) SIEMENS S 7 -1515. Standard and CERN controls supported Easily integrated into SC WINCC program More information can be found https: //www. siemens. com/global/en/home/products/automation/systems/industrial/plc/simatic-s 7 -1500. html 3

2 - COLDBOX. Slow Control almost finished with the integration of the Photon Detectors MPOD Power Distribution Supervisor PC SC Controller Siemens S 7 1500 Field Interface Cold Electronics PL 506 PS Cold Electronics MPOD PS Photon Detector MPOD PS • • Working on the final SC WINCC supervisor Wiener MPOD and PL 506 integrated in the WINCC program Temperature gradient monitor repaired All cables LV, HV, Temp, Optical already installed • Tests done with the Cold Electronics: • 48 VCC from PL 506 ok, control from SC • Fans OK • Heaters OK • Interlock of the PL 506 PS linked to the fans ON. • During the tests with the Cold electronic team we found a surprise with 10 Volts power supply for the heaters. This PS, switching power supply, generated quite a lot of noise in the CE data taking. For the meanwhile it has been disconnected and it will be replaced by another type. • Also a test has to be repeated with the fans when they are ON they generated a noise a 50 k. Hz band 4

Coldbox Slow control - screen shoot Working in the integration of the Wiener MPOD’s and PL 506 power supply. Almost finished, PL 506 already commissioned and operating remotely 5

3 - COLDBOX CRYOGENICS. In addition CERN/DT has been requested to produce the hardware/software for the cryogenic control system Also a control system based on Siemens 1500 controller that executes the process Connected to the WINCC application as supervisor program 6

WEB Remote Access Only one direction https: //np 04 -online-webviewer. web. cern. ch Slow control Architecture last week CERN GPN General Purpose Network PC Supervisor + DB S 7 Driver Wiener OPC Server S 7 Driver Cryogenics Controller Process COLDBOX Cryogenics PC Supervisor + DB S 7 Driver NP 04 Controller Coldbox Controller Cold electronics MPOD minicrate Process COLDBOX SC Photon Detector MPOD minicrate Cold electronics PL 506 Process Single Phase Cryostat 7

Slow control Architecture This week Remote Access-Multiple session WEB Remote Access Only one direction https: //np 04 -online-webviewer. web. cern. ch CERN MAIN DATA SERVER (Linux) CERN GPN General Purpose Network S 7 Driver Cryogenics Controller Process Windows Wiener OPC Server Coldbox Controller Process Cold electronics MPOD minicrate COLDBOX Cryogenics COLDBOX SC NP 04 Controller Photon Detector MPOD minicrate Cold electronics PL 506 Single Phase Cryostat 8

All this work is possible thanks to the CERN EP-DT-DI team members: Sylvain Ravat Manuel Rodriguez Giulio Malaguti Enrico Gamberini Laurent Deront Marc Carrichon Bayram Dinger Gerard Crepet Xavier Pons Led by Giovanna 9
