Promet AS: Additive Manufacturing Advanced metallic 3 D printing using the latest technology of Selective Laser Melting. This method of manufacturing gives engineers the possibility to design geometries not possible with conventional machining. The next step in the Industrial Revolution Private and Confidential thenobugroup. com

Promet AS: Additive Manufacturing: Delays Private and Confidential thenobugroup. com

Promet AS : Available materials • Stainless Steel 1. 4404, 1. 4410, 1. 4542 • Tool Steel 1. 2344, 1. 2709 • Co- Cr Alloys 2. 4723 / ASTM F 75 • Super Alloys Inconel 625, 718, 939 or HX • Titanium Grade 1 - 2 • Titan Alloys Ti. Al 6 Nb 7, Ti. Al 6 V 4 • Aluminium Alloys Al. Si 12, Al. Si 10 Mg, Al. Si 7 Mg. Cu • Bronze Cu. Sn 10 Specifications: • • • spherical particles 10 µm < ø < 45 – 63 µm good flowability dryness pureness (chemistry) Private and Confidential thenobugroup. com

Promet AS : Additive Manufacturing Lightweight Complex Structures • • Saves space Saves weight Saves # of parts High accuracy Free form design Short delivery time Internal channels No welding needed Private and Confidential thenobugroup. com

Promet AS : Hybrid Manufacturing Using additive manufacturing with conventional CNC machining Rotating Nozzle for customer Energy. X • • Internal cones (not possible to machine) Rotates when pressure is applied Material: Inconel 718 Seal faces machined after 3 D print Seal face Private and Confidential Internal cone thenobugroup. com

Promet AS : Additive manufacturing/CNC Machining Rotating Nozzle: First model • 130 mm height • Long seal faces included in model • 2600 layers of 0. 05 mm Private and Confidential thenobugroup. com

Promet AS : Additive manufacturing/CNC Machining Rotating Nozzle: Final model • 80 mm height • Seal faces machined after printing • 1600 layers of 0. 05 mm • Design changed to save material/time • In additive manufacturing, complexity is FREE Private and Confidential thenobugroup. com

Promet AS : Additive manufacturing/CNC Machining Rotating Nozzle: Final part • Seal faces machined • High performance nozzle • Successful test Private and Confidential thenobugroup. com

Promet AS : Hybrid Manufacturing Using additive manufacturing with conventional CNC machining Stem Housing for customer Energy. X • • Internal channels Ø 0, 5 mm and Ø 2, 2 mm High accuracy part Material: Inconel 718 CNC machined after 3 D print Private and Confidential thenobugroup. com

Promet AS : Hybrid Manufacturing Stem Housing for customer Energy. X • • Internal channels Ø 0, 5 mm and Ø 2, 2 mm High accuracy part Material: Inconel 718 CNC machined after 3 D print Private and Confidential thenobugroup. com

Promet AS : Hybrid Manufacturing Private and Confidential thenobugroup. com

Promet AS : Hybrid Manufacturing https: //www. youtube. com/watch? v=bl 0 Od. Ss. MDok Private and Confidential thenobugroup. com

Promet AS : Hybrid Manufacturing Stem Housing for customer Energy. X • • • Heat treament performed by Ui. S Solution annealing: 2 hours, 1025 °C, water quench Age hardening: 8 hours, 775 °C, air cool Private and Confidential thenobugroup. com

Promet AS : Hybrid Manufacturing Stem Housing for customer Energy. X • • First operation additive manufactured Second operation CNC machined Private and Confidential thenobugroup. com

Private and Confidential thenobugroup. com

Promet AS : Additive manufacturing You You have the the idea design tools imagination opportunity We have the expertise We have the process 3 D laser printing – Tomorrows products, today Private and Confidential thenobugroup. com

Engineering Precision Solutions Email: tor@promet. no Private and Confidential thenobugroup. com
