Production and Applications of MultiLayer 3 D Fabrics

Production and Applications of Multi-Layer 3 D Fabrics Muhammad Nadeem Shuakat And Xungai Wang Centre for Material and Fibre Innovation, Deakin University, Geelong, VIC 3217, Australia

What are Composites? Materials formed by intimately combining two or more discrete physical phases to get superior properties of the individual constituents. Common examples are • • • Natural wood: a composite of cellulose and Lignin. Plywood: a composite of thin wooden sheets and glue. Ancient Bricks: a composite of mud and straw. Cement blocks: a composite of cement and iron wires mesh. Bath tub: a composite of Glass fibre and resin. Polymer matrix and a fibrous material as the reinforcement are the most commonly used examples of composite materials. • Most advance forms are materials used in high tech industries.

Why Composites? • • • Composites replacing metals minimizing tons of CO 2. Durable composites, need very lesser replacements. Composites are strong and light in weight. Fabric preforms have broad flexibility in design. They can be moulded in complex form and geometry. Their strength and stiffness can be tailored according to end use by changing • • • Layer to layer placement at different angles in laminated preforms. Volume fraction in 3 D textile preforms. Ratio of preform and polymer matrix.

Technical Textile Sectors Year 2005 2010 Oekotech Mobiltech Indutech Sporttech Buildtech Volume ‘ 000 tons 287 2828 2624 1153 2033 Value US$ mn 1039 26861 16687 16052 7296 Volume ‘ 000 tons 400 3338 3257 1382 2591 Value US$ mn 1389 29282 21528 19062 9325 Hometech Clothtech Meditech Agrotech Packtech Geotech 2499 1413 1928 1615 279 2990 319 7622 7014 6670 6568 5873 5329 927 2853 1656 2380 1958 340 3606 413 8778 8306 8238 8079 6857 6630 1203 Total 19681 106899 23774 127288

Textile Reinforcement Structures Laminated composite preforms Braiding Knitting Weaving 3 -D Textile composite preforms Non. Woven Braiding Knitting Weaving Non. Woven Tailored Fibre Placement

3 -D Textile composite preforms • • • Knitting Braiding Tailored Fibre Placement Thick Non-woven Weaving

Knitting In 3 D knitted structures, more than one yarn and multiple needle beds are used to get much thicker structures

Braiding Different numbers of yarns mounted on spools, cross each other at a certain angle in a circular or pre-defined path to form a circular or specific shaped preforms.

Tailored Fibre Placement Tows of carbon fibres are placed in a sheet form at various angles as required by the design of product, stitched by fine mono filament polyester.

3 D Weaving In 3 D weaving the constituent yarns cross at various angles and between different layers to form a 3 D mesh or a network like structure.

3 D Woven Textiles 3 D woven fabrics are classified into two categories • Basis of Axis • Basis of Dimensions

Basis of Axis • • • 3 - axis fabric (yarns in x, y and z axis) 5 - axis fabric (3 axes in x direction and one in each y and z) 7 - axis fabric (3 axes each in x and y directions and one in z) 9 - axis fabric (3 axes in all x, y and z directions) 13 - axis fabric (3 axes in all x, y and z directions and with four further yarns passing through eight diagonally opposite corners)

Basis of Dimensions

Production of 3 D Woven Textiles • True 3 D Fabrics • 2 D Woven Fabrics (Multi-Layer Stitched Fabrics)

True 3 D Fabrics • True 3 D Fabrics need special machines. • These machines can only produce special shaped fabrics. • Limited and special use of these machines and fabrics.

Why 2 D Multi-Layer Stitched Fabrics? • Composite manufacturing facility is negligible in Pakistan. • Very few industries using prepeg for composite products. • We don’t have any share in composite exports for specialized products. • Basic structures and materials for prepeg and composite products can be produced using existing infrastructure. • Multi-Layer Fabrics don’t require extra investment for machines. • At present, we don’t need invest a lot for true 3 D textile preforms to enter this market and taking risk for loss of revenue.

Production of 3 D Multi-Layer Fabrics can be produced on • Single Shed Machines • Multi Shed Machines Both types of machines can produce multi-layer fabrics, only difference is: • Production rate • Ease of using multiple kind of yarns in multi-shed weaving machines.

Single Shed Weaving Machines • One pick at a time • Lower production rates.

Multi-Shed Weaving Machines • Simultaneously multi-picking • Higher production rates. • Possibility of inserting different materials in different sheds.

Types of Multi-Layer Fabrics Single layer fabric Open width two layer fabric Open width three layer fabric Open width four layer fabric Tubular two layer fabric Tubular three layer fabric Tubular four layer fabric

How to develop Multi-Layer Fabrics Double Layer Tubular Fabrics • Top layer or fabric is denoted by Face (F) and bottom layer or fabric Back (B) • Further layers are denoted by middle 1 (m 1) and middle 2 (m 2). • In the resultant design of the multilayer fabric ends may be arranged in F-B-F-B order or any suitable order to get appropriate no of ends of each layer • Picks must be always arranged in F-B-F-B sequence to get resulting two-layer-tubular-fabric. • The weave repeat is completed on 4 ends x 4 picks.

Tubular fabrics without stitching • The top layer ends should always weave only with face pick and back ends with back picks. • The top layer ends should always be up on back picks. • Back end should always be down on face picks.

Tubular fabrics without stitching Rule-1: Face ends will only weave with face picks • “X” = face ends raised on face picks • “. ” = face ends down on face picks

Tubular fabrics without stitching Rule-2: Back ends will only weave with back picks • “O” = back ends raised on back picks • “. “ = back ends down on back picks

Tubular fabrics without stitching Rule-3: Face ends raised on back picks and back ends lowered on face picks. • “/” = face ends raised on back picks • “-” = back ends down on face picks

Tubular fabrics without stitching • Fabric produced in this way is tubular • Two layers each having plain weave • Each layer independent of other.

Double Layer Tubular Fabrics

Multi-Layer Stitched Fabrics

Applications of 3 D textile structures > Aerospace Industry > Automobile Industry > Construction Industry > Medical Industry > Sports Industry > Defence Industry > Others

Aerospace Industry New 787 Dreamliner developed by Boeing company • Comprises 50% composite materials with reduced weight • More savings in terms of fuel • More capacity for passengers and cargo.

Automobile Industry By using composite materials: • 30% weight reduction without compromising on strength. • Carbon fibre reinforced plastics (CFRP) are 50% lighter than steel. • CFRP gives at least same strength as steel. • Gives added extra miles to every litre of fuel.

Construction Industry Composites are ideal for use in the construction industry because of • • • Their dimensional stability Strength with reduced weight Good impact resistance Low flammability Low maintenance Good design flexibility Composites are used in the form of • Panels • Pillars • Ceiling • Floor Tiles

Composite material in building • "INNOTEX" in Aachen Melaten is the first building fully developed from textile reinforced concrete. • RWTH Aachen University in collaboration with Shell developed this building. • This is thermally insulated and self supporting building • Saving of 420 tons of CO 2 gas

Medical Industry • Being light in weight and robust, fibre reinforced composite materials are used in medical applications. • Combination of glass & carbon fibre allows flexibility to minimize breakage in splint supports. • The energy storing property of carbon fibre makes it an ideal material for this dynamic ankle foot orthosis.

Sports Industry • Composite materials are replacing conventional wooden materials to make sticks and rackets lighter • Giving sportsmen more freedom of movement with added strength. • Sport bicycle manufacturers are using composites to reduce weight. • Giving user more freedom in terms of speed with added safety.

Defence Industry • Composite have become an integral part of defence • Use of composites made Hummvee lighter & allowed higher payloads. • Safe Passage having concrete composite. • Honey comb based tubeless tyres. • Usage of composites increased from 2% to 24% of total weight from F 15 to F 22. • By using composite materials in fighter planes, more flight time with the same amount of fuel was achieved. • The reduced weight allows more ammunition on the plane, with the added advantage of better and quick manoeuvring

Defence Industry

Defence Industry

Conclusion • Textile composites are better source of metal replacement reducing tons of CO 2 emission preserving natural environment. • Textile composites can be used in a variety of products and are simplest solution to enter technical textile export markets. • 3 D textile preforms produced by multi-layer stitched fabrics can be produced on existing infra structure without any further investment. • The multi-layer stitched preforms can be developed into more complex shapes and geometries by using jacquards as lifting mechanisms. • Multi-shed will give more diverse effect in weft with increased production. • Rapier weft insertion gives ease of picking almost any thing can be used. • A combination of jacquard lifting, multi-shed and rapier can give more flexibility in producing complex shapes and geometries with more ease.
