Power over Ethernet (Po. E) Solution
Full Range of Po. E Products u Power Sourcing Equipment 15 W → 30 W → 60 W u Powered Device 2
Intelligent Po. E Management u Po. E System Management u Po. E Port Configuration ü Po. E Budget Overloading Protection ü Po. E Temperature Threshold ü Po. E Power Usage Threshold ü Power Feeding Status Monitoring ü 802. 3 af mode control ü Power feeding On/Off/schedulable and priority ü ü ü configuration Power Limit function for Po. E power management Auto detect powered device and consumption levels Classify connected powered devices u PD (Powered Device) Alive Check u Schedule Po. E Power Recycle 3
Po. E Schedule u Per Port / Per Profile / Per day, Schedulable Po. E ON/OFF Control Per Hour & Min Setting Daily Work 4 Profiles Off-Business Hours Per Week Day Setting Daily Work Power Consumption Off-Business Power Saving 4
Po. E PD Alive Check …… PD Status Good !! Po. E Switch Alarm Notification PD Alive !! 5
Schedule Po. E Power Recycle Allows each of the connected Po. E powered device to reboot at a specified time each week Buffer Utilization: 30% 24: 00 0: 00 ~ 24: 000: 00 Mon Tue Wed Thu ~ 24: 00 Fri Buffer Utilization: Buffer Utilization: Po. E Power Recycles 45% 60% 75% 10% 90% each Friday at midnight 0: 00 ~ 24: 00 Sat Po. E On ~ Po. E On Sun 0: 00 Po. E Off 24: 00 Po. E On ~ Po. E On 0: 00 Reduce the chance of powered device crash resulting from buffer overflow Po. E On ü Po. E On u Buffer Utilization: 15% 6
Product Features Po. E Switch
Po. E Switch Overview u IEEE 802. 3 at/af compliant u Full Po. E port: 8, 16, 24, 48 u Po. E budget from 55 W to 720 W u Intelligent Po. E Management u Fiber-Optical Link Capability u Home, SOHO, SMB, Enterprise to Industrial grade applications 48 -Port Po. E+ 24 -Port Po. E+ 16 -Port Po. E+ 8
48 -Port Managed Po. E Switch u 30 W IEEE 802. 3 at Po. E support u Total 720 W Po. E budget u Layer 2 /4 IPv 6 Managed Gigabit Switch u 4 SFP slots, flexible for Gigabit Fiber-Optic network extension u SSH / SSL Secure Management u Integrate Security and Qo. S for Po. E PD operating u Po. E Power management ü ü WGSW-48040 HP Po. E Port power limit / Total limit to ensure stable system operating Monitor power usage, current usage, power consumption on Powered Devices 9
24 -Port Managed Po. E Switch u 30 W IEEE 802. 3 at Po. E support u Total 360 W Po. E budget u Layer 2 /4 IPv 6 Stackable / Gigabit Switch u 4 SFP slots, flexible for Gigabit Fiber-Optic network extension u SSH / SSL Secure Management u 2 HDMI-Like 5 Gbps Stacking interfaces ü ü u SGSW-24040 HP Up to 20 Gbps stacking bus, Full-duplex Ring topology Single IP management ü Up to 384 Gigabit PDs managed via one IP address u Integrate Security and Qo. S for Po. E PD operating u Po. E Power management ü ü Po. E Port power limit / Total limit to ensure stable system operating Monitor power usage, current usage, power consumption on Powered Devices 10
SGSW-24040 HP Application Gigabit Data speed + Power Single IP Management 11
Stackable Gigabit Po. E Switch Family SGSW-24040 P 4 SGSW-24040 HP 10/1000 T 24 24 24 1000 SX/LX 4 4 4 Compatible Model Feature Interface 100 FX Stacking Standard Po. E 2 x 5 Gbps / HDMI-Like 802. 3 af 802. 3 at, 802. 3 af Po. E Output 48 V / 15. 4 W 52 V / 30 W Po. E Budget 220 W 380 W 360 W No. of Class 2 24 24 24 No. of Class 3 14 24 24 No. of Class 4 -- -- 12 Stack Capability Hardware Stack, up to 16 units, 384 ports 12
Industrial High Power Po. E Switch IGS-10020 HPT u IPv 6 IP Address / NTP / DNS management u Po. E Power up to 30. 8 Watts for each Po. E ports u Auto detect powered device (PD) u VLAN, Spanning Tree Protocol u ERPS (Ethernet Ring Protection Switching) u IEEE 802. 1 x Port-Based / MAC-Based network access authentication 13
Industrial Po. E Fiber Switch IGS-624 HPT u Fiber-Optical Link Capability u 802. 3 af/at Po. E injector u 48 V DC to 52 V DC Po. E+ power boost u High Power Budget for Po. E Extension u Intelligent LED Indicator for Real-time Po. E Usage u Redundant power system u -40~75 o. C Operating Temperature u IP 30 Rugged Case IGS-624 HPT 14
Industrial Po. E Fiber Switch Application 240 km 15
Product Features Po. E Injector Hub
Po. E Injector Hub Family IEEE 802. 3 at (Up to 30. 8 W) HPOE-2400 G Gigabit Ethernet Fast Ethernet (24 -Port Gigabit Po. E) HPOE-460 (4 -Port Gigabit Po. E) IEEE 802. 3 af (Up to 15. 4 W) POE-2400 G (24 -Port Gigabit Po. E) HPOE-1200 G (12 -Port Gigabit Po. E) POE-2400 (24 -Port Po. E) POE-2400 P 4 (24 -Port Po. E, 400 Watts full power) POE-400 (4 -Port Po. E) POE-1200 (12 -Port Po. E) POE-1200 P 2 (12 -Port Po. E, 200 Watts full power) 17
802. 3 at Po. E Injector Hub u Gigabit Mid-Span Power over Ethernet Injector Hub ü ü ü 24 ports on the upper stack are data and power ports 24 ports on the lower stack are data ports 1 -Port 10/100 Mbps management port u Complies with IEEE 802. 3 at 52 V DC per port maximum 30. 8 watts u 720 -watt Po. E power budget u Po. E Power Schedule to save power u Automatically detects powered device and consumption level u Remote Po. E Power management by WEB u Po. E per port power feeding limit and priority u Temperature over protection to prevent device damage u SNMP and SNMP trap u 19 -inch rack mountable; 1 U height HPOE-2400 G 18
HPOE-2400 G Application IEEE 802. 3 at 30 watts IEEE 802. 3 af 15. 4 watts 19
Product Features Po. E Injector / Splitter
Ultra Po. E Injector / Splitter POE-171 POE-173 POE-171 S 60 W Po. E Injector 60 W Po. E Splitter u 56 V DC power input (Po. E-171) u 50 V DC power input (Po. E-173) u 12 V/19 V/24 V DC output (POE-171 S) u 0 to 50 o. C operating temperature u Compact size metal case protection u IEEE 802. 3 at / 802. 3 af End-span and Mid-span mode u Supports 15. 4 W, 30 W or 60 W IEEE 802. 3 at/af standard Po. E device u Plug and play u Remote power feeding up to 100 meters 21
Ultra Po. E Injector / Splitter Ultra Po. E provides Double Power, better than conventional 802. 3 at Po. E 22
30 W Po. E Injector POE-163 POE-164 Gigabit 30 W Po. E Injector u IEEE 802. 3 at / 802. 3 af Mid-span PSE u Supports 15. 4 W or 30 W IEEE 802. 3 at/af standard Po. E device u 100~240 V AC power input, 53 V DC Po. E output u 0 to 50 o. C operating temperature u Compact size metal case protection u 1 Ethernet copper port with built-in Po. E injector u Plug and play u Remote power feeding up to 100 meters 23
Product Features Po. E Converter / Extender
Passive Po. E Converter u IEEE 802. 3 af/at Po. E compliant u Passive Po. E Output u 1 DC 12 V/19 V/24 V DIP switch u -40 ~ 75 o. C operating temperature POE-165 S 12/19/24 V DC 25
Po. E over Coaxial Extender u Advantages of Po. E over Coaxial ü ü ü No need to find power outlet in every location Saves time and money Provides power to the receiver up to 1000 m in distance VC-203 PR Receiver VC-203 PT Transmitter Po. E over Coaxial RG 6 Coaxial Cable 26
Po. E over Coaxial Extender Model VC-203 PT VC-203 PR VC-205 PT VC-205 PR Transmitter Receiver 1 x 10/100 Base-TX (Po. E IN) 1 x 10/100 Base-TX (Po. E OUT) Power/Data Transmitter Power/Data Receiver -- -- -40 to 75 o. C Item Po. E over Coax. Extender Ethernet Port BNC Connector DIP Switch 2 -Position DIP Switch • CO or CPE mode • Band plan: Asymmetric or Symmetric (Default: CPE, Asymmetric) -- 2 -Position DIP Switch (Rear) • Po. E out or DC out • 12 V DC / 24 V DC output voltage (Default: Po. E Out, 12 V DC) Operating Temperature -40 to 75 o. C 27
Po. E Extender u Complies with IEEE 802. 3 at / 802. 3 af Po. E u Extends the range of Po. E an additional 100 meters (328 ft. ) u Automatically detects and protects Po. E equipments from being damaged by incorrect installation u 4 units, daisy-chain installation with 500 meters distance support u Plug and Play u -10~60 o. C operating temperature POE-E 201 28
POE-E 201 Multi-Unit Installation 500 m 29
Industrial Media Converter IGTP-80 x series ü LC Fiber Interface IGTP-805 AT ü Multi / Single Mode SFP module ü Distance up to 120 km max. (Vary on SFP module, 100/1000 dual mode support) IGTP-802 TS IGTP-802 T ü SC Fiber Interface with Single-mode ü Distance up to 10 km ü SC Fiber Interface with Multi-mode ü Distance up to 220 m / 550 m 30
Industrial Media Converter IGTP-80 x series u IEEE 802. 3 at / 802. 3 af standard u Po. E Power up to 30 Watts for Po. E port u 24 V / 48 V DC redundant power u DC 52 V power over RJ-45 Ethernet Cable to devices with Ethernet port u Real-Time Power Fault Relay Alarm u -40 to 75 o. C operating temperature u IP 30 metal case / DIN-Rail and Wall-mountable design u 6 KV DC EFT protection for power line / 6 KV DC Ethernet ESD protection 31
Product Features Solar Po. E Switch
33
Features BSP-300 u Battery charging and discharging The BSP-300 empowers the connected Po. E devices in the day and night time from charging and discharging. Charging Discharging 34 / 34 15
BSP-300 Application BSP-300 Site: Desert in Chile 35 35/45
BSP-300 Application 36 36/45
POE Tester u Quickly tests RJ-45 outlet for Power over Ethernet existence u Two LEDs indicate the types of PSE (power source equipment) ü ü ü End-span Po. E switch Mid-span Po. E injector / injector hub 4 -pair, 60 -watt ultra Po. E injector u IEEE 802. 3 at/af Po. E compliant u Compact size, Plug and Play design 37
u View PLANET Po. E solution online 38
