# Pie Charts Reading Higher GCSE Questions AQA These

- Slides: 11

Pie Charts – Reading – Higher – GCSE Questions – AQA These questions are the same format as previous GCSE exams. COPY means they use the exact same numbers as the original GCSE question. Otherwise, they are clone questions using different numbers. The worksheets are provided in 2 sizes.

Printing To print handouts from slides Select the slide from the left. Then click: File > Print > ‘Print Current Slide’ To print multiple slides Click on a section title to highlight all those slides, or press ‘Ctrl’ at the same time as selecting slides to highlight more than one. Then click: File > Print > ‘Print Selection’ To print double-sided handouts Highlight both slides before using ‘Print Selection’. Choose ‘Print on Both Sides’ and ‘Flip on Short Edge’.

AQA Higher: November 2017 Paper 1, Q 11 1 AQA Higher: November 2017 Paper 1, Q 11 The four candidates in an election were A, B, C and D. 1 The pie chart shows the proportion of votes for each candidate. Not drawn accurately Proportion of votes A D The four candidates in an election were A, B, C and D. Not drawn accurately Proportion of votes A D B B C C Work out the probability that a person who voted, chosen at random, voted for D. Answer [4 marks]

AQA Higher: June 2017 Paper 2, Q 10 1 AQA Higher: June 2017 Paper 2, Q 10 The pie chart shows the total number of lawyers in a city. 1 The pie chart shows the total number of lawyers in a city. Lawyers Women 260° Men There are 4480 more male lawyers than female lawyers. Work out the total number of lawyers. Answer There are 4480 more male lawyers than female lawyers. [3 marks] Work out the total number of lawyers. Answer [3 marks]

AQA Higher: November 2017 Paper 1, Q 11 1 The four candidates in an election were A, B, C and D. The pie chart shows the proportion of votes for each candidate. Not drawn accurately Proportion of votes A D B C Work out the probability that a person who voted, chosen at random, voted for D. Answer [4 marks]

AQA Higher: June 2017 Paper 2, Q 10 1 The pie chart shows the total number of lawyers in a city. Lawyers Women 260° Men There are 4480 more male lawyers than female lawyers. Work out the total number of lawyers. Answer [3 marks]

AQA Higher: November 2017 Paper 1, Q 11 1 The four candidates in an election were A, B, C and D. The pie chart shows the proportion of votes for each candidate. Not drawn accurately Proportion of votes A D B C Work out the probability that a person who voted, chosen at random, voted for D. Answer [4 marks]

AQA Higher: June 2017 Paper 2, Q 10 1 The pie chart shows the total number of lawyers in a city. Lawyers Women 160° 100° 260° Men 100° There are 4480 more male lawyers than female lawyers. Work out the total number of lawyers. [3 marks] 160° = 4480 lawyers Answer 10, 080

Questions? Comments? Suggestions? …or have you found a mistake!? Any feedback would be appreciated . Please feel free to email: [email protected] co. uk
