Physics 101: Lecture 07 Constant Acceleration and Relative Velocity Physics 101: Lecture 7, Pg 1

Relative Velocity l Sometimes your velocity is known relative to a reference frame that is moving relative to the earth. èExample 1: A person moving relative to a train, which is moving relative to the ground. èExample 2: a plane moving relative to air, which is then moving relative to the ground. l These velocities are related by vector addition: » vac is the velocity of the object relative to the ground » vab is the velocity of the object relative to a moving reference frame » vbc is the velocity of the moving reference frame relative to the ground Physics 101: Lecture 7, Pg 2 32

Relative Velocity You are on a train traveling 40 mph North. If you walk 5 mph toward the front of the train, what is your speed relative to the ground? A) 45 mph 40 45 B) 40 mph C) 35 mph 5 Physics 101: Lecture 7, Pg 3 25

Relative Velocity You are on a train traveling 40 mph North. If you walk 5 mph toward the rear of the train, what is your speed relative to the ground? A) 45 mph 40 35 B) 40 mph C) 35 mph 5 Physics 101: Lecture 7, Pg 4 27

Relative Velocity You are on a train traveling 40 mph North. If you walk 5 mph sideways across the car, what is your speed relative to the ground? A) < 40 mph B) 40 mph C) >40 mph N + 5 mph W = 5 40 Physics 101: Lecture 7, Pg 5 30

Example: airplane • An airplane needs to fly due south to reach it’s destination, but there is a wind blowing from the east. Will this increase, decrease or have no effect on the travel time? vp= 50 m/s v. T vw= 20 m/s Physics 101: Lecture 7, Pg 6

y Example x Three swimmers can swim equally fast relative to the water. They have a race to see who can swim across a river in the least time. Relative to the water, Beth (B) swims perpendicular to the flow, Ann (A) swims upstream, and Carly (C) swims downstream. Which swimmer wins the race? A) Ann B) Beth C) Carly correct A B C Physics 101: Lecture 7, Pg 7 39

Tractor Demo 1 Which direction should I point the tractor to get it across the table fastest? A) 30 degrees left B) Straight across C) 30 degrees right 1 2 3 Physics 101: Lecture 7, Pg 9 34

Tractor Demo (moving table) l Which direction should I point the tractor to get it across the table fastest? A) 30 degrees left B) Straight across C) 30 degrees right 1 2 3 Physics 101: Lecture 7, Pg 10 37

y Example x If the width of the river is 50 m and Beth can swim at 3 m/s, how long does it take her to get across? If the river is flowing at 2 m/s, How far downstream is she swept? 50 m A B C 2 m/s Physics 101: Lecture 7, Pg 11 39

y Swimmer Example x What angle should Ann take to get directly to the other side if she can swim 3 mph relative to the water, and the river is flowing at 2 mph? How long does it take her to get across? q A B C 2 m/s Physics 101: Lecture 7, Pg 12 48

Summary of Concepts l. X and Y directions are Independent! èPosition, velocity and acceleration are vectors l. F = m a applies in both x and y direction l Relative Motion (Add vector components) Physics 101: Lecture 7, Pg 13
