PBX vs Centrex Garry Meadows Steve Klesper Tom

PBX vs Centrex Garry Meadows Steve Klesper Tom Ondick Aaron Hurt Ron Pridemore Tim Wade Source: PBX vs. Centrex Comparison - Gartner - 10/14/02

Considerations u u u u Introduction Definition of PBX Definition of Centrex Cost Responsibility / Control Flexibility Support Security Drawbacks Advantages Small Company Options Medium Company Options Large Company Options Summary Bibliography

PBX Definition Newton, Harry “Newton’s Telecom Dictionary” CMP Books, Feb 2002: 556 - Private Branch Exchange is a privately owned version of the phone switches used in central office. This allows for the user to have more features on hand while allowing the exact needs of the business to be designed when the PBX is purchased. IP PBXs today handle voice and data traffic simultaneously enabling users to transport both over the same pipe. This provides large cost savings when implementing VOIP solutions. Even though the PBX is a small switch, it must access the CO to connect to the PSTN to make external calls. There are several advantages and drawbacks to the PBX which will be covered in more detail later in this presentation.

Centrex Definition Newton, Harry “Newton’s Telecom Dictionary” CMP Books, Feb 2002: 146 - Centrex is a business telephone solution offered by the local telephone company from the CO. Centrex adds several custom calling features that businesses require but still maintain the equipment and the floor space. Centrex systems are generally easier to grow that a PBX as the phone company is responsible for ordering new equipment and dealing with installation. This frees the business from having to have personnel on staff to do provisioning and maintenance for a complicated piece of equipment. Centrex services today do allow users to make changes to their individual lines remotely as well as receive call detail records which were previously only available on PBX systems. Two large drawbacks are that Centrex services are cable intensive and the company is at the mercy of the CO as to the total number of lines that are physically available in the CO.

Cost must be considered in several categories u Acquisition – High initial cost for PBX, little for Centrex but a recurring monthly charge is applied u Network Access – PBX requires fewer lines; Centex requires a line for each extension u Maintenance – Dependent upon PBX; Centrex MAC’s cost are substantial u Facilities – PBX owner pays the bill; Telco does for Centrex u Security – Telco not as susceptible to attack; PBX trained staff needed u Predictability – Hardware and software changes in PBX; Centrex rates subject to regulation (read contract)

Responsibility / Control PBX Controlled entirely by purchasing business u Limited only by system constraints and financial limitations of the business u Centrex Controlled by the Telco u Capabilities designed to meet the needs of major market demand u Questionable flexibility for smaller organizations u

Flexibility PBX Hundreds of features and software packages u Managed easily with no service contracts required u Finite limits based on capital expenditure u Centrex Limited features in comparison to PBX u Real time MAC’s can not be performed and may be very expensive u Special features usually limited to large organizations u

Support PBX u u u Dependent on availability of trained staff and vendor technicians Technician turnover rate very high System failure may be expensive and labor intensive Centrex u u Large, well trained staff Minimal downside Monitored constantly with spare parts on hand. Included (usually) in leasing agreement with little to no cost to the user

Security PBX DISA Trunks u Remote Maintenance Ports u IVR u Traditional PBX systems more vulnerable than Centrex to outside attacks u Centrex Responsibility of Telco u Taken very seriously u Assumes Centrex user has taken steps to avoid credit card abuse u

Drawbacks PBX u u u Possible system crash Floor space and technical knowledge required Large amount of money up front CPE equipment (in certain cases) must be purchased from the same vendor Technology could become obsolete making it difficult to find parts and service Centrex u u u Every extension requires its own copper line Call made within office must first go to CO to be routed back to office Reconfiguration of the switch must be done by CO Features fewer than that of PBX Tax savings by leasing a Centex lines are nonexistent

Advantages u u u u PBX Tax benefits for purchasing PBX can be seen Calls made internally are switched at the PBX; requires less outside lines Extensions possible: 9999 Vast service combinations may be purchased Configuration updates accomplished by trained staff Five digit in house dialing Multiple PBXs may be connected to create large virtual PBX u u u u Centrex Implementation fast and inexpensive Service is not required by the customer Features similar to many on PBX Limitless number of outside lines available Upgrades accomplished without end users knowledge Floor space and power requirements met by Telco Security responsibility of Telco Reliability generally higher

Small Company Needs A company with ten people or less will likely not want to spend excess money on a large system, nor want to hire a technical person to operate the system. Therefore, a Centrex system would be the best solution. Purchasing 10 lines at an approximate cost of $20 -$25 per line would be significantly cheaper than a PBX system. Telephone sets would be the only CPE required.

Medium Company Needs In this area, numbers and future growth are very important. Leasing 100 Centrex lines at $25 per month would be reasonable compared to buying a PBX. However, if the company is fairly young and plans to grow rather quickly, a PBX would be the best solution. This would allow the company to add extensions without wasting time or money waiting for Centrex services from the phone company. Generally, a company with 100 people will have its own IT personnel which could easily be trained to operate and maintain a PBX system. Nevertheless, there are many variables that could cause a medium sized company to lean one way or the other when it comes to Centrex or PBX.

Large Company Needs Large companies usually have requirements for a PBX system. Generally speaking, 90% of calls are made internally. This means that only 10% of the number of calls made go to the CO; therefore, out of 1000 lines in a PBX only 100 would need to connect to the CO. This presents a large savings over a Centrex which requires a minimum of one line per station. Companies of this size also have large turnover which would lead to high costs if maintenance was left to CO. The PBX also offers access to internal voice mail as well as call transfer, conference call and speed dial features. If employees are not located in the same building, multiple PBXs may be tied together to create a virtual PBX allowing for 5 digit dialing between buildings.

Summary The age old battle of Centrex Vs PBX is not a cut and dry issue. Many variables such as future growth, cost, and ability to maintain systems needs to be taken into account. Both systems have distinct advantages and disadvantages. Therefore, overall requirements drive the final decision. Today PBXs are getting smaller and cheaper, while Centrex services are being added that are comparable to that of the PBX. Companies need to meet with appropriate vendors to get estimates before making their final decision. Future requirements for voice over IP (VOIP) and video calls are being met by IP PBXs and emerging Centrex services. IP PBXs will allow the company to migrate slowly from TDM to IP with less cost to the company.

Bibliography Newton, Harry “Newton’s Telecom Dictionary” CMP Books, Feb 2002: 146, 556 http: //munshi. sonoma. edu/s 96/bu 420/pbx. html Bates, Regis J & Gregory, Donald W “Voice and Data Communications Handbook” 4 th edition, Osborne/Mc. Graw Hill, Jan 2001: 175 -188 Cole, Marion “Introduction to Telecommunications” 2 nd Edition, Prentice Hall, Jan 2002 131 -132 http: //www. nwfusion. com/columnist/2002/1014 edit. html, Dix, John Gloves come off in IP Centrex vs IP PBX
