Paul Collinge Senior Premier Field Engineer Stage 1
- Slides: 48
Paul Collinge Senior Premier Field Engineer
Stage 1 Performance troubleshooting engineer not required 1. • • • 2. • • 3. • 4. •
Stage 2 Performance troubleshooting engineer is required 5. 6. 7. 8.
• • Latency/Round Trip Time • TCP Window Scaling • GEO DNS issues • • Routing and Peering TCP Idle time settings
Measuring RTT from the Proxy to Office 365 • • •
Internal RTT (ms) External RTT (ms) Total RTT to O 365 54. 88 346 400. 88 Here we can see clearly, the poor RTT is outside the customer’s environment, on the ISP link to Office 365. If this RTT is unexpected, the customer can engage their ISP to investigate.
• • http: //www. verizonenterprise. com/about/network/latency/
TCP Window Scaling enabled? Maximum TCP receive buffer (Bytes) No 65535 (64 k) Yes 1073725440 (1 gb)
Impact of TCP Window Scaling Presuming a 1000 Mbps link here is the maximum throughput we can get with TCP window scaling disabled and then with it enabled Round Trip Time (ms) Maximum Throughput (Mbit/sec) without scaling Maximum Throughput (Mbit/sec) with scaling 300 1. 71 447. 36 200 2. 56 655. 32 100 5. 12 1310. 64 50 10. 24 2684. 16 25 20. 48 5368. 32 10 51. 20 13420. 80 5 102. 40 26841. 60 1 512. 00 134208. 00
Impact of enabling this setting Before & After correctly enabling TCP Window Scaling- Download a 14 mb PDF 600. 0 507. 0 Seconds 400. 0 300. 0 200. 0 100. 0 21. 0 0. 0 Australia Proxy (Incorrect Windows Scaling settings) Australia Proxy TCP Window Scaling enabled Office 365 Australia PC Australian PC downloading a large PDF before and after correctly setting the TCP Window Scaling on the Proxy
Internet egress point
• This trace is from the UK • Look for hosts called NTWK. MSN. NET which is the Microsoft global network • In the example we hit the MSFT network in 10 ms • Then traverse the USA via • ASH-Virginia • ATB-Georgia • LAX-Los Angeles • Then to APAC via • TYA - Tokyo • SIN-Singapore Tracing route to OUTLOOK-APACNORTH. OFFICE 365. COM [132. 245. 65. 146] over a maximum of 30 hops: 1 1 ms Sky. Router. Home [192. 168. 0. 1] 3 11 ms ip-89 -200 -132 -100. ov. easynet. net [89. 200. 132. 100] 4 10 ms igbtmdistc 7503. msft. net [195. 66. 236. 140] 5 84 ms xe-0 -3 -2 -0. ash-96 cbe-1 a. ntwk. msn. net [207. 46. 45. 227] 6 96 ms 95 ms ae 2 -0. atb-96 cbe-1 a. ntwk. msn. net [207. 46. 33. 228] 9 140 ms 142 ms 140 ms 191. 234. 83. 150 10 142 ms 138 ms 139 ms ae 11 -0. lax-96 cbe-1 b. ntwk. msn. net [207. 46. 47. 11] 11 256 ms ae 2 -0. tya-96 cbe-1 a. ntwk. msn. net [207. 46. 149] 12 265 ms ae 0 -0. tya-96 cbe-1 b. ntwk. msn. net [204. 152. 140. 181] 13 288 ms 290 ms 292 ms xe-7 -0 -1 -0. sin-96 cbe-1 a. ntwk. msn. net [207. 46. 38. 252] 14 290 ms 288 ms 287 ms xe-5 -3 -1 -0. sin-96 cbe-1 b. ntwk. msn. net [207. 46. 41. 39] 15 279 ms ae 1 -0. sg 2 -96 cbe-1 a. ntwk. msn. net [191. 234. 80. 90] 18 280 ms 279 ms 132. 245. 65. 146
TCP Idle time settings • •
• • Initial connect: 14: 12: 24. 6483418 19. 0046514 0. 0003578 iexplore. exe 10. 200. 30. 40 btssig-msl. bcp-01. Contoso. sig HTTP: Request, CONNECT Contosoemeamicrosoftonlinecom-3. sharepoint. emea. microsoftonline. com: 443 , Using NTLM Authorization NTLM NEGOTIATE MESSAGE Proxy Response: 14: 12: 24. 6876389 19. 0439485 0. 0283000 iexplore. exe btssig-msl. bcp-01. Contoso. sig 10. 200. 30. 40 HTTP: Response, HTTP/1. 1, Status: Proxy authentication required, URL: Contosoemeamicrosoftonlinecom-3. sharepoint. emea. microsoftonline. com: 443 NTLM CHALLENGE MESSAGE We then send the request again, this time with NTLM authentication for the proxy: Contoso Office 365 Network Review Second request with NTLM Auth: 14: 12: 24. 6883198 19. 0446294 0. 0004838 iexplore. exe 10. 200. 30. 40 btssig-msl. bcp-01. Contoso. sig HTTP: Request, CONNECT Contosoemeamicrosoftonlinecom-3. sharepoint. emea. microsoftonline. com: 443 , Using NTLM Authorization NTLM AUTHENTICATE MESSAGE Version: NTLM v 2, Domain: headoffdom, User: paul. collinge, Workstation: W 7 TEST 20 200 OK response from proxy but this takes 3 seconds. 14: 12: 27. 7859643 22. 1422739 3. 0878394 iexplore. exe btssig-msl. bcp-01. Contoso. sig 10. 200. 30. 40 HTTP: Response, HTTP/1. 1,
• http: //support. microsoft. com/kb/2637629 • • •
DNS Performance • •
• • • Multiple things in the 3 way handshake to the proxy/Office 365 should be checked to ensure they are optimal Check the TCP options in both the syn and the syn ack TCPOptions: - Max. Segment. Size: 1 type: Maximum Segment Size. 2(0 x 2) Option. Length: 4 (0 x 4) Max. Segment. Size: 1460 (0 x 5 B 4) //Max is 1460 bytes on Ethernet, shouldn’t be much lower than this. If it is, it will cause poor performance + No. Option: + Windows. Scale. Factor: Shift. Count: 8 + No. Option: + SACKPermitted: //This should be enabled as It allows us to better handle dropped packets
http: //blogs. technet. com/b/onthewire/ Network Analysis tool http: //msdn. microsoft. com/en-us/library/dn 850362. aspx
http: //channel 9. msdn. com/Events/Tech. Ed www. microsoft. com/learning http: //microsoft. com/technet http: //developer. microsoft. com
