Passive UHF in License Plates Enables CostEffective Secure
Passive UHF in License Plates Enables Cost-Effective, Secure and Reliable Electronic Toll Collection Регистрационные знаки с пассивной RFID-меткой как инструмент доступной, безопасной и надежной системы сбора оплаты за проезд ITS ON ROAD III. International Conference «Role and Place of Intelligent Transport Systems in Toll Highway Network of the Russian Federation. Current Development Trends» 7 -9 September 2016
2 ITS on Road | Passive UHF in License Plates Enables Cost-Effective, Secure and Reliable Electronic Toll Collection Content Содержание 1 IDe. PLATE® – RFID-Based License Plate | Номерной знак с RFID-меткой 2 Advantages of IDe. PLATE® for Tolling | Преимущества IDe. PLATE® для оплаты проезда 3 Successful Project in Kazan, Tartastan | Успешный проект в Казани, Татарстан 4 Benefits of IDe. PLATE® | Преимущества IDe. PLATE®
3 ITS on Road | Passive UHF in License Plates Enables Cost-Effective, Secure and Reliable Electronic Toll Collection IDe. PLATE® – The RFID-Based License Plate IDe. PLATE® – номерной знак с RFID-меткой § Passive UHF RFID transponder as an integral part of trusted aluminium license plates § Unique factory-locked ID number on every transponder deployed in the market § AES Security with two 128 -bit keys for cryptographic authentication and encryption § Untraceable function to hide portions of data, restrict access privileges for privacy protection § Top notch RF performance: 15 m range on a license plate § Пассивный UHF RFID транспондер в качестве составной части номерного знака § Уникальный, серийный номер в каждой метке, который «прошивается» на заводе-изготовителе § Реализован AES с 128 -битным ключом для криптозащиты и аутентификации § Для защиты данных реализована функция управления правами доступа к областям памяти § Гарантированное считывание в потоке на расстоянии до 15 метров Meets requirements of important standards for license plates § Russian GOST R 50577 -93, § German DIN 74069 and § International ISO 7591 Соответствует требованиям стандартов для номерных знаков § России ГОСТ Р 50577 -93, § Немецкий DIN 74069 и § Международный ISO 7591
5 ITS on Road | Passive UHF in License Plates Enables Cost-Effective, Secure and Reliable Electronic Toll Collection Advantages over Active RFID (DSRC) Преимущества по сравнению с активной RFID (DSRC) Battery-free / Extended Lifetime Batteries of active DSRC transponders have fast discharging at low temperatures and has to be changed from time to time Без элемента питания / Более долгий срок службы Батареи в активных транспондерах быстро разряжаются на морозе и требуют замены время от времени Lightweight and Comfortable RFID in License Plates are more or less invisible for the user, whereas active DSRC transponders on windscreens are bulkier and can fall off. Легкий и удобный Метка в номерном знаке незаметна для водителя, тогда как активные транспондеры занимают место под стеклом и могут выпасть из крепления Cost-Effective Active DSRC transponders are quite accurate, but the initial investment is high, since they are relatively complex devices that tend to be more expensive. Менее затратный Активные транспондеры DSRC достаточно точные, но в виду того, что это относительно сложное устройство, установка связана с существенными затратами
6 ITS on Road | Passive UHF in License Plates Enables Cost-Effective, Secure and Reliable Electronic Toll Collection Latest IDe. PLATE® Developments Последние достижения в разработке IDe. Plate World-Leading Long Range RFID Performance Top notch RF performance of 15 m read range (and more) on a license plate Cutting-Edge Security Implementation License plate authentication and privacy protection via untraceable command on basis of two 128 -bit AES crypto keys Multi-Lane Free Flow Traffic Whether a Toll Plaza is installed or a free flow solution is preferred, RFID-based license plates always meets the requirements and can be read even at 260 km/h. Лучшее в мире считывание на дистанции Гарантированное считывание метки в знаке на дистанции 15 и более метров Передовая защита данных Считывание знака и защита данных через неклонируемые команды на основе двух 128 битных ключей AES Считывание при многополосном, свободном транспортном потоке Не зависимо от того установлена ли площадка для сбора оплаты или выбрана модель свободного транспортного потока, номерные знаки с RFID-меткой могут быть считаны на скоростях до 260 км/ч
7 ITS on Road | Passive UHF in License Plates Enables Cost-Effective, Secure and Reliable Electronic Toll Collection Successful Project in Kazan, Tartastan Успешный проект в Казань, Татарстан § Insufficient read rate of existing camera system, depending on season, the read rate is not even 50 % § From June 2014 to February 2015 a total amount of 729 public buses had been equipped with two RFID-based License Plates § Test results show a RFID-based identification rate of 97, 4 % § In the meantime far-reaching improvements on RFID-Software and Hardware were achieved § Идентификация ТС оптическими системами в зависимости от погоды составляла около 50% § С июня 2014 по февраль 2015 в общей сложности 729 рейсовых автобусов были оснащены комплектом номерных знаков с RFID-метками § Результаты теста показали вероятность идентификации 97, 4% § Со времени эксперимента технология была еще более усовершенствована
8 ITS on Road | Passive UHF in License Plates Enables Cost-Effective, Secure and Reliable Electronic Toll Collection Additional Benefits of RFID in Aluminium License Plates Дополнительные преимущества алюминиевого знака с RFID-меткой Extended Security of Alumium License Plates IDe. PLATE combines all the security features and positive attributes of widespread and trusted aluminium license plates with contactless RF identification as well as authentication of license plates as a government issued document. Повышенная защищенность от подделки алюминиевого знака IDe. Plate сочетает элементы защиты широко распространенных алюминиевых знаков с радиочастотной идентификацией и аутентификацией знаков, как государственного документа Wide Customer Layer Compulsary use of license plates offers, when using IDe. PLATEs, offers a large potential customer base for electronic toll collection. Широкий диапазон пользователей Дополнительный функционал номерного знака в случае использования IDe. Plate позволяет сразу получить большую базу пользователей Additional Use Cases Once widely deployed easy extension to other applications such as vehicle registration, law-enforcement, speed control, running red lights, expired registration and technical inspection, access control, parking, … Дополнительные применения С момента массового выпуска, применение легко расширить для регистрации автотранспорта, контроля скорости, проезда на красный сигнал светофора, контроля прохождения ТО, контроля доступа на территорию, парковки и проч.
10 ITS on Road | Passive UHF in License Plates Enables Cost-Effective, Secure and Reliable Electronic Toll Collection J. H. Tönnjes E. A. S. T. Gmb. H & Co. KG Syker Straße 201 27751 Delmenhorst / Germany Telefon +49 (0) 42 21 795 -244 Telefax +49 (0) 42 21 795 -300 www. toennjes. com east@toennjes. com
