Panel 1. 5 scanning Chiho Wang, Seog Oh Duke University

Panel 1. 5 scanning Chiho Wang, Seog Oh Duke University

Panel 1. 5 scanning • Panel 1. 5 vs 2. 5, differences relevant to

Panel 1. 5 scanning • Panel 1. 5 vs 2. 5, differences relevant to scanning: § No survey hole on base plate (outer ring) § No alignment dowel pin hole at inner ring bottom. • Procedures specific to 1. 5: § Hand adjust and align 1 st wire (wire 0) to X-ray scanner. § Use the average of the first 8 wires to calculate expected positions of other wires and straws. • 8 straws as a group, scan 10 positions along X on each half scan, with 4 overlapping X positions from each half (i. e. 16 X independent positions along the whole length). § In production will likely do 6 positions with 2 overlaps (i. e. 10 independent positions along the length) to save time. 12/04/17 Chiho Wang, Seog Oh 2

Scan pattern of well positioned wires/straws 0. 625 mm 1. 875 mm Wire 92

Scan pattern of well positioned wires/straws 0. 625 mm 1. 875 mm Wire 92 Straw 92 edge 1 Straw 92 edge 2 Straw 91 edge 2 Straw 93 edge 1 Original scan plan: • Assuming wire & straws are reasonably in the right place • Move to expected straw/wire location and scan ± 0. 15 mm with 0. 02 mm steps per wire and per straw edge (i. e. 15 steps/scan) • Re-scan any missed wires/straws (hopefully only a few) • Complete one panel per 8 hours 12/04/17 Chiho Wang, Seog Oh 3

Scan pattern of not so well positioned wires/straw Wire 52 Straw 52 edge 1

Scan pattern of not so well positioned wires/straw Wire 52 Straw 52 edge 1 Straw 51 edge 2 12/04/17 Straw 52 edge 2 Straw 53 edge 1 Wire 56 Straw 56 edge 1 Straw 56 edge 2 Straw 55 Chiho edge 2 Straw 57 edge 1 Wang, Seog Oh 4

Another example of mis-placed wire/straw Straw 60 edge 1 Wire 60 Straw 59 edge

Another example of mis-placed wire/straw Straw 60 edge 1 Wire 60 Straw 59 edge 2 Straw 60 edge 2 Straw 61 edge 1 • If wire/straw positions are too far off: • Increase range by increasing number of steps/scan • will take longer time • Scanning a panel per 8 hours would be difficult. • Re-scan list could be longer • Currently using, per wire and per straw edge: • 35 steps X 0. 02 mm = 0. 7 mm range • But still missing some wires/straws 12/04/17 Chiho Wang, Seog Oh 5

Monitor plots: 3 pages/straw Page 1: Fit pattern Position 0 Position 1 Position 5

Monitor plots: 3 pages/straw Page 1: Fit pattern Position 0 Position 1 Position 5 Position 0 Position 6 Position 2 Position 7 Position 3 Position 8 Position 4 Position 9 12/04/17 Chiho Wang, Seog Oh 6

Monitor plots, page 2: Results Y (mm) Straw error bars ± 30µm Straw edge

Monitor plots, page 2: Results Y (mm) Straw error bars ± 30µm Straw edge 2 Wire error bars ± 15µm Straw center (blue) Wire Measured wire/straw Position (black) Straw edge 1 Straw diameter 12/04/17 Expected straw/wire position (red) Chiho Wang, Seog Oh X (mm) 7

Monitor plots, page 3: Statistics 12/04/17 Straw diameter Wire offset From straw center Wire

Monitor plots, page 3: Statistics 12/04/17 Straw diameter Wire offset From straw center Wire offset from expected location Straw center offset from expected location Chiho Wang, Seog Oh 8

Straw 19 12/04/17 Chiho Wang, Seog Oh 9

Straw 19 12/04/17 Chiho Wang, Seog Oh 9

Straw 19 12/04/17 Chiho Wang, Seog Oh 10

Straw 19 12/04/17 Chiho Wang, Seog Oh 10

Straw 19 12/04/17 Chiho Wang, Seog Oh 11

Straw 19 12/04/17 Chiho Wang, Seog Oh 11

Straw 24 12/04/17 Chiho Wang, Seog Oh 12

Straw 24 12/04/17 Chiho Wang, Seog Oh 12

Straw 24 12/04/17 Chiho Wang, Seog Oh 13

Straw 24 12/04/17 Chiho Wang, Seog Oh 13

Straw 24 12/04/17 Chiho Wang, Seog Oh 14

Straw 24 12/04/17 Chiho Wang, Seog Oh 14

Straw 46 (no wire) 12/04/17 Chiho Wang, Seog Oh 15

Straw 46 (no wire) 12/04/17 Chiho Wang, Seog Oh 15

Straw 46 (no wire) Wire result should be ignored 12/04/17 Chiho Wang, Seog Oh

Straw 46 (no wire) Wire result should be ignored 12/04/17 Chiho Wang, Seog Oh 16

Straw 47 Wire 48 12/04/17 Chiho Wang, Seog Oh 17

Straw 47 Wire 48 12/04/17 Chiho Wang, Seog Oh 17

Straw 47 12/04/17 Chiho Wang, Seog Oh 18

Straw 47 12/04/17 Chiho Wang, Seog Oh 18

Straw 47 12/04/17 Chiho Wang, Seog Oh 19

Straw 47 12/04/17 Chiho Wang, Seog Oh 19

Wire off window 12/04/17 Straw 48 Chiho Wang, Seog Oh Wire in window 20

Wire off window 12/04/17 Straw 48 Chiho Wang, Seog Oh Wire in window 20

Straw 48 Wire off window, ignore 12/04/17 Chiho Wang, Seog Oh 21

Straw 48 Wire off window, ignore 12/04/17 Chiho Wang, Seog Oh 21

Wire/straw offsets vs wire/straw # Wire offset from straw center Error bars indicate range

Wire/straw offsets vs wire/straw # Wire offset from straw center Error bars indicate range (not σ) Wire offset from expected position Excluded Wire/Straw# : 46, 48, 50, 56, 59, 60, 61, 66, 80, 94 (shown as 0 due to out of scan window Straw center offset from expected position 12/04/17 Chiho Wang, Seog Oh Wire # 22

All wire/straw/positions excluded #: 46, 48, 50, 56, 59, 60, 61, 66, 80, 94

All wire/straw/positions excluded #: 46, 48, 50, 56, 59, 60, 61, 66, 80, 94 12/04/17 Chiho Wang, Seog Oh 23

2 D plot of scan location Right scan Left scan Overlap 12/04/17 Chiho Wang,

2 D plot of scan location Right scan Left scan Overlap 12/04/17 Chiho Wang, Seog Oh 24

Summary • Entire left and right normal scan plots available at: § http: //mu

Summary • Entire left and right normal scan plots available at: § http: //mu 2 e. phy. duke. edu/scan/VI/data/Panel/panel_1. 5/panel. RNs_35 stp_20171201_164807. pdf § http: //mu 2 e. phy. duke. edu/scan/VI/data/Panel/panel_1. 5/panel. LNs_35 stp_20171201_122902. pdf • Large offset of straw and wire positions are seen in panel 1. 5 • Increased range of scan is required and will take longer • Plan: § Scan to include missing wires/straws § Stereo scan § Scan pressurized panel 12/04/17 Chiho Wang, Seog Oh 25
