ORTHOGRAPHIC PROJECTION MULTIVIEW QUIZ 2 PLEASE ADD YOUR
- Slides: 25
ORTHOGRAPHIC PROJECTION & MULTIVIEW QUIZ 2 PLEASE ADD YOUR NAME, PER & DATE NOW!
1. ) Sketch a center mark
2. ) In which view do we see the true length of the inclined plane?
3. ) Define the word foreshortened:
4. ) How many principle views will an oblique plane appear in?
5. ) How many views should be used for simple cylinder?
6. What type of dimensions are centerlines used for?
7. ) Define the word oblique:
8. ) Which lines take precedent hidden lines or centerlines?
9. ) Where does the top side view go in relationship to the front side view?
10. ) In a multiview drawing, when you see straight lines that are neither horizontal or vertical what should you expect to find?
BONUS QUESTION Who’s that French guy that got this multiview thing going?
Multiviews Quiz 2 BEFORE WE CONTINUE • Exchange quiz’s with someone adjacent to you • Check to make sure their name & per is placed above the quiz • Write your initials below • Clearly mark all blank answers wrong before we begin going over it
1. ) Sketch a center mark
2. ) In which view do we see the true length of the inclined plane? The edge view
3. ) Define the word foreshortened: Shorter then it actually is
4. ) How many principle views will an oblique plane appear in? All of them
5. ) How many views should be used for a simple cylinder? Two
6. What type of dimensions are centerlines used for? Location Dimensions
7. ) Define the word oblique: Not parallel, not perpendicular
8. ) Which lines take precedent hidden lines or centerlines? Hidden Lines over Centerlines!
9. ) Where does the top side view go in relationship to the front side view? Directly above
10. ) In a multiview drawing, when you see straight lines that are neither horizontal or vertical what should you expect to find? An inclined or oblique surface
BONUS QUESTION: Who’s that French guy that got this multiview thing going? Gaspard Monge
