open EDGE Ampere for the open EDGE Shannon

open. EDGE Ampere for the open. EDGE Shannon Hollas Senior Director Worldwide Business Development Ampere Computing

Ampere Overview We are a passionate, experienced team committed to building & delivering what comes next for Cloud and Edge Computing

Ampere Arm v 8 Processors e. MAG delivers High Performance CPU, Memory and I/O in Low Power Solutions e. MAG 32 Ampere-designed 64 -bit Armv 8 cores running at consistent 3. 3 GHz 8 DDR 4 -2667 memory controllers maximize memory bandwidth Ampere e. MAG 2 Node: 7 nm • More Cores, Memory Bandwidth, IO • Higher power efficiency across wider TDP range 202 x 2019 2018 Ampere e. MAG++ 202 x Ampere e. MAG+ Ampere e. MAG™ Node: 16 nm 42 lanes of PCIe 3. 0 enable networking and storage for Telco / Edge e. MAG SKU 8140 8180 Cores 16 32 TDP 75 W 125 W SPECrate 2017_int_base est. * 34 60 * Estimated based on measured Ampere 8180 and 8140 using gcc 8. 2 -ofast, lto, jemalloc

Ampere Edge Platforms 1 U Lenovo HR 330 A 2 U Lenovo HR 350 A Raptor OCP open. EDGE Enclosure • Lenovo and Raptor platforms available today in production volume • Standard 19”, Open 19, and OCP configurations available for Edge, Telco, and Storage • open. EDGE platform sampling in Q 4 with production volume in Q 1’ 20 • Design collateral available for custom designs • Available through Ampere via sales@amperecomputing. com Twin Server Open 19 Brick

Ampere for SEBA Applications SEBA • SEBA: SDN Enabled Broadband Access • Manages wireline customer broadband services ONOS APPS ONOS WORKFLOW Grafana • Ported to scalable and versatile e. MAG Arm processor • Source code and demo available ELK VOLTHA Kafka RUNTIME CONFIG / SERVICES Prometheus XOS PROFILE KUBERNETES OS OS OS BARE METAL ARM SERVER

Ampere for 5 G Applications MME Guest OS Hypervisor Host OS open. EDGE Server PGW Guest OS Hypervisor Host OS open. EDGE Server SGW Guest OS Hypervisor Host OS open. EDGE Server e. MAG + FPGA Hardware Acceleration Akraino REC Blueprint In Development for e. MAG 2 Development platform available 3 -node server cluster running on e. MAG 2 provides optimal fit Source code and demo available today High core count, performance, throughput

Ampere VNF Ecosystem Ampere is partnering with industry leaders to provide a complete UCPE software stack Ampere e. MAG processor enables more VNF’s in u. CPE power and cost envelope Ampere plans to contribute Arm based u. CPE spec to OCP NFVI SD-WAN Firewall Routing Security Deep Packet Telco Enea, Telco Systems Fat. Pipe Checkpoint, Clavister 6 WIND Trend Micro, Enea SEBA, RIC/REC VIRTUAL MACHINE VNF VNF VNF CONTAINERS GUEST OPERATING SYSTEM VIRTUAL MACHINE VNF GUEST OPERATING SYSTEM NFVI MANAGER SECURE BOOT VNF CONTAINERS VIRTUAL MACHINE VNF VNF CONTAINERS GUEST OPERATING SYSTEM VIRTUAL SWITCH (OVS-DPDK) DATA PATH (DPDK) HYPERVISOR (KVM) LINUX BASED HOST OPERATING SYSTEM e. MAG ARM PROCESSOR

Ampere Hawk Motherboard Overview • Compatible with OCP open. EDGE Chassis CPU sled • 6. 5" x 13. 85" • 32 and 16 core e. MAG SKUs • 32 bit and 64 bit Support • TSMC 16 nm Fin. FET Processor • 32/16 Ampere Armv 8 64 -bit CPU cores @ 3. 3 GHz Sustained Turbo • 32 KB L 1 I-cache, 32 KB L 1 D-cache per core • Shared 256 KB L 2 cache per 2 cores • 32 MB globally shared L 3 cache Memory • 8 x 72 -bit DDR 4 -2667 channels • Up to 16 DIMMs and 1 TB/socket • ECC, Chip. Kill, and DDR 4 RAS features I/O • OCP Mezzanine v 2 (Conn. A/B) 10/40/100 Gb. E NIC • 1 x 16 PCIe slot • 2 x M. 2 x 4 NVME • 4 x SATA 3 • 2 x USB 2. 0 Power • 125 W TDP for 32 cores • 75 W TDP for 16 cores • Advanced Power Management Performance • SPECrate 2017_int_peak: 68* • SPECrate 2006_int_peak: 502* Availability • Sampling: Q 4’ 19 • Volume Production: Q 1’ 20 7" 14" * Estimated based on measured Ampere 8180 and 8140 using gcc 8. 2 -ofast, lto, jemalloc

Hawk Edge Platforms Twin Server Open 19 CPU Brick OCP open. EDGE CPU Sled Nokia Air. Frame/ Wiwynn EP 100

Hawk in open. EDGE CPU Sled Demo available at open. EDGE Experience Lab and Wiwynn booth

Call to Action • Ampere 100% committed to OCP • Bring demo/POC opportunities to us • Ampere believes open. EDGE enclosure has potential beyond Telco and Carrier Project Wiki with latest specification : https: //www. opencompute. org/wiki/Telcos/open. EDGE Follow-up or availability questions : sales@amperecomputing. com
