OBJECTIVES After studying Chapter 21 the reader will

OBJECTIVES After studying Chapter 21, the reader will be able to: 1. Prepare for ASE Engine Performance (A 8) certification test content area “B” (Ignition System Diagnosis and Repair). 2. Describe the procedure used to check for spark. 3. Discuss what to inspect and look for during a visual inspection of the ignition system. 4. List the steps necessary to check and/or adjust ignition timing on engines equipped with a distributor. 5. Describe how to test the ignition system using an oscilloscope. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

CHECKING FOR SPARK • Typical causes of a no-spark (intermittent spark) condition include the following: – – Weak ignition coil Low or no voltage to the primary (positive) side of the coil High resistance or open coil wire, or spark plug wire Negative side of the coil not being pulsed by the ignition module – Defective pickup coil – Defective module Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

CHECKING FOR SPARK FIGURE 21 -1 A spark tester looks like a regular spark plug with an alligator clip attached to the shell. This tester has a specified gap that requires at least 25, 000 volts (25 k. V) to fire. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

CHECKING FOR SPARK FIGURE 21 -2 A close-up showing the recessed center electrode on a spark tester. It is recessed 3/8 in. into the shell and the spark must then jump another 3/8 in. to the shell for a total gap of 3/4 in. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

ELECTRONIC IGNITION TROUBLESHOOTING PROCEDURE • When troubleshooting any electronic ignition system for no spark, follow these steps to help pinpoint the exact cause of the problem: – Turn the ignition on (engine off) and, using either a voltmeter or a test light, test for battery voltage available at the positive terminal of the ignition coil. – Connect the voltmeter or test light to the negative side of the coil and crank the engine. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

IGNITION COIL TESTING USING AN OHMMETER • To test the primary coil winding resistance, take the following steps: – Set the meter to read low ohms. – Measure the resistance between the positive terminal and the negative terminal of the ignition coil. • To test the secondary coil winding resistance, follow these steps: – Set the meter to read kilohms (kΩ). – Measure the resistance between either primary terminal and the secondary coil tower. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

IGNITION COIL TESTING USING AN OHMMETER FIGURE 21 -3 Checking an ignition coil using a multimeter set to read ohms. (Courtesy of Fluke Corporation) Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

PICKUP COIL TESTING • The pickup coil can be tested for proper voltage output. • During cranking, most pickup coils should produce a minimum of 0. 25 volt AC. • This can be tested with the distributor out of the vehicle by rotating the distributor drive gear by hand. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder FIGURE 21 -4 Measuring the resistance of an HEI pickup coil using a digital multimeter set to the ohms position. The reading on the face of the meter is 0. 796 kΩ or 796 ohms in the middle of the 500 - to 1, 500 -ohm specifications. © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

TESTING MAGNETIC SENSORS • If the sensor is removed from the engine, hold a metal (steel) object against the end of the sensor. • It should exert a strong magnetic pull on the steel object. If not, replace the sensor. • Then, the sensor can be tested using a digital meter set to read AC volts. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

TESTING MAGNETIC SENSORS FIGURE 21 -5 An AC voltage is produced by a magnetic sensor. Most sensors should produce at least 0. 1 volt AC while the engine is cranking if the pickup wheel has many teeth. If the pickup wheel has only a few teeth, you may need to switch the meter to read DC volts and watch the display for a jump in voltage as the teeth pass the magnetic sensor. (Courtesy of Fluke Corporation) Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

TESTING HALL-EFFECT SENSORS • As with any other sensor, the output of the Halleffect sensor should be tested first. • Using a digital voltmeter, check for the presence of a changing DC (digital hi-low) voltage when the engine is being cranked. • The best test is to use an oscilloscope and observe the waveform. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

TESTING HALL-EFFECT SENSORS FIGURE 21 -6 (a) The connection required to test a Hall-effect sensor. (b) A typical waveform from a Halleffect sensor. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

TESTING OPTICAL SENSORS FIGURE 21 -7 (a) The low-resolution signal has the same number of pulses as the engine has cylinders. (b) A dual-trace pattern showing both the low-resolution signal and the highresolution signals that usually represent 1 degree of rotation. (Courtesy of Fluke Corporation) Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

BAD WIRE? REPLACE THE COIL! FIGURE 21 -8 A track inside an ignition coil is not a short, but rather a low-resistance path or hole that has been burned through from the secondary wiring to the steel core. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

TESTING FOR POOR PERFORMANCE • A simple method of testing a distributorless (wastespark systems) ignition with the engine off involves removing the spark plug wires (or connectors) from the spark plugs (or coils or distributor cap) and installing short lengths (2 in. ) of rubber vacuum hose in series. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder FIGURE 21 -9 A length of vacuum hose being used for a coil wire. The vacuum hose is conductive because of the carbon content of the rubber in the hose. This hose measures only 1, 000 ohms and was 1 ft long, which is lower resistance than most spark plug wires. Notice the spark from the hose’s surface to the tip of a grounded screwdriver. © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

TESTING FOR POOR PERFORMANCE FIGURE 21 -10 Using a vacuum hose and a grounded test light to ground one cylinder at a time on a DIS. This works on all types of ignition systems and provides a method for grounding out one cylinder at a time without fear of damaging any component. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

TESTING FOR A NO-START CONDITION • A no-start condition (with normal engine cranking speed) can be the result of either no spark or no fuel delivery. • Computerized engine control systems use the ignition primary pulses as a signal to inject fuel—a port or throttle-body injection (TBI) style of fuelinjection system. If there is no pulse, then there is no squirt of fuel. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

FIRING ORDER • Firing order means the order that the spark is distributed to the correct spark plug at the right time. • The firing order of an engine is determined by crankshaft and camshaft design. • The firing order is determined by the location of the spark plug wires in the distributor cap of an engine equipped with a distributor. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder FIGURE 21 -11 The firing order is cast or stamped on the intake manifold on most engines that have a distributor ignition. © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SECONDARY IGNITION INSPECTION • Inspect a distributor cap for a worn or cracked center carbon insert, excessive side insert wear or corrosion, cracks, or carbon tracks, and check the towers for burning or corrosion by removing spark plug wires from the distributor cap one at a time. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SECONDARY IGNITION INSPECTION FIGURE 21 -12 Note where the high-voltage spark jumped through the plastic rotor to arc into the distributor shaft. Always check for a defective spark plug(s) when a defective distributor cap or rotor is discovered. If a spark cannot jump to a spark plug, it tries to find a ground path wherever it can. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SECONDARY IGNITION INSPECTION FIGURE 21 -13 Carbon track in a distributor cap. These faults are sometimes difficult to spot and can cause intermittent engine missing. The usual cause of a tracked distributor cap (or coil, if it is a distributorless ignition) is a defective (open) spark plug wire. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SECONDARY IGNITION INSPECTION FIGURE 21 -14 Corroded terminals on a waste-spark coil can cause misfire diagnostic trouble codes to be set. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SPARK PLUG WIRE INSPECTION • Spark plug wires should be visually inspected for cuts or defective insulation and checked for resistance with an ohmmeter. • Good spark plug wires should measure less than 10, 000 ohms per foot of length. – Faulty spark plug wire insulation cause hard starting or no starting in damp weather conditions. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SPARK PLUG WIRE INSPECTION FIGURE 21 -15 This spark plug boot on an overhead camshaft engine has been arcing to the valve cover causing a misfire to occur. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SPARK PLUG WIRE INSPECTION FIGURE 21 -16 Measuring the resistance of a spark plug wire with a multimeter set to the ohms position. The reading of 16. 03 kΩ(16. 030 ohms) is okay because the wire is about 2 feet long. Maximum allowable resistance for a spark plug wire this long would be 20 kΩ(20, 000 ohms). Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SPARK PLUG WIRE PLIERS ARE A GOOD INVESTMENT FIGURE 21 -17 Spark plug wire boot pliers are a handy addition to any toolbox. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SPARK PLUG SERVICE • Spark plugs should be inspected when an engine performance problem occurs and should be replaced regularly to ensure proper ignition system performance. • Many spark plugs have a service life of over 20, 000 miles (32, 000 kilometers). • Platinum-tipped original equipment spark plugs have a typical service life of 60, 000 to 100, 000 miles (100, 000 to 160, 000 kilometers). Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

ROUTE THE WIRES RIGHT! FIGURE 21 -18 Always take the time to install spark plug wires back into the original holding brackets (wiring combs). Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SPARK PLUG SERVICE FIGURE 21 -19 When removing spark plugs, it is wise to arrange them so that they can be compared any problem can be identified with a particular cylinder. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SPARK PLUG SERVICE FIGURE 21 -20 A spark plug thread chaser is a low-cost tool that hopefully will not be used often, but is necessary to clean the threads before new spark plugs are installed. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SPARK PLUG SERVICE FIGURE 21 -21 Since 1991, General Motors engines have been equipped with slightly (1/8 in. or 3 mm) longer spark plugs. This requires that a longer spark plug socket should be used to prevent the possibility of cracking a spark plug during installation. The longer socket is shown next to a normal 5/8 in. spark plug socket. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SPARK PLUG INSPECTION • Spark plugs are the windows to the inside of the combustion chamber. • A thorough visual inspection of the spark plugs often can lead to the root cause of an engine performance problem. • Two indications on spark plugs and their possible root causes in engine performance include the following: – Carbon fouling. – Oil fouling. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder FIGURE 21 -22 An extended-reach spark plug that shows normal wear. The color and condition indicate that the cylinder is operating correctly. © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SPARK PLUG INSPECTION FIGURE 21 -23 Spark plug removed from an engine after a 500 -mile race. Note the clipped side (ground) electrode. The electrode design and narrow (0. 025 in. ) gap are used to ensure that a spark occurs during extremely high engine speed operation. The color and condition of the spark plug indicate that near-perfect combustion has been occurring. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SPARK PLUG INSPECTION FIGURE 21 -24 Typical worn spark plug. Notice the rounded center electrode. The deposits indicate a possible oil usage problem. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SPARK PLUG INSPECTION FIGURE 21 -25 New spark plug that was fouled by a too-rich air-fuel mixture. The engine from which this spark plug came had a defective (stuck partially open) injector on this one cylinder only. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

QUICK AND EASY SECONDARY IGNITION TESTS FIGURE 21 -26 A water spray bottle is an excellent diagnostic tool to help find an intermittent engine miss caused by a break in a secondary ignition circuit component. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

IGNITION TIMING • Generally, for testing, engines must be at idle with computer engine controls put into base timing, the timing of the spark before the computer advances the timing. • Pretiming Checks • Timing Light Connections • Determining Cylinder 1 • Checking or Adjusting Ignition Timing Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder FIGURE 21 -27 Typical timing marks. The numbers of the degrees are on the stationary plate and the notch is on the harmonic balancer. © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

IGNITION TIMING FIGURE 21 -28 Cylinder 1 and timing mark location guide. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

IGNITION TIMING FIGURE 21 -29 (a) Typical SPOUT connector as used on many Ford engines equipped with distributor ignition (DI). (b) The connector must be opened (disconnected) to check and/or adjust the ignition timing. On DIS/EDIS systems, the connector is called SPOUT/SAW (spark output/spark angle word). Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SCOPE-TESTING THE IGNITION SYSTEM • • • Firing Line Spark Line Intermediate Oscillations Transistor-On Point Dwell Section Pattern Selection – Superimposed. – Raster (stacked). – Display (parade). • Reading the Scope on Display (Parade) • Reading the Spark Lines Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SCOPE-TESTING THE IGNITION SYSTEM • • Spark Line Slope Reading the Intermediate Section Electronic Ignition and the Dwell Section Dwell Variation (Distributor Ignition) Coil Polarity Acceleration Check Rotor Gap Voltage Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SCOPE-TESTING THE IGNITION SYSTEM FIGURE 21 -30 Typical engine analyzer hookup that includes a scope display. (1) Coil wire on top of the distributor cap if integral type of coil; (2) number 1 spark plug connection; (3) negative side of the ignition coil; (4) ground (negative) connection of the battery. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SCOPE-TESTING THE IGNITION SYSTEM FIGURE 21 -31 Clip-on adapters are used with an ignition system that uses an integral ignition coil. (Courtesy of Fluke Corporation) Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SCOPE-TESTING THE IGNITION SYSTEM FIGURE 21 -32 Typical secondary ignition oscilloscope pattern. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SCOPE-TESTING THE IGNITION SYSTEM FIGURE 21 -33 A single cylinder is shown at the top and a 4 cylinder engine at the bottom. (Courtesy of Fluke Corporation) Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SCOPE-TESTING THE IGNITION SYSTEM FIGURE 21 -34 Drawing shows what is occurring electrically at each part of the scope pattern. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SCOPE-TESTING THE IGNITION SYSTEM FIGURE 21 -35 Typical secondary ignition pattern. Note the lack of firing lines on the superimposed pattern. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SCOPE-TESTING THE IGNITION SYSTEM FIGURE 21 -36 Raster is the best scope position to view the spark lines of all the cylinders to check for differences. Most scopes display cylinder 1 at the bottom. The other cylinders are positioned by firing order above cylinder 1. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SCOPE-TESTING THE IGNITION SYSTEM FIGURE 21 -37 Display is the only position to view the firing lines of all cylinders. Cylinder 1 is displayed on the left (except for its firing line, which is shown on the right). The cylinders are displayed from left to right by firing order. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SCOPE-TESTING THE IGNITION SYSTEM FIGURE 21 -38 A downward-sloping spark line usually indicates high secondary ignition system resistance or an excessively rich air-fuel mixture. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SCOPE-TESTING THE IGNITION SYSTEM FIGURE 21 -39 An upward-sloping spark line usually indicates a mechanical engine problem or a lean air-fuel mixture. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SCOPE-TESTING THE IGNITION SYSTEM FIGURE 21 -40 The relationship between the height of the firing line and length of the spark line can be illustrated using a rope. Because energy cannot be destroyed, the stored energy in an ignition coil must dissipate totally, regardless of engine operating conditions. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SCOPE-TESTING A WASTESPARK IGNITION SYSTEM • A handheld digital storage oscilloscope can be used to check the pattern of each individual cylinder. • Some larger scopes can be connected to all spark plug wires and therefore able to display both power and waste-spark waveforms. FIGURE 21 -41 A dual-trace scope pattern showing both the power and the waste spark from the same coil (cylinders 1 and 6). Note that the firing line is higher on the cylinder that is under compression (power); otherwise, both patterns are almost identical. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SCOPE-TESTING A COIL-ON-PLUG IGNITION SYSTEM • On a coil-on-plug (COP) type of ignition system, each individual coil can be shown on a scope and using the proper cables and adapters, the waveform for all of the cylinders can be viewed at the same time FIGURE 21 -42 A secondary waveform of a Ford 4. 6 liter V-8, showing three sparks occurring at idle speed. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

IGNITION SYSTEM DIAGNOSIS Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

SUMMARY 1. A thorough visual inspection should be performed on all ignition components when diagnosing an engine performance problem. 2. Platinum spark plugs should not be regapped after use in an engine. 3. A secondary ignition scope pattern includes a firing line, spark line, intermediate oscillations, and transistor-on and transistor-off points. 4. The slope of the spark line can indicate incorrect air-fuel ratio or other engine problems. Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

REVIEW QUESTIONS 1. Why should a spark tester be used to check for spark rather than a standard spark plug? 2. How do you test a pickup coil for resistance and AC voltage output? 3. What harm can occur if the engine is cranked or run with an open (defective) spark plug wire? 4. What are the sections of a secondary ignition scope pattern? 5. What can the slope of the spark line indicate about the engine? Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

CHAPTER QUIZ 1. Technician A says that the firing line shows the voltage that is required to fire the spark plug. Technician B says that spark line shows the duration of the spark inside the cylinder. Which technician is correct? a) b) c) d) Technician A only Technician B only Both Technicians A and B Neither Technician A nor B Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

CHAPTER QUIZ 2. Technician A says that a defective spark plug wire can cause an engine miss. Technician B says that a defective spark plug can cause an engine miss. Which technician is correct? a) b) c) d) Technician A only Technician B only Both Technicians A and B Neither Technician A nor B Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

CHAPTER QUIZ 3. The _____ sends a pulse signal to an electronic ignition module. a) b) c) d) Ballast resistor Pickup coil Ignition coil Condenser Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

CHAPTER QUIZ 4. Typical primary coil resistance specifications usually range from _____ ohms. a) b) c) d) 100 to 450 500 to 1, 500 1 to 3 6, 000 to 30, 000 Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

CHAPTER QUIZ 5. Typical secondary coil resistance specifications usually range from _____ ohms. a) b) c) d) 100 to 450 500 to 1, 500 1 to 3 6, 000 to 30, 000 Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

CHAPTER QUIZ 6. Technician A says that an engine will not start and run if the ignition coil is tracked. Technician B says that one wire of any pickup coil must be grounded. Which technician is correct? a) b) c) d) Technician A only Technician B only Both Technicians A and B Neither Technician A nor B Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

CHAPTER QUIZ 7. Technician A says that a GM HEI distributor rotor can burn through and cause an engine miss during acceleration. Technician B says that a defective distributor cap can cause an engine miss during acceleration. Which technician is correct? a) b) c) d) Technician A only Technician B only Both Technicians A and B Neither Technician A nor B Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

CHAPTER QUIZ 8. The secondary ignition circuit can be tested using _____. a) b) c) d) An ohmmeter A test light An ammeter Both a and b Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

CHAPTER QUIZ 9. Two technicians are discussing a no-start condition. During cranking, a magnet held over the coil moves and the engine backfires at times. Technician A says that a bad pickup coil or CKP sensor is the most likely cause. Technician B says that an open coil primary is the most likely cause. Which technician is correct? a) b) c) d) Technician A only Technician B only Both Technicians A and B Neither Technician A nor B Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458

CHAPTER QUIZ 10. Which sensor produces a square wave signal? a) b) c) d) Magnetic sensor Hall-effect sensor Pickup coil Both b and c Automotive Fuel and Emissions Control Systems, 2/e By James D. Halderman and Jim Linder © 2009 Pearson Higher Education, Inc. Pearson Prentice Hall - Upper Saddle River, NJ 07458
