NSRP National Shipbuilding Research Program NSRP Joint Panel
NSRP National Shipbuilding Research Program NSRP Joint Panel Meeting Electrical Technologies Panel Surface Prep & Coatings Panel March 29, 2018 Charleston, SC
Agenda Thursday, March 29, 2018 (General Session) Time Presentation 8: 00 Convene Meeting – Begin VTC – Joint Session 8: 00 Introductions and Welcome to Charleston Steve Duca, NSRP ATI Executive Director 8: 10 SP&C Panel Chair’s Report Arcino Quiero, Jr. , Panel Chair 8: 40 Electrical Panel Chair’s Report Jason Farmer, Panel Chair 9: 10 NSRP Program Update Frances Pearce / Nick Laney, ATI 9: 30 NAVSEA O 5 P 2 SP&C Technical Update Mark Ingle, TWH, NAVSEA 05 P 2 10: 15 Break 10: 30 Fiber Optic Systems John Mazurowski, PSU Electro-Optics Center 11: 00 2016 Project Update – Implementation of Robust Paperless Paint (PTR –Robert Cloutier) Ross Boyd, Tru. QC Megan Brinker, Tru. QC 11: 30 NAVSEA O 5 Z 3 Technical Update Chris Nemarich, NAVSEA 05 Z 33 12: 00 SP&C Panel Steering Committee Working Lunch (Provided) Electrical and SP&C Panels Lunch (On Your Own) After lunch separate into individual Panels (Electrical and SP&C) for the remainder of the meeting Speaker
Agenda Thursday Afternoon, March 29, 2018 (Electrical Breakout) 1: 00 Convene Meeting – Begin VTC Panel Project Updates: 1: 00 2017 Project Update – Distributed Temperature Sensing for Inspection of Electrical Panels on Navy Ships Jeff Callen, PSU EOC 1: 30 2017 Project Update – Power Panel and Breaker Commonality Ricky Deloge, BIW 2: 30 2018 Project Kick-Off – Evaluation of Efficacy of Self-Sealing Cable Transit Devices for Aluminum Bulkheads and Decks in Non-Watertight Boundaries Terry Mannion, STI Marine 3: 00 Break 3: 15 2018 Project Kick-Off – Low Voltage Shipboard Lighting Feasibility Study Jason Framer, Ingalls Shipbuilding 3: 45 Advancements in LED Technology Lylyn Stockstill, LP Solutions Deirdre Burley, GLB & Associates 4: 15 For the Good of the Panel All 4: 30 Wrap Up and Adjournment Jason Farmer, Panel Chair
NSRP National Shipbuilding Research Program Electrical Technologies Panel Chair’s Report NSRP Joint Panel Meeting March 29, 2018 Charleston, SC
Mission Statement ü Reduce the cost associated with the installation and operation of electrical systems in ship construction, maintenance, and modernization ü Facilitate communications among Navy programs, electrical system integrators, ship designers, shipbuilders and other NSRP panels 5
Current Focus Areas • Promote commonality of electrical processes, products, components, and methods across ship programs • Evaluate & transition improved electrical system technologies, installation processes, and electrical system specifications. • The panel’s mission is to identify and implement technologies and processes that improve: v Total Ownership Cost v Energy Efficiency v Electrical System Performance v Safety of Workforce and Ship’s Crew 6
Panel Activities �Panel Projects �Improved Methods for Bonding & Grounding �Fiber Optic Testing Enhancement for Cost Reduction �Materials & Components for Exterior Electrical Connections (Phase 2) �Safer Inspection of MV-HV Systems �Alternatives to Fiber Optic Connectors * Final Report Available via NSRP Website
Panel Activities � Panel Projects � Distributed Temperature Sensing for Inspection of Electrical Panels on Navy Ships � Power Panel and Breaker Commonality � Low Voltage Shipboard Lighting Feasibility Study** � Evaluation of Efficacy of Self-Sealing Cable Transit Devices for Aluminum Bulkheads and Decks in Non. Watertight Boundaries** ** 2018 New Starts � Areas of Interest � Electrical Installation � Solid State Lighting � High Temperature Insulated Bus Pipe � Switchgear Inspection
2016 Summary � Panel Meetings Spring – Joint Panel Meeting � � � Date: May 10 -12, 2016 Location: Biloxi, MS Focus: Shipboard Power Systems Summer – Joint Panel Meeting with WD Panel � Date: August 24 -25, 2016 � Location: Green Bay, WI � Tour: Marinette Marine ü Winter – Panel Meeting � Date: December 7 -8, 2016 � Location: Jacksonville, FL � Tour of BAE Systems � Focus: Future Shipboard Power System Technologies and Bonding & Grounding Methods � Technology Transition Activities Ship. Tech 2016 NSRP Day @ NAVSEA SNAME 2016
2017 Overview � Panel Meetings Spring – All Panel Meeting � Date: March 7 -9, 2017 � Location: Charleston, SC ü Summer – Joint Panel Meeting (BT, ELE, SDMT) � Date: June 20 -21, 2017 � Location: Portland, ME � Tour: Bath Iron Works / DDG 1001 � Winter – Joint Panel Meeting (ELE, RM) � Date: November 7 -8, 2017 � Location: San Diego, CA � Tour: General Atomics � Technology Transition Activities All Panel Expo MFPT 2017 NSRP Day @ NAVSEA SNAME 2017
Questions
