Nov 23 2010 Rob Chen Senior Technical Consultant
雲端基礎第二部 建置永續可靠虛擬環境 Nov 23, 2010 Rob Chen Senior Technical Consultant © Hitachi Data Systems Corporation 2010. All rights reserved.
AGENDA § Introducing: Hitachi Data Resilience § Hitachi Data Resilience Products and Solutions Briefing § Hitachi Data Resilience in Microsoft Hyper-V Environment Ø Hitachi Unified Compute Platform & Virtual Storage Platform Ø Hitachi Dynamic Provisioning Ø Business Continuity & Disaster Recovery: Hitachi Storage Cluster § Summery § Q&A
Data Resilience Core Solution Technologies Three key technology areas comprise the foundation of the data resilience process. Together, these technologies drive solutions for protecting and securing business data in physical and virtual data storage environments Data Replication & Management Includes within- and between array replication as well as array-agnostic replication and management products and services for open systems and mainframes Data Protection & Management Includes technologies and services for continuous data protection, de-duplication, data archiving, and data backup Data Security Incorporates offerings for data confidentiality, data integrity, traceability, secure partitioning, data sanitization, sure management, and secure cloud
The Hitachi Data Resilience Solution Stack Represents A Process That is Enhanced by Technologies Hitachi Global Solution Services (GSS) Data Security Virtualization Continuous Data Protection Data De-Duplication Data Replication Data Archiving Data Backup Hitachi Global Solution Services (GSS) Data Resilience is Enhanced By: § Hitachi Enterprise Storage § Hitachi Modular Storage § Hitachi Content Platform § Backup & Replication Assessments § Data Migration § Application Solutions
AGENDA § Introducing: Hitachi Data Resilience § Hitachi Data Resilience Products and Solutions Briefing § Hitachi Data Resilience in Microsoft Hyper-V Environment Ø Hitachi Unified Compute Platform & Virtual Storage Platform Ø Hitachi Dynamic Provisioning Ø Business Continuity & Disaster Recovery: Hitachi Storage Cluster § Summery § Q&A
You Face a Number of Challenges with Implementing a Data Resilience Strategy A number of challenges exist Technical Complexity § High operating and maintenance costs § High personnel costs, which drives increased OPEX Strategic Focus § A balance in focus between operational resilience and disaster planning is required to optimize value from data resilience Mapping Solutions to Requirements § Multiple requirements; Traditional point data resilience products solve only part of the problem You need to leverage Data Resilience solutions that meet your data protection and recovery objectives at the lowest possible Total Cost of Ownership
Hitachi Data Resilience for Virtualized Environments File Service And Data Archiving Server Virtualization Virtual Servers Hitachi UCP Physical Servers HNAS HCP VTL NAS CAS VTL Storage Pool Hitachi Optimized Storage Unsurpassed performance, reliability and High Perf optimization for virtualized environments. FC - MOD Hitachi BOS-V Hitachi Tiered Storage Manager Hitachi Dynamic Provisioning Hitachi Optimized Solutions Helping organizations achieve greater operational resilience and resource efficiency. High Perf FC - ENT VSP High Capcity FC - MOD High Capacity WAN FC - ENT High Capacity SATA - MOD USP V Data Backup And De-Duplication AMS High Capacity SATA - ENT VSP Hitachi True. Copy Hitachi Universal Replicator Hitachi Storage Cluster Hitachi In-System Shadow. Image Hitachi Replication Manager Hitachi Protection Manager • AMS = Hitachi Adaptable Modular Storage • HCP = Hitachi Content Platform • HNAS = Hitachi NAS Platform, powered by Blue. Arc® • VSP = Hitachi Virtual Storage Platform® • USP-V = Hitachi Universal Storage Platform® V
AGENDA § Introducing: Hitachi Data Resilience § Hitachi Data Resilience Products and Solutions Briefing § Hitachi Data Resilience in Microsoft Hyper-V Environment Ø Hitachi Unified Compute Platform & Virtual Storage Platform Ø Hitachi Dynamic Provisioning Ø Business Continuity & Disaster Recovery: Hitachi Storage Cluster § Summery § Q&A
Orchestration § Integrated workflow § Centralized management § Deployment § Intelligent SLA environment § Template and policy based § Chargeback § Reporting Unified Portal Open APIs Hitachi Unified Compute Platform Scale Unit IT Admin Cloud Scale Unit Network Storage Compute Applications Remote Scale Unit System Center VMM and Ops Mgr, Hitachi, Other Local 2 nd Scale Unit Manage and Monitor Developer Business User
Hardware and Software Components – Initial Versions Ethernet Fibre Channel Servers § Hitachi Blade Symphony 2000 § Hitachi Blade Symphony 320 § Hitachi 2 U § Limited 3 rd party server support* Storage §Hitachi VSP §Hitachi USP VM §Other storage through USP V or VM Network §Industry Standards §TBD Network Software §Hitachi management §Network management §MS System Center Operations Manager §MS System Center Virtual Machine Manager §MS Hyper-V support
Hitachi Unified Compute Platform – What Does It DO? Next Generation Efficiency Business User Orchestration Hardware, Software and Integration Reporting Virtual environments provided IT Admin § Quickly § Consistently § Simply Developer to IT as well as to the business Role Based User Access Scalable Architecture Unified Compute Platform Unified Management Multi Tenancy
HDS Virtual Storage Platform 3 D Scaling: Scale Up Increase performance, capacity and connectivity tightly coupled through a global cache to meet increasing server demands. Solution Capabilities § Host servers can access all the resources that are dynamically added to the base configuration. § All the resources can act as one system for maximum performance and capacity. § Managed as one common pool of resources for more efficient utilization of resources § Dynamically scale for performance, capacity, connectivity without disruption Business Value § Industry’s highest OLTP performance for open and mainframe environments. § Grow from a small data center footprint – 19” rack § Front to rear airflow for most efficient floor planning § Highest density storage using 2. 5” drives § Host transparent migration from/to multivendor storage at 80 percent less effort and cost 3 D
HDS Virtual Storage Platform 3 D Scaling: Scale Out Solution Capabilities Increase aggregate performance, capacity, throughput, and connectivity by dynamic allocation of storage resources to satisfy multiple distributed host server requirements. § Build out the storage system by combining multiple units into a single logical system § Dynamically scales out to support the needs of different servers by prioritizing the common storage resources § Ensure safe multitenancy and quality of service through partitioning of cache and port address space. Business Value § Tailor for increasing workloads without compromise § Consolidate resources for virtual server environments 3 D § Highest data center density and lowest power consumption for the capacity stored
HDS Virtual Storage Platform 3 D Scaling: Scale Deep Storage virtualization can provide a third dimension of scaling for consolidating externally attached storage systems with virtual servers. Solution Capabilities § External storage joins the storage pool with all the functionality of the storage system § Offloads less demanding data to lower cost external storage § Simplifies management of external storage with common management, data protection, and search § Allows use of existing or legacy assets – over 200 storage systems and up to 255 PB Business Value § Increase value and useful life of existing assets § Reduce OPEX costs through a common management framework 3 D § Reduce CAPEX using lower cost tiers of external storage
Hitachi Dynamic Provisioning § Virtualize devices into a pool of capacity and allocate by pages HDP Volume (Virtual LUN) § Dynamically provision new servers in seconds § Eliminate allocated but unused waste by allocating only the pages that are used HDP Pool § Extend Dynamic Provisioning to external virtualized storage § Convert fat volumes into thin volumes by moving then into the pool 120 Response Time (ms) § Optimize storage performance by spreading the I/O across more arms LDEV LDEVLDEVs 100 80 60 40 716% more transactions 20 0 0 1, 000 2, 000 3, 000 4, 000 5, 000 Transactions (IOPS) Single LDEV Windows LVM HDP Pool 6, 000 7, 000
Today: Automated Data Mobility § Two layers of data mobility • Infrastructure layer or block level Tier 0 • Object layer or file level § Enterprise SLC Flash has 100, 000 write/format cycles Tier 1 • Wear leveling, error recovery, spares § Use virtualization and data mobility tools to move (or reprovision) the volume without disruption to any other pool or tier based on Tier 2 • Promotion or demotion • Consolidation or migration • SLO, performance or cost change § Automated with policy based management • Based upon pre-set SLAs Infrastructure/ block level Object/file level
Page Level Tiering POOL A § Different tiers of storage are now in EFD/SSD TIER 0 one pool of pages § Data is written to the highest Last Referenced SAS TIER 1 performance tier first § As it becomes less active it migrates to lower level tiers § If activity increases it will be promoted back to a higher tier § Since 20% of data accounts for 80% of the activity, only the active part of a volume will reside on the higher performance tiers. Last Referenced SATA TIER 2
Hitachi Storage Cluster for Microsoft® Hyper-V™ § Innovative business continuity/disaster recovery solution for Microsoft Hyper-V environments § Leverages proven technology from Hitachi and Microsoft – Hitachi system-based remote replication technology • Hitachi True. Copy® Synchronous software • Hitachi Universal Replicator software (asynchronous) – Hitachi Storage Cluster – Microsoft Windows® 2008 § Provides business continuity/disaster recovery locally or within metropolitan areas and across geographically dispersed sites – Automatic failover and data recovery in the event of a site outage Intended for midrange to enterprise users Available through Hitachi Global Solution Services (GSS)
Hitachi Storage Cluster for Microsoft® Hyper-V™ — Components Based on Hitachi Storage Cluster technology—supported by many years of experience and proven with many enterprise-level sites Hitachi Hardware Hitachi Software Hitachi Adaptable Modular Storage Hitachi Virtual Storage Platform Hitachi Universal Storage Platform VM Hitachi Storage Cluster Hitachi True. Copy or Hitachi Universal Replicator Now, built on Hitachi Storage Cluster Success — Hitachi Storage Cluster for Hyper-V Microsoft Windows Server® 2008 Enterprise or Data Center Editions Hyper-V Failover Clustering Windows 2008 Server Core Installation
Hitachi Storage Cluster for Microsoft® Hyper-V™ — How it Works Installed as a generic resource script in the cluster resource group Ensures replication traffic is moving in the proper direction based on the owning node in the cluster Controls disk access in the event of a failover Controls the order that resources come online within the cluster group
Hitachi Storage Cluster for Microsoft® Hyper-V™ — How it Works § In normal operation, virtual machines run on their primary server and all data is replicated to the remote array. Site A Hitachi UCP Site B Hitachi UCP FC/DWDM/WAN Hitachi Virtual Storage Platform Synchronous or Asynchronous Replication between Storage Systems Hitachi Virtual Storage Platform
Hitachi Storage Cluster for Microsoft® Hyper-V™ — How it Works § In the event of a server failure or scheduled maintenance, virtual machines can be automatically migrated to another local server. Site A Hitachi UCP Site B Hitachi UCP Migration at Local Site FC/DWDM/WAN Hitachi Virtual Storage Platform Synchronous or Asynchronous Replication between Storage Systems Hitachi Virtual Storage Platform
Hitachi Storage Cluster for Microsoft® Hyper-V™ — How it Works § In the event of a major outage at the primary site, all replicated virtual machines failover automatically to the recovery site. Site A Hitachi UCP Site B Hitachi UCP Virtual Machines Failover to Site B FC/DWDM/WAN Hitachi Virtual Storage Platform Synchronous or Asynchronous Replication between Storage Systems Hitachi Virtual Storage Platform
Hitachi Storage Cluster for Microsoft® Hyper-V™ — How it Works § Disks are easily re-synchronous on primary site recovery. Site A Hitachi UCP Site B Hitachi UCP FC/DWDM/WAN Hitachi Virtual Storage Platform Synchronous or Asynchronous Replication between Storage Systems Hitachi Virtual Storage Platform
Hitachi Storage Cluster for Microsoft® Hyper-V™ — How it Works § When ready, virtual machines are moved back to the primary site. § Replication direction reverses and the environment returns to its normal operating state. Site A Hitachi UCP Site B Hitachi UCP Virtual Machines Failback to Site A FC/DWDM/WAN Hitachi Virtual Storage Platform Synchronous or Asynchronous Replication between Storage Systems Hitachi Virtual Storage Platform
AGENDA § Introducing: Hitachi Data Resilience § Hitachi Data Resilience Products and Solutions Briefing § Hitachi Data Resilience in Microsoft Hyper-V Environment Ø Hitachi Unified Compute Platform & Virtual Storage Platform Ø Hitachi Dynamic Provisioning Ø Business Continuity & Disaster Recovery: Hitachi Storage Cluster § Summery § Q&A
Benefits § Provides common business continuity and disaster recovery solution – Windows and Hyper-V - supported Linux operating systems – Physical and virtualized host environments § Simplifies dispersed business continuity and disaster recovery process – – – No need to cluster individual applications Easier deployment/management Provides clustering over distance to mitigate risks of site-wide disasters Built upon Microsoft Cluster Server (MSCS), not third-party clustering Provides near real-time remote replica of production disks for use at the recovery site § Delivers the benefits of system-based versus host-based replication § Enables server to storage virtualization END-TO-END VIRTUALIZATION Virtualized servers and storage to drive operational and business efficiencies
Solution Summary — Hitachi Data Systems Virtualization Strategy § Committed to server virtualization environments – Developing innovative solutions – Driving further efficiencies within these environments § Clear market leader in storage virtualization – Unique position to provide “blueprints” for end-to-end virtualization § Building solutions around business continuity and disaster recovery Storage platforms are ideally suited for these environments • Hitachi Adaptable Modular Storage • Hitachi Universal Storage Platform V or Universal Storage Platform VM § Proven geographically dispersed business continuity and disaster recovery solution with Hitachi Storage Cluster for Microsoft Environments. § Proven replication technologies
Hitachi Storage Cluster for Microsoft Hyper-V Microsoft Windows Server Hitachi Storage Cluster + Hitachi True. Copy or Universal Replicator + § Improves availability § Optimizes and expands Disaster Recovery to additional applications in virtualized Windows environments § Automated failover, data resynchronization and automated failback of virtual machines
Microsoft + Hitachi Data Systems Data Resilience = Success Choose Hitachi Data Resilience For: § Competitive Advantage § Scalable, Flexible and Secure Solutions § A Comprehensive Resolution to Your Data Complexity Challenges § The Best Bottom Line § World Class Consulting, Implementation Services, and support
QUESTIONS AND DISCUSSION
