50 Years of Delivering Earth Observation Advances Successfully Built and Delivered: • Over 100 Remote Sensing Satellites • More than 500 Instruments GOES-R

Satisfying Global Market Needs for Over 25 Years 1 2 Echo. Star IIIIV IV A 2100 bus 1958 SCORE 1 st Communications Payload 3 Echo. Star VII Telstar 101 102 401 402 R Inmarsat-3/F Between 1975 and 1980 BSE, Satcom 1, Satcom 2, Anik-B Satcom C 3 Satcom C 4 ACTS 1985 RCA Astro Electronics Pan. Am. Sat-1 Spacenet-3 R BS-3 A 4 AP 7 Intelsat-VIII 15 16 11 8 18 JCSAT 11, 12 NSS-7 NSS-6 NSS-803 VINASAT 1 Chinastar-1 ACe. S Garuda-1 Nimiq-1 Spacenet-4 BS-3 N SIRIUS 4 Nimiq-2 Telkom I Iridium (89 buses) IKONOS 1995 GE Astro Space 14 Rainbow-1 JCSAT-110 ABS-1 1990 10 12 4 5 Anik-E 2 BS-3 B 6 AMC 1 2 3 Satcom C 1 Aurora-2 GSTAR-3 GSTAR-4 Asia. Sat 2 NSS-K Satcom Ku-2 ASTRA-1 A ASTRA-1 B ASC-1 GSTAR-1 Spacenet-2 Satcom Ku-1 Spacenet-1 BS-2 A BS-2 B Satcom 2 R Aurora 1 Satcom 1 R Satcom 4 Satcom 3 R Echo. Star X 12 345 Anik-E 1 1980 Koreasat Legend N-STAR c 2000 BSAT-3 a JCSAT 9, 10 ASTRA IKR ASTRA IL 2005 2010 Lockheed Martin CSS Martin Marietta Astro Space Our A 2100 -Based GOES-R Solution Provides Highest Value and Performance, A 2100 spacecraft have accumulated 200 years of on-orbit operation without a failure 5

GOES-R Overview Extending the continuity of NOAA’s 40 -year geostationary mission, GOES-R will be the next weather sentinel for monitoring threatening weather, and providing data forecasting and environmental analyses • A collaborative development and acquisition – Flight Project - led by NASA – Ground Segment Project - led by NOAA • Scheduled for launch in 2015 • Six advanced instruments • New and improved capabilities for – decreased lead times for severe weather warnings – better storm tracking capabilities – solar, space weather, and climate analyses – advanced products for aviation, transportation, commerce

Satellite Driving Requirements • Provide precision, stable space platforms at two operational geostationary orbital locations (75 W and 135 W) carrying the baseline instrument set • Operational Mission - First Launch 2015: Provide continuity and improvements over the current system with spacecraft bus reliability of 0. 81 after 10 years of on-orbit operation preceded by 5 years ground storage & up to 5 years onorbit storage • Spacecraft On-Orbit Life of 15 years with orbit East-West and North-South position maintained to within +/-0. 1 degree. Support 9 station location changes • Collect and transmit up to 140 Mbps (coded) Instrument Payload data from each location continuously. • Continue Rebroadcast function at L-Band up to 31 Mbps utilizing dual polarization • Provide continuing and new services (Search & Rescue, Data Collection, EMWIN)

GOES-R Mission GOES-R is the next generation of NOAA geostationary satellites that will provide a major improvement in quality, quantity and timeliness of data collected. Visible & IR Imagery • Advanced Baseline Imager (ABI) Lighting Mapping • Geostationary Lightning Mapper (GLM) Space Weather Monitoring • Space Environment In-Situ Sensor Suite (SEISS) • Magnetometer Solar Imaging • Solar Ultra-Violet Imager (SUVI) • Extreme UV/X-Ray Irradiance Sensors (EXIS)

SUVI EXIS Magnetometer SEISS GLM Star trackers ABI

Magnetometer Greg Mandt – 1. 8 m SUVI EXIS SEISS Star trackers GLM ABI

GOES-R Spacecraft Configuration (External) ABI GLM EARTH POINTING OMNI ANT STAR TRACKERS Dimensions: S-BAND DIPOLE • 5. 4 m from LV adapter to top of ABI X-BAND ANT • S/A Panels are approx. 1 m x 4 m SIS ELECTRONICS each SUVI GPS ANT UHF ANT L-BAND GRB ANT EXIS SUN SENSOR SGPS SEISS MPS-LO MPS-HI EHIS AFT HEMI + BICONE OMNI ANT SOLAR ARRAY MAGNETOMETER

Notable Performance Elements • Operates through daily stationkeeping and momentum adjust maneuvers – Low risk station-keeping operations – Increased instrument availability – Decreased propellant required due to high efficiency thruster • Yaw flip improves ABI radiometric response – Outage twice per year – Total time of noncompliance for instrument interface requirements <120 min per year • Vibration Isolation for optical bench

Design Elements Support Precision INR for Users • ABI and GLM are mounted on stiff optical bench ABI & GLM Decoupled from Bus – Dynamics are tunable to optimize system performance – Couple instrument motion to IMU and star trackers with low thermal distortion • High-accuracy attitude determination system on the instrument optical bench – High accuracy star trackers – High-bandwidth, low-latency and low-noise IMU for effective motion compensation Animation shows the vibration-isolation impact Augmented attitude control array damping demonstrated with risk-reduction tests

Optical Bench Vibration Isolation Impact

GOES-R Satellite Production and Support Locations
