Networking (video #1 A) Alan L. Cox alc@rice. edu Some slides adapted from CMU

Networking (video #1 A) Alan L. Cox [email protected] edu Some slides adapted from CMU 15. 213 slides

Objectives Be exposed to the basic underpinnings of the Internet Be able to use

Objectives Be exposed to the basic underpinnings of the Internet Be able to use network socket interfaces effectively Be exposed to the basic underpinnings of the World Wide Web Cox Networking 2

The 2004 A. M. Turing Award Goes to. . . Cox Networking 3

The 2004 A. M. Turing Award Goes to. . . Cox Networking 3

The 2004 A. M. Turing Award Goes to. . . Bob Kahn Vint Cerf

The 2004 A. M. Turing Award Goes to. . . Bob Kahn Vint Cerf "For pioneering work on internetworking, including the design and implementation of the Internet's basic communications protocols, TCP/IP, and for inspired leadership in networking. " The first Turing Award given to recognize work in computer networking Cox Networking 4

Telephony Interactive telecommunication between people Analog voice Transmitter/receiver continuously in contact with electronic circuit

Telephony Interactive telecommunication between people Analog voice Transmitter/receiver continuously in contact with electronic circuit Electric current varies with acoustic pressure Analog/Continuous Signal Over electrical circuits Cox Networking 5

Telephony Milestones 1876: Alexander Bell invented telephone 1878: Public switches installed at New Haven

Telephony Milestones 1876: Alexander Bell invented telephone 1878: Public switches installed at New Haven and San Francisco, public switched telephone network is born People can talk without being on the same wire! Without Switch Cox With Switch Networking 6

Telephony Milestones 1878: First telephone directory; White House line 1881: Insulated, balanced twisted pair

Telephony Milestones 1878: First telephone directory; White House line 1881: Insulated, balanced twisted pair as local loop 1885: AT&T formed 1892: First automatic commercial telephone switch 1903: 3 million telephones in U. S. 1915: First transcontinental telephone line 1927: First commercial transatlantic commercial service Cox Networking 7

Telephony Milestones 1937: Multiplexing introduced for inter-city calls One link carries multiple conversations With

Telephony Milestones 1937: Multiplexing introduced for inter-city calls One link carries multiple conversations With Multiplexing Without Multiplexing Cox Networking 8

Data or Computer Networks designed for computers to computers or devices vs. communication between

Data or Computer Networks designed for computers to computers or devices vs. communication between human beings Digital information vs. analog voice Digital/Discrete Signal Not a continuous stream of bits, rather, discrete “packets” with lots of silence in between Dedicated circuit hugely inefficient Packet switching invented Cox Networking 9

Major Internet Milestones 1960 -1964 Basic concept of “packet switching” was independently developed by

Major Internet Milestones 1960 -1964 Basic concept of “packet switching” was independently developed by Baran (RAND), Kleinrock (MIT) AT&T insisted that packet switching would never work! 1965 First time two computers talked to each other using packets (Roberts, MIT; Marill, SDC) dial-up MIT TX-2 Cox SDC Q 32 Networking 10

Major Internet Milestones 1968 BBN group proposed to use Honeywell 516 mini-computers for the

Major Internet Milestones 1968 BBN group proposed to use Honeywell 516 mini-computers for the Interface Message Processors (i. e. packet switches) 1969 The first ARPANET message transmitted between UCLA (Kleinrock) and SRI (Engelbart) We sent an “L”, did you get the “L”? Yep! We sent an “O”, did you get the “O”? Yep! We sent a “G”, did you get the “G”? Crash! Cox Networking 11

Major Internet Milestones • 1970 First packet radio network ALOHANET (Abramson, U Hawaii) •

Major Internet Milestones • 1970 First packet radio network ALOHANET (Abramson, U Hawaii) • 1973 Ethernet invented (Metcalfe, Xerox PARC) • Why is it called the “Inter-net”? • 1974 “A protocol for Packet Network Interconnection” published by Cerf and Kahn – First internetworking protocol TCP – This paper was cited for their Turing Award • 1977 First TCP operation over ARPANET, Packet Radio Net, and SATNET • 1985 NSF commissions NSFNET backbone • 1991 NSF opens Internet to commercial use Cox Networking 12

Internet Hourglass Architecture Email, Web, ssh, . . . TCP, UDP, … IP Ethernet,

Internet Hourglass Architecture Email, Web, ssh, . . . TCP, UDP, … IP Ethernet, Wi. Fi, 3 G, bluetooth, . . . Cox Networking 13

Network Hardware register file CPU chip ALU system bus memory bus main memory I/O

Network Hardware register file CPU chip ALU system bus memory bus main memory I/O bridge Bus Interface Expansion slots I/O bus USB controller mouse keyboard Cox graphics adapter disk controller network adapter disk network monitor Networking 14

Computer Networks A network is a hierarchical system of “boxes” and “wires” organized by

Computer Networks A network is a hierarchical system of “boxes” and “wires” organized by geographical proximity Cluster network spans a rack or room • Ethernet, Infiniband, Wi. Fi, … LAN (local area network) spans a building or campus • Switched Ethernet is most prominent example WAN (wide-area network) spans very long distance • A high-speed point-to-point link • Leased line or SONET/SDH circuit, or MPLS/ATM circuit An internetwork (internet) is an interconnected set of networks The Global IP Internet (uppercase “I”) is the most famous example of an internet (lowercase “i”) Cox Networking 15

Lowest Level: Ethernet Segment Ethernet segment consists of a collection of hosts connected by

Lowest Level: Ethernet Segment Ethernet segment consists of a collection of hosts connected by wires (twisted pairs) to a hub host 100 Mb/s host hub host 100 Mb/s ports Operation Each Ethernet adapter has a unique 48 -bit address Hosts send bits to any other host in chunks called frames Hub slavishly copies each bit from each port to every other port • Every host sees every bit Note: Hubs are obsolete • Bridges (switches, routers) became cheap enough to replace them (don’t broadcast all traffic) Cox Networking 16

Next Level: Bridged Ethernet Segment Spans room, building, or campus Bridges cleverly learn which

Next Level: Bridged Ethernet Segment Spans room, building, or campus Bridges cleverly learn which hosts are reachable from which ports and then selectively copy frames from port to port host hub host 100 Mb/s host bridge 100 Mb/s 1 -10 Gb/s host Cox 1 Gb/s bridge 1 Gb/s host Networking host hub host bridge host 17

Conceptual View of LANs For simplicity, hubs, bridges, and wires are often shown as

Conceptual View of LANs For simplicity, hubs, bridges, and wires are often shown as a collection of hosts attached to a single wire: host Cox host. . . host Networking 18

Next Level: internets Multiple incompatible LANs can be physically connected by specialized computers called

Next Level: internets Multiple incompatible LANs can be physically connected by specialized computers called routers The connected networks are called an internet host. . . host. . . LAN 1 host LAN 2 router WAN router LAN 1 and LAN 2 might be completely different, totally incompatible LANs (e. g. , Ethernet and Wi. Fi, 802. 11*, T 1 -links, DSL, …) Cox Networking 19

The Internet Circa 1986 In 1986, the Internet consisted of one backbone (NSFNET) that

The Internet Circa 1986 In 1986, the Internet consisted of one backbone (NSFNET) that connected 13 sites via 45 Mbps T 3 links Merit (Univ of Mich) BARRNet (Palo Alto) NCSA (Illinois) Mid. Net (Lincoln, NE) Cornell Theory Center West. Net (Salt Lake City) Pittsburgh Northwest. Net (Seattle) Supercomputing Center San Diego Supercomputing Center John von Neumann Center (Princeton) SESQUINET (Rice) SURANET (Georgia Tech) Connecting to the Internet involved connecting one of your routers to a router at a backbone site, or to a regional network that was already connected to the backbone Cox Networking 20

NSFNET Internet Backbone source: www. eef. org Cox Networking 21

NSFNET Internet Backbone source: www. eef. org Cox Networking 21

After NSFNET Early 90 s Commercial enterprises began building their own high-speed backbones Backbone

After NSFNET Early 90 s Commercial enterprises began building their own high-speed backbones Backbone would connect to NSFNET, sell access to companies, ISPs, and individuals 1995 NSFNET decommissioned NSF fostered the creation of network access points (NAPs) to interconnect the commercial backbones Cox Networking 22

Current Internet Architecture Cox Networking 23

Current Internet Architecture Cox Networking 23

AT&T Backbone Cox Networking 24

AT&T Backbone Cox Networking 24

Networking (video #1 B) Alan L. Cox alc@rice. edu Some slides adapted from CMU

Networking (video #1 B) Alan L. Cox [email protected] edu Some slides adapted from CMU 15. 213 slides

The Notion of an internet Protocol How is it possible to send bits across

The Notion of an internet Protocol How is it possible to send bits across incompatible LANs and WANs? Solution: protocol software running on each host and router smoothes out the differences between the different networks Implements an internet protocol (i. e. , set of rules) that governs how hosts and routers should cooperate when they transfer data from network to network TCP/IP is the protocol for the global IP Internet Cox Networking 26

What Does an internet Protocol Do? 1. Provides a naming scheme An internet protocol

What Does an internet Protocol Do? 1. Provides a naming scheme An internet protocol defines a uniformat for host addresses Each host (and router) is assigned at least one of these internet addresses that uniquely identifies it 2. Provides a delivery mechanism An internet protocol defines a standard transfer unit (packet) Packet consists of header and payload • Header: contains info such as packet size, source and destination addresses • Payload: contains data bits sent from source host Cox Networking 27

Transferring Data Over an internet (1) client server protocol software data LAN 1 adapter

Transferring Data Over an internet (1) client server protocol software data LAN 1 adapter PH FH 1 (4) Router LAN 1 adapter LAN 1 data (8) data (7) data PH FH 2 (6) data PH FH 2 protocol software PH FH 1 LAN 1 frame (3) Host B data internet packet (2) Host A LAN 2 adapter PH FH 1 LAN 2 adapter LAN 2 frame data LAN 2 PH FH 2 (5) protocol software Cox Networking 28

Other Issues We are glossing over a number of important questions: What if different

Other Issues We are glossing over a number of important questions: What if different networks have different maximum frame sizes? (segmentation) How do routers know where to forward frames? How are routers informed when the network topology changes? What if packets get lost? We’ll leave the discussion of these question to computer networking classes (COMP 429) Cox Networking 29

Global IP Internet Based on the TCP/IP protocol family IP (Internet protocol) : •

Global IP Internet Based on the TCP/IP protocol family IP (Internet protocol) : • Provides basic naming scheme and unreliable delivery capability of packets (datagrams) from host-to-host UDP (Unreliable Datagram Protocol) • Uses IP to provide unreliable datagram delivery from process-to-process TCP (Transmission Control Protocol) • Uses IP to provide reliable byte streams from processto-process over connections Accessed via a mix of Unix file I/O and functions from the sockets interface Cox Networking 30

A Client-Server Transaction Most network applications are based on the client-server model: A server

A Client-Server Transaction Most network applications are based on the client-server model: A server process and one or more client processes Server manages some resource Server provides service by manipulating resource for clients 1. Client sends request Client process 4. Client handles response Server process 3. Server sends response Resource 2. Server handles request Note: clients and servers are processes running on hosts (can be the same or different hosts) Cox Networking 31

Organization of an Internet Application Internet client Internet server Client User code Server TCP/IP

Organization of an Internet Application Internet client Internet server Client User code Server TCP/IP Kernel code TCP/IP Sockets interface (system calls) Hardware interface (interrupts) Network adapter Hardware and firmware Network adapter Global IP Internet Cox Networking 32

A Programmer’s View of the Internet Hosts are mapped to a set of 32

A Programmer’s View of the Internet Hosts are mapped to a set of 32 -bit IP addresses 128. 42. 128. 17 (4 * 8 bits) A set of identifiers called Internet domain names are mapped to the set of IP addresses for convenience www. cs. rice. edu is mapped to 128. 42. 128. 17 A process on one Internet host can communicate with a process on another Internet host over a connection Cox Networking 33

Internet Connections Clients and servers communicate by sending streams of bytes over connections: Point-to-point,

Internet Connections Clients and servers communicate by sending streams of bytes over connections: Point-to-point, full-duplex (2 -way communication), and reliable A socket is an endpoint of a connection Socket address is an IP address, port pair A port is a 16 -bit integer that identifies a process: Ephemeral port: Assigned automatically on client when client makes a connection request Well-known port: Associated with some service provided by a server (e. g. , port 80 is associated with Web servers) A connection is uniquely identified by the socket addresses of its endpoints (socket pair) (cliaddr: cliport, servaddr: servport) Cox Networking 34

Putting it all Together: Anatomy of an Internet Connection Client socket address 128. 2.

Putting it all Together: Anatomy of an Internet Connection Client socket address 128. 2. 194. 242: 51213 Client Server socket address 208. 216. 181. 15: 80 Connection socket pair (128. 2. 194. 242: 51213, 208. 216. 181. 15: 80) Client host address 128. 2. 194. 242 Cox Server (port 80) Server host address 208. 216. 181. 15 Networking 35

Clients Examples of client programs Web browsers, email, ssh How does a client find

Clients Examples of client programs Web browsers, email, ssh How does a client find the server? The IP address in the server socket address identifies the host (more precisely, an adapter on the host) The (well-known) port in the server socket address identifies the service, and thus implicitly identifies the server process that performs that service Examples of well known ports • • Cox Port 7: Echo server 22: Ssh server 25: Mail server 80: Web server Networking 36

Using Ports to Identify Services Server host 128. 2. 194. 242 Client host Client

Using Ports to Identify Services Server host 128. 2. 194. 242 Client host Client Service request for 128. 2. 194. 242: 80 (i. e. , the Web server) Web server (port 80) Kernel Echo server (port 7) Client Service request for 128. 2. 194. 242: 7 (i. e. , the echo server) Web server (port 80) Kernel Echo server (port 7) Cox Networking 37

Servers are long-running processes (daemons) Created at boot-time (typically) by the init process (process

Servers are long-running processes (daemons) Created at boot-time (typically) by the init process (process 1) Run continuously until the machine is turned off Each server waits for requests to arrive on a well-known port associated with a particular service Port 7: echo server 22: ssh server 25: mail server 80: HTTP (“Web”) server A machine that runs a server process is also often referred to as a “server” Cox Networking 38

Server Examples Web server (port 80) Resource: files/compute cycles (CGI programs) Service: retrieves files

Server Examples Web server (port 80) Resource: files/compute cycles (CGI programs) Service: retrieves files and runs CGI programs on behalf of the client See /etc/services for a comprehensive list of the services available on a UNIX machine Ssh server (port 22) Resource: terminal Service: proxies a terminal on the server machine Mail server (port 25) Resource: email “spool” file Service: stores mail messages in spool file Cox Networking 39

Sockets Interface Created in the early 80’s as part of the original Berkeley distribution

Sockets Interface Created in the early 80’s as part of the original Berkeley distribution of Unix that contained an early version of the Internet protocols Provides a user-level interface to the network Underlying basis for all Internet applications Based on client/server programming model Cox Networking 40

Sockets What is a socket? To the kernel, a socket is an endpoint of

Sockets What is a socket? To the kernel, a socket is an endpoint of communication To an application, a socket is a file descriptor that lets the application read/write from/to the network • Remember: all Unix I/O devices, including networks, are modeled as files Clients and servers communicate with each other by reading from and writing to socket descriptors The main distinction between regular file I/O and socket I/O is how the application “opens” the socket descriptors Cox Networking 41

Overview of the Sockets Interface Client Server socket bind open_listenfd open_clientfd listen connect Connection

Overview of the Sockets Interface Client Server socket bind open_listenfd open_clientfd listen connect Connection request rio_writen rio_readlineb close Cox accept rio_writen EOF Networking Await connection request from next client rio_readlineb close 42

Echo Server: accept Illustrated listenfd(3) Server Client clientfd Connection request Client listenfd(3) Server clientfd

Echo Server: accept Illustrated listenfd(3) Server Client clientfd Connection request Client listenfd(3) Server clientfd listenfd(3) Client clientfd Cox Server connfd(4) Networking 1. Server blocks in accept, waiting for connection request on listening descriptor listenfd 2. Client makes connection request by calling and blocking in connect 3. Server returns connfd from accept. Client returns from connect. Connection is now established between clientfd and connfd 43

Connected vs. Listening Descriptors Listening descriptor End point for client connection requests Created once

Connected vs. Listening Descriptors Listening descriptor End point for client connection requests Created once and exists for lifetime of the server Connected descriptor End point of the connection between client and server A new descriptor is created each time the server accepts a connection request from a client Exists only as long as it takes to service client Why the distinction? Allows for concurrent servers that can communicate over many client connections simultaneously • E. g. , Each time we receive a new request, we fork a child to handle the request Cox Networking 44

Networking (video #2) Alan L. Cox alc@rice. edu Some slides adapted from CMU 15.

Networking (video #2) Alan L. Cox [email protected] edu Some slides adapted from CMU 15. 213 slides

Web History 1945: Vannevar Bush, “As we may think”, Atlantic Monthly, July, 1945 •

Web History 1945: Vannevar Bush, “As we may think”, Atlantic Monthly, July, 1945 • Describes the idea of a distributed hypertext system • A “memex” that mimics the “web of trails” in our minds 1989: Tim Berners-Lee (CERN) writes internal proposal to develop a distributed hypertext system • Connects “a web of notes with links” • Intended to help CERN physicists in large projects share and manage information 1990: Tim Berners-Lee writes a graphical browser for Next machines Cox Networking 46

Web History (cont) 1992 NCSA server released 26 WWW servers worldwide 1993 Marc Andreessen

Web History (cont) 1992 NCSA server released 26 WWW servers worldwide 1993 Marc Andreessen releases first version of NCSA Mosaic browser Mosaic version released for (Windows, Mac, Unix) Web (port 80) traffic at 1% of NSFNET backbone traffic Over 200 WWW servers worldwide 1994 Andreessen and colleagues leave NCSA to form "Mosaic Communications Corp" (became Netscape, then part of AOL) Cox Networking 47

Internet Hosts Source: Internet Systems Consortium Cox Networking 48

Internet Hosts Source: Internet Systems Consortium Cox Networking 48

Web Servers Clients and servers communicate using the Hyper. Text Transfer Protocol (HTTP) Client

Web Servers Clients and servers communicate using the Hyper. Text Transfer Protocol (HTTP) Client and server establish TCP connection Client requests content Server responds with requested content Client and server (may) close connection HTTP request Web client (browser) Web server HTTP response (content) HTTP/1. 1 is still the most widely used RFC 2616, 1999 HTTP/2, 2015 Cox Networking 49

Web Content Web servers return content to clients content: a sequence of bytes with

Web Content Web servers return content to clients content: a sequence of bytes with an associated MIME (Multipurpose Internet Mail Extensions) type Example MIME types text/html text/plain application/pdf image/gif image/jpeg Cox HTML document Unformatted text PDF document Binary image (GIF format) Binary image (JPEG format) Networking 50

Static and Dynamic Content The content returned in HTTP responses can be either static

Static and Dynamic Content The content returned in HTTP responses can be either static or dynamic Static content: content stored in files and retrieved in response to an HTTP request • Examples: HTML files, images, audio clips Dynamic content: content produced on-the-fly in response to an HTTP request • Example: content produced by a program executed by the server on behalf of the client (i. e. , search results) Bottom line: All Web content is associated with a file or program that is managed by the server Cox Networking 51

URLs Each file managed by a server has a unique name called a URL

URLs Each file managed by a server has a unique name called a URL (Universal Resource Locator) URLs for static content: http: //www. rice. edu: 80/index. html http: //www. rice. edu • Identifies a file called index. html, managed by a Web server at www. rice. edu that is listening on port 80 URLs for dynamic content: http: //www. cs. cmu. edu: 8000/cgi-bin/adder? 15000&213 • Identifies an executable file called adder, managed by a Web server at www. cs. cmu. edu that is listening on port 8000, that should be called with two argument strings: 15000 and 213 Cox Networking 52

How Clients and Servers Use URLs Example URL: http: //www. aol. com: 80/index. html

How Clients and Servers Use URLs Example URL: http: //www. aol. com: 80/index. html Clients use prefix (http: //www. aol. com: 80) to infer: What kind of server to contact (http (Web) server) Where the server is (www. aol. com) What port the server is listening on (80) Servers use suffix (/index. html) to: Determine if request is for static or dynamic content • No hard and fast rules for this • Historically executables resided in cgi-bin directory Find file on file system • Initial “/” in suffix denotes home directory for requested content • Minimal suffix is “/”, which servers expand to some default home page (e. g. , index. html) Cox Networking 53

Testing Servers Using telnet The telnet program is invaluable for testing servers that transmit

Testing Servers Using telnet The telnet program is invaluable for testing servers that transmit ASCII strings over Internet connections Our simple echo server Web servers Mail servers Usage: unix> telnet <host> <portnumber> Creates a connection with a server running on <host> and listening on port <portnumber> Cox Networking 54

Anatomy of an HTTP Transaction unix> telnet www. rice. edu 80 Trying 128. 42.

Anatomy of an HTTP Transaction unix> telnet www. rice. edu 80 Trying 128. 42. 206. 11. . . Connected to www. netfu. rice. edu. Escape character is '^]'. GET / HTTP/1. 1 Host: www. rice. edu Client: open connection to server Telnet prints 3 lines to the terminal Client: request line Client: required HTTP/1. 1 HOST header Client: empty line terminates headers HTTP/1. 1 200 OK Server: response line Date: Thu, 5 Apr 2018 <. . snip. . > Server: followed by 8 response headers Server: Apache/2. 4. 6 (Red Hat Enterprise Linux) <. . snip. . > Accept-Ranges: bytes <. . snip. . > Transfer-Encoding: chunked Content-Type: text/html; charset=UTF-8 Server: empty line (“rn”) terminates hdrs 15 e 3 Server: first line in response body <. . snip. . > Server: HTML content not shown. 0 Server: last line in response body Connection closed by foreign host. Server: closes connection unix> Client: closes connection and terminates Cox Networking 55

HTTP Requests HTTP request is a request line, followed by zero or more request

HTTP Requests HTTP request is a request line, followed by zero or more request headers Request line: <method> <uri> <version> <method> is either GET, POST, OPTIONS, HEAD, PUT, DELETE, or TRACE <uri> is typically URL for proxies, URL suffix for servers <version> is HTTP version of request (HTTP/1. 0 or HTTP/1. 1) Cox Networking 56

HTTP Requests (cont) HTTP methods: GET: Retrieve static or dynamic content • Arguments for

HTTP Requests (cont) HTTP methods: GET: Retrieve static or dynamic content • Arguments for dynamic content are in URI • Workhorse method (99% of requests) POST: Retrieve dynamic content • Arguments for dynamic content are in the request body OPTIONS: Get server or file attributes HEAD: Like GET but no data in response body PUT: Write a file to the server! DELETE: Delete a file on the server! TRACE: Echo request in response body • Useful for debugging Cox Networking 57

HTTP Requests (cont) Request headers: <header name>: <header data> Provide additional information to the

HTTP Requests (cont) Request headers: <header name>: <header data> Provide additional information to the server Major differences between HTTP/1. 1 and HTTP/1. 0 uses a new connection for each transaction HTTP/1. 1 also supports persistent connections • Multiple transactions over the same connection • Connection: Keep-Alive HTTP/1. 1 requires HOST header • Host: www. rice. com HTTP/1. 1 adds additional support for caching Cox Networking 58

HTTP Responses HTTP response is a response line followed by zero or more response

HTTP Responses HTTP response is a response line followed by zero or more response headers Response line: <version> <status code> <status msg> <version> is HTTP version of the response <status code> is numeric status <status msg> is corresponding English text • 200 • 403 • 404 OK Forbidden Not found Request was handled without error Server lacks permission to access file Server couldn’t find the file Response headers: <header name>: <header data> Provide additional information about response Content-Type: MIME type of content in response body Content-Length: Length of content in response body Cox Networking 59

Proxies A proxy is an intermediary between a client and an origin server To

Proxies A proxy is an intermediary between a client and an origin server To the client, the proxy acts like a server To the server, the proxy acts like a client HTTP request Client HTTP request HTTP response Cox Origin Server Proxy HTTP response Networking 60

Why Proxies? Can perform useful functions as requests and responses pass through Examples: Caching,

Why Proxies? Can perform useful functions as requests and responses pass through Examples: Caching, logging, anonymization Client A Request foo. html Client B Request foo. html Proxy cache foo. html Origin Server Slower more expensive global network foo. html Fast inexpensive local network Cox Networking 61

A Client’s Request Line To A Proxy GET http: //www. rice. edu/ HTTP/1. 1

A Client’s Request Line To A Proxy GET http: //www. rice. edu/ HTTP/1. 1 Host: www. rice. edu Accept: text/html, application/xhtml+xml, application/xml; q=0. 9, */*; q=0. 8 Proxy-Connection: keep-alive Upgrade-Insecure-Requests: 1 Cookie: SS_MID=4 bff 7079 -1 d 9 b-464 e-a 3 ab-bee 5762488 a 6 i 69 kf 1 o 6; __unam=bf 980 eb-15 c 0 e 074 c 94 -a 631 ba-8; _ga=GA 1. 2. 1181809510. 1416263362; _gid=GA 1. 2. 179111272. 1523312176 User-Agent: Mozilla/5. 0 (Macintosh; Intel Mac OS X 10_11_6) Apple. Web. Kit/605. 1. 15 (KHTML, like Gecko) Version/11. 1 Safari/605. 1. 15 Accept-Language: en-us Accept-Encoding: gzip, deflate Connection: keep-alive CRLF (rn) The client’s request line to a proxy must specify the full URL Cox Networking 62

For More Information W. Richard Stevens, “Unix Network Programming: Networking APIs: Sockets and XTI”,

For More Information W. Richard Stevens, “Unix Network Programming: Networking APIs: Sockets and XTI”, Volume 1, Second Edition, Prentice Hall, 1998. THE network programming bible Complete versions of the echo client and server are developed in the text Available on the course web site You should compile and run them for yourselves to see how they work Feel free to borrow any of this code Cox Networking 63

Next Time Concurrency Cox Networking 64

Next Time Concurrency Cox Networking 64

Dotted Decimal Notation By convention, each byte in a 32 -bit IP address is

Dotted Decimal Notation By convention, each byte in a 32 -bit IP address is represented by its decimal value and separated by a period • IP address 0 x 8002 C 2 F 2 = 128. 2. 194. 242 Functions for converting between binary IP addresses and dotted decimal strings: inet_pton: converts a dotted decimal string to an IP address in network byte order inet_ntop: converts an IP address in network by order to its corresponding dotted decimal string “n” denotes network representation, “p” denotes presentation representation Cox Networking 65

IP Address Structure IP (V 4) Address space divided into classes: Class A 0

IP Address Structure IP (V 4) Address space divided into classes: Class A 0 0123 Net ID Class B 1 0 Class C 1 1 0 8 Net ID 24 31 Host ID Net ID Class D 1 1 1 0 Class E 1 1 16 Host ID Multicast address Reserved for experiments Special Addresses for routers and gateways (all 0/1’s) Loop-back address: 127. 0. 0. 1 Unrouted (private) IP addresses: 10. 0/8, 172. 16. 0. 0/12, 192. 168. 0. 0/16 Dynamic IP addresses (DHCP) Cox Networking 66

Domain Naming System (DNS) The Internet maintains a mapping between IP addresses and domain

Domain Naming System (DNS) The Internet maintains a mapping between IP addresses and domain names in a huge worldwide distributed database called DNS Conceptually, programmers can view the DNS database as a collection of millions of addrinfo structures: struct addrinfo { int ai_flags; /* flags for getaddrinfo */ int ai_family; /* address type (AF_INET or AF_INET 6) */ int ai_socktype; /* the socket type */ int ai_protocol; /* the type of protocol */ size_t ai_addrlen; /* length of ai_addr */ struct sockaddr *ai_addr; /* pointer to a sockaddr struct */ char *ai_canonname; /* the canonical name */ struct addrinfo *ai_next; /* pointer to the next addrinfo struct */ }; Functions for retrieving host entries from DNS: getaddrinfo: query DNS using domain name or IP Cox getnameinfo: query DNS using sockaddr struct Networking 67

Properties of DNS Host Entries Each host entry is an equivalence class of domain

Properties of DNS Host Entries Each host entry is an equivalence class of domain names and IP addresses Each host has a locally defined domain name localhost which always maps to the loopback address 127. 0. 0. 1 Different kinds of mappings are possible: Simple case: 1 domain name maps to one IP address: • water. clear. rice. edu maps to 128. 42. 208. 6 Multiple domain names mapped to the same IP address: • www. cs. rice. edu, ececs. rice. edu, and bianca. cs. rice. edu all map to 128. 42. 128. 17 Multiple domain names mapped to multiple IP addresses: • aol. com and www. aol. com map to multiple IP addresses Some valid domain names don’t map to any IP address: • for example: clear. rice. edu Cox Networking 68
