Network Peripheral Network Peripheral u Digital Media Center

Network Peripheral

Network Peripheral u Digital Media Center IP Office ü HDMI / Video Wall over IP ü Wireless Presentation Gateway u Network Attached Storage (NAS) Servers u IP KVM u Print Server u IP Power Manager TV HDMI / Video Wall over IP 2

HDMI / Video Wall over IP IHD-200 PT / IHD-200 PR (Transmitter / Receiver) u 1080 P Ultra High Quality Video transmitter u Max. 8 x 8 screen array supported u 16 multi-casting groups u Point-to-Point, Point-to-Many and Many-to-Many broadcasting u HDCP-compliant and Blu-ray ready u HDMI with dts (2 ch. audio) u Supports Power over Ethernet u Automatic EDID (Extended Display Identification Data) configuration 3

Wireless Interactive Presentation Gateway u IEEE 802. 11 n compliant u Wireless AP and AP-client mode u Up to 30 fps network screen projection u 4 -to-1 split screen projection u VGA / 1080 p Full HD HDMI output u Audio / Video streaming u Plug & Show u Interactive Presentation with Uo. IP (USB over IP) and Mobile Apps (Web Slides, Sidepad) u Friendly web browser management WIPG-300 H 4

NAS Server 1 -Bay SATA NAS Server u 1 Standard USB 2. 0 Port for External USB HDD u Supports Windows utility and web-based management u Shares music, pictures, movies and data over network u Supports BT Download u DLNA compatible u 10/1000 Base-TX (Auto MDI/MDI-X), supports auto crossover detection u Supports most popular OS including Windows 7 / XP / Vista, MAC 10. 5 and later NAS-7103 5

IP Power Manager IP-based Switch Power Manager u Remote power control u Multiple power control methods: ü ü ü Wake on LAN System After AC Back Kill the Power u Intelligent Power-on sequencing based on event occurrence or planned schedule u Versatile sensors supported through Environmental Sensor inputs u Events notification by pop-up, sending trap or e-mail u Supports SSL and SSH protocols u IP Filter to prevent unauthorized access IPM-4220 (4 -port) IPM-8220 (8 -port) IPM-12001 (110 V) IPM-12002 (220 V) 6

IP Power Manager IP-based Meter Power Manager u 0 U size design u LCD panel displays current, max alarm, device temperature and network information u Hot-swap IP Module without power shutdown u Events notification by pop-up, sending trap or e-mail u Supports SSL and SSH protocols u IP Filter to prevent unauthorized access Hot-swap IP Module IPM-16120 7

KVM Switch 8/16 -Port Combo KVM Switch u Supports PS/2 and USB compatible mouse/trackball u Standalone machine controls up to 8/16 computers u Cascade up to 64/256 computers u Max. resolution up to 2048 x 1536 u Computer selection: Manual Key, Hotkeys and on screen display (OSD) u Desktop and 1 U size design u Remote computer control via TCP/IP protocol (For IKVM Series) KVM-210 -08 (8 -port) KVM-210 -16 (16 -port) IKVM-210 -08 (8 -port) IKVM-210 -16 (16 -port) 8

LCD KVM Switch 17" 8/16 -Port Combo VGA LCD KVM Switch u 1 U size design u Supports PS/2 and USB compatible mouse/trackball u Cascade up to 64/256 computers u Max. resolution up to 1280 x 1024 u Computer selection: Manual Key, Hotkeys and on screen display (OSD) KVM-210 -08 M (8 -port) u u Multiplatform support: Windows 2000/2003/XP/Vista/7/10, Linux, Mac, and Sun Remote computer control via protocol (For IKVM Series) KVM-210 -16 M (16 -port) IKVM-210 -08 M (8 -port) TCP/IP IKVM-210 -16 M (16 -port) 9

u View PLANET Network Peripheral products online 10
