CH 1 Introduction of Or. CAD

NAM S. B MDLAB. Electronic Engineering, Kangwon National University CAD(Computer Aided Design/Drawing) CAD Designed or Drawing using Computer Kind of CAD 건축, 토목, 기계 분야 : Auto. CAD 등 Auto. CAD is a CAD (Computer Aided Design or Computer Aided Drafting) software application for 2 D and 3 D design and drafting, developed and sold by Autodesk, Inc. 기계 분야 : Mechanical CAD 등 Electric CAD 분야 : Or. CAD, PADs 등

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Auto. CAD

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Mechanical CAD

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Auto. CAD

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Auto. CAD

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Mechanical CAD

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Example: 2 D CAD drawing

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Example: 3 D CAD model

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Or. CAD

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Or. CAD

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Or. CAD 역사 1985 : Or. CAD. co → DOS용 Electric CAD : Or. CAD 1988 : Or. CAD. co → Or. CAD III 1990 : Or. CAD. co → Or. CAD IV 1993 : Or. CAD. co → Windows 3. 1 1995 : Or. CAD. co → Windows 95 Or. CAD Capture, Simulate, Layout 1997 : Or. CAD. co → Micro. Sim. co (Pspice) + Or. CAD Cadence사가 Or. CAD. co 인수 → Or. CAD 9. 0 → Or. CAD 16. 0 → Or. CAD 20. 0

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Or. CAD 구성 Schematic Capture(Or. CAD Capture CIS) Project file ( *. opj) : Design file과 simulation 파일들의 이름 및 연결정보 Design file ( *. dsn) : Circuit file + Design cache + 도면정보 Simulation(Pspice/Simulation) PCB Layout (Layout Plus)

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Schematic Capture(Or. CAD Capture CIS)

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Simulation(Pspice/Simulation)

NAM S. B MDLAB. Electronic Engineering, Kangwon National University PCB Layout (Layout Plus)

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Or. CAD work flow Circuit Debug Input Signal Circuit Design 손으로 종이에 Schematic Capture Or. CAD capture tool Simulation Model Or. CAD Simulatione tool PCB layout Or. CAD PCB layer tool Circuit Manufacture

NAM S. B MDLAB. Electronic Engineering, Kangwon National University

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Or. CAD 전자 부품 C: Or. CAD_16. 0captureLIBRARY Discreate. olb 저항 고정저항

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Discreate. olb 저항 가변저항 Trimmer 가변저항

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Discreate. olb 저항 Array 저항 SIP type SMD type DIP type

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Discreate. olb 저항 칩 저항 1005(1%)칩저항, 1005(5%)칩저항, 1005칩저항(100개), 1608(0. 1%)칩저항 , 1608(1%) 칩저항, 1608(5%)칩저항 , 1608칩저항(100개) , 2012(0. 1%)칩저항 , 2012(1%)칩저항 2012(5%)칩저항 , 2012칩저항(100개) , 3216(5%)칩저항 , 3216칩저항(100개) 3225칩저항 , 5025칩저항(100개) , 6432칩저항 , 기타 사이즈

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Discreate. olb 케페시터(capacitor) 전해 케페시터 DIP type SMD type

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Discreate. olb 케페시터(capacitor) 세라믹 케페시터 탄탈 케페시터

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Discreate. olb 케페시터(capacitor) 모노리틱 케페시터 필림 케페시터

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Discreate. olb 케페시터(capacitor) 마일러 케페시터 가변 케페시터

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Discreate. olb 케페시터(capacitor) 칩 케페시터 005 (컷테이프) 1608 (컷테이프) 2012 (컷테이프) 3216 (컷테이프) 1005 (Reel) 1608 (Reel) 2012 (Reel) 3216 (Reel) 4532칩세라믹 3225칩세라믹 칩Array

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Discreate. olb 인덕터(Inductor) 파워 인덕터 고전압 type 차폐 type

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Discreate. olb 인덕터(Inductor) 링 코일 인덕터 에어 코일 인덕터

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Discreate. olb 인덕터(Inductor) 리드코일 인덕터 칩 인덕터

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Discreate. olb 인덕터 스위치 푸쉬 스위치

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Discreate. olb 스위치 DIP sw toggle 스위치 로터리 sw 슬라이드 sw

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Discreate. olb 다이오드 정류다이오드 발광 다이오드 브리지 다이오드

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Discreate. olb 트랜지스터 PNP type NPN type

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Connector. olb HEADER 기타

NAM S. B MDLAB. Electronic Engineering, Kangwon National University Gate. olb Digital Gate

NAM S. B MDLAB. Electronic Engineering, Kangwon National University library

NAM S. B MDLAB. Electronic Engineering, Kangwon National University

NAM S. B MDLAB. Electronic Engineering, Kangwon National University New Project

NAM S. B MDLAB. Electronic Engineering, Kangwon National University

NAM S. B MDLAB. Electronic Engineering, Kangwon National University
