MULTIPIN CONNECTOR CONNECTION RADIALL PN 691803004 Receptacle for

MULTIPIN CONNECTOR CONNECTION RADIALL P/N 691803004 Receptacle for cable and for 52 socket contacts RADIALL P/N 691802002 Plug for cable and for 52 socket contacts CERN P/N 04. 31. 52. 100. 5 Shielded 56 -conductor HV cable RADIALL P/N 691802002 Plug for cable and for 52 socket contacts RADIALL P/N A 1932 AP 691803004 Part Quantity ( ) price Ordering status 691803004 18 ( 25 ) 691802002 36 (50) , , 691804200 936 (3000) , , 691804300 1872 (3000) , , 691804230 72 (400) , , 04. 31. 52. 100. 5 30 m Required quotation to radiall 6. 6 SF Receptacle for cable and for 52 socket contacts HV Decoupler Box

External Connections and Ordering option • • Components of front pannel External connectors Output Channels(1… 48), Floating Ground(FAGND), IINT IEXT Multi connector Radiall 691803004 Type, 52 pin male( to be mated with Radiall 691802002) • FAGND Radiall R 921921 socket, 2 mm • PASSIVE INTERLOCK 00 -type LEMO connector • SIGNAL INTERLOCK 00 -type LEMO connector Ordering Option Code Description WA 1932 APAAAA A 1932 AP-SY 1527 H. V. channels+3 k. V/500 u. AMultipin Conn. (48 ch) WA 995 XAAAAAA A 995 -insertion/extraction tool Radiall 282549024 for A 996 WA 996 XAAAAAA A 996 -52 pin cable connector for A 173 XBA 183 XB-A 1932 A-A 1535 Mod. A 1932 A front pannel

Needed parts
