MONGOLIAN INTERNET EXCHANGE /MIX/ BATSAIKHAN. J CHIEF OF INFORMATION TECHNOLOGY DEVELOPMENT DIVISION. MONGOLIAN NATIONAL DATA CENTER.

Contents o Brief introduction o Evolution o Network solutions o Usage o Monitoring

1 -р хэсэг : MIX-ийн товч ойлголт Quick guide of MIXX Mongolian Internet exchange point /MIX/ is an infrastructure which creates opportunity for Internet service providers /ISP/ and their customers to exchange internet traffics, access to servers, browsing webs /in Mongolia/.

A brief history • In 2011 MIX was originally built with 1. 5 Mbps speed by Infocon LLC. Nevertheless it was liquidated by the reason of inadequacy • Later in 2002 Micom /MTC/ built, installed new equipment, ensured its service and maintenance /MCSCom Public IP/.

Newly renovated equipment 2002, Micom: Cisco Catalyst 2924 Switch 24 x 10/100 Ethernet (RJ-45) interface IEEE 802. 3, 802. 3 U, 802. 1 D changed in April, 2010 : Cisco Catalyst 3550 Switch 24 x 10/100 Ethernet ports with IEEE 802. 3 af and 2 GBIC-based Gigabit Ethernet ports

Newly renovated equipment Холболтын төхөөрөмж changed in September, 2010 : Nexus 7010 Switch: Ø 32 10 G Ethernet, 192 10/1000 Ethernet ports Ø no service interruptions even during hardware and software upgrades Ø front-to-back airflow and integrated cable management Ø fabric modules for load-balanced, faulttolerant deliver 138 Gbps per slot, 230 Gbps per slot Ø Cisco NX-OS Software Release

Network solution Layer 2 BGP

Network solution Layer 3 BGP

Usage Direct Indirect BMD HOME NET Disconnected NIT system ШУТИС Хо. МТС Mogul Service and supports

№ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 Одоогийн ашиглалт CONNECTION TYPE ORGANIZATION MICOM UNIVISION SKYMEDIA GMOBILENET WICOM DATACENTER KHULAN CONTENT MONNOT MOBICOM CITINET SANSARNET TOPNET KHANSCOM DIGICOM YOKOZUNANET RAILCOM NETCOM BOLDSOFT NIT SYSTEMS ERDEMNET MOGUL SERVICE & SUPPORT KEWIKO ISATCOM OPTINET HOMENET MAGICNET MOBINET ULUSNET GNET BMD CORE PORT CONNECTION 2 core 4 core 2 core 2 core 2 core 1 core 1 core - SFP-10 G, SFP-10 G SFP-10 G SFP-1 G, SFP-1 G SFP-1 G SFP-1 G ETH-1 G ETH-100 M ETH-1 G - Direct Direct Direct Direct Direct Direct Direct Mobicom – Indirect Boldsoft – Indirect Mobicom - Indirect Usage

Usage № 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 Internet service provider UNIVISION MOBICOM / (MOBINET, ULUSNET) SKYMEDIA CITINET MICOM GNET YOKOZUNANET KEWIKO DIGICOM G-MOBILENET MAGICNET ERDEMNET /CSMS/ NETCOM RAILCOM TOPICA SANSARNET BOLDSOFT HOMENET MOGUL S&S WICOM KHANSCOM OPTINET ISATCOM NIT SYSTEMS TELEMAX MUST-SICT ASITEL TUNAMALCOM INCOMENET DATACENTER KHULAN CONTENT MONNOT 2008 46, 3 88, 8 22, 6 84, 4 44, 3 21, 2 47, 4 0 23, 3 6, 5 12, 4 3, 9 0 14, 9 4, 7 12, 3 9, 2 4, 7 0 0 4, 2 0 0 1, 2 2, 4 2, 1 1, 5 0 0 0 Network Traffic/Mbps/ 2010 2012 106, 2 96, 8 88, 5 112, 5 98, 1 78, 6 98, 5 0 53, 2 74, 2 62, 4 59, 4 0 30. I 32, 3 35, 8 11, 5 33, 4 0 0 65, 9 18, 9 0 0 48, 1 38, 4 15, 4 13, 8 5, 3 141 0 0 192 565 98 328 140 79 292 1, 5 58 80 97 67 27 35 39 188 12 42 0 0 69 23 0 0 57 39 22 16 6 881 0 0 2015 1290 939 333 322 226 203 168 119, 4 97 97 66 60 54 50, 4 49 48 25 17, 7 17, 2 15. 5 15. 45 2. 33 2, 1 1, 7 0 0 0 1324 464 0

Usage INTERNET EXCHANGE POINT NETWORK TRAFFIC IMPROVEMENT CHART 6000 5000 4000 3000 2000 1000 0 2008 2010 2012 Old MIX /2008/ 374. 4 Mbps New MIX Static /2010/ 1323. 2 Mbps MIX Dynamic /2012/ MIX Dynamic/2015/ 2516. 7 Mbps 5798. 28 Mbps 2015

Monitoring equipment of MIX Internet exchange of Mongolia Monitoring Net. Com Cisco Nexus 7010 ISPs Source. Fire 3 D 9900 Arbor Peakflow v Port mirror configuration on Nexus 7010 v Configured by Arbor BGP

Monitoring equipment of MIX Source. Fire monitoring • Source. Fire 3 D Sensor 9900 - Sensing interface 10 G (fiber optic) x 4 • Source. Fire Defence Center 1000 • Arbor Peak. Flow 5. 0 Monitoring Cisco Nexus 7010 МIX switch

External network traffic MIX and external network traffic chart 160, 000 140, 000 External network traffic /Mbps/ 120, 000 100, 000 MIXX traffic /Mbps/ 80, 000 60, 000 Total External and MIXX traffic /Mbps/ 40, 000 20, 000 Total network capacity /Mbps/ 09 20 10 20 11 20 12 20 13 20 14 20 15 20 16 20 17 20 18 20 19 20 20 20 21 20 07 08 20 20 06 20 20 05 -

Priority Ø High speed connection between ISPs and MIX devices Ø Customers access to network servers browse websites with limitless-speed , located in Mongolia Ø Organizations can co-locate and make direct connection between their servers and MIX Ø Transit providers can backup transitions by using their network /MIX/ connection Ø Organizations can provide online game services, IP TV, Vo. IP services based on MIX Ø Also provide Web content management services /text, images, sounds, videos, animations, application/

Priority Ø ISPs, limited the speed on customer’s ports - Citinet. - Sansarnet. In other words customers pay for access to websites located in other countries to ISP. Ø Check speed: 1. Go to www. speedtest. net 2. By choosing one of the following 4 websites included in Mongolia customers can check the internet speed in Mongolia.
