Millimetre ATCA Results Vincent Minier School of Physics UNSW 21 November 2002 Millimetre Workshop

Millimetre ATCA Results Vincent Minier School of Physics UNSW 21 November 2002 Millimetre Workshop 2002, ATNF

ATCA at 3 & 12 mm – Current Status 3 mm system 12 mm

ATCA at 3 & 12 mm – Current Status 3 mm system 12 mm system Ø Frequency range: (1) 84. 906 -87. 305 GHz (2) 88. 506 -91. 305 GHz Ø Frequency range: 16 -26 GHz (no tuning needed !) Ø 3 baselines, 2 pol. : CA 02, CA 03, CA 04 Ø 15 baselines, 2 pol. : CA 01, CA 02, CA 03, CA 04, CA 05, CA 06 Ø System temperature: 250 – 400 K Ø Bandwidth : 128 MHz Ø System temperature: 60 – 70 K

First light on 30 th Nov. 2000 Orion Si. O 86. 243 GHz

First light on 30 th Nov. 2000 Orion Si. O 86. 243 GHz

Recent Results at 3 and 12 mm q Pre-planetary disks around young stars (Wilner,

Recent Results at 3 and 12 mm q Pre-planetary disks around young stars (Wilner, Bourke, Wright, Jorgensen, van Dishoeck, Wong, 2002) q Planetary water masers in extra-solar systems (Minier, Lineweaver, Burton, Purcell, Longmore, Norris, 2003) q Search for biomolecules in Sgr B 2 (Jones, Hunt, 2002) q Massive star formation in the Galactic Plane (Minier, Burton, Wong, Purcell, Hill, Longmore, Barnes, 2002 – 2003) q Late-type stars (AGB, CSE, Si. O masers) (Olofsson, Lindqvist, Wong, 2002) q Massive star formation in the LMC (N 113: Wong, Ott, Mizuno et al. , 2000 – 2002; Water vapour masers: Beasley, Claussen, Marvel & Staveley-Smith) q SNR 1987 (Manchester et al. 2002) q Molecular gas in nearby galaxies (Koribalski et al. 2001)

1. Pre-planetary disks around young stars

1. Pre-planetary disks around young stars

D. Wilner et al. , submitted Dust in Pre-planetary Disks TW Hya T Tauri

D. Wilner et al. , submitted Dust in Pre-planetary Disks TW Hya T Tauri star 41± 4 m. Jy HD 100546 Herbig Be star 36± 3 m. Jy

2. Planetary water masers in extra-solar systems

2. Planetary water masers in extra-solar systems

Water vapour masers in giant planet atmospheres HST, 336 nm Io C A E

Water vapour masers in giant planet atmospheres HST, 336 nm Io C A E Shoemaker-Levy 9 collision: 17 th July 1994 Cosmovici et al. 1996 ØSeptember 2002, Cosmovici et al. announced the detection of water masers in 4 exo-planetary systems (e. g. Eps. Eridani). ØDecember 2002, the detections were not re-confirmed with the VLA despite a sensitivity of a few m. Jy/beam.

Search for water masers toward very young “solar systems” (1 -2 Gyr) 12 mm

Search for water masers toward very young “solar systems” (1 -2 Gyr) 12 mm system Ø Frequency range: 22. 23508 GHz Ø EW 352+antenna 6 15 baselines, 2 pol. : CA 01, CA 02, CA 03, CA 04, CA 05, CA 06 Ø Tsys & sensitivity: 60 – 70 K 20 -40 m. Jy Maser?

3. Search for biomolecules in Sgr B 2

3. Search for biomolecules in Sgr B 2

Search for glycine (87 GHz) and propylene oxide (86. 7 GHz) Propylene oxide HCO+

Search for glycine (87 GHz) and propylene oxide (86. 7 GHz) Propylene oxide HCO+ No detection down to 30 m. Jy/beam. Unknown line Glycine

4. Massive star formation in the Galactic Plane

4. Massive star formation in the Galactic Plane

Galactic plane Opt FIR Methanol masers as tracers of massive star formation Dame et

Galactic plane Opt FIR Methanol masers as tracers of massive star formation Dame et al. 2001 CO

G 318. 95 -0. 20 (IRAS 14567 -5846) ATCA at 6. 7 and 8.

G 318. 95 -0. 20 (IRAS 14567 -5846) ATCA at 6. 7 and 8. 6 GHz UC HII +MSX/mid-IR Methanol maser + MSX/mid-IR IRAS source is resolved in 2 cores

G 318. 95 -0. 20 (IRAS 14567 -5846) Ø HCN, HCO+(Mopra); H 13 CO+,

G 318. 95 -0. 20 (IRAS 14567 -5846) Ø HCN, HCO+(Mopra); H 13 CO+, HC 3 N, CH 3 OH: all dense gas tracers (>105 cm-3). Ø ATCA-3 mm + EW 214 (6 – 20 arcsec). Ø 750 A resolved out or large phase errors on long baselines Ø EW 352 (bad weather) Ø RMS=80 -100 m. Jy/beam EW 214

Averaged spectra H 13 CO+ HCO+ CH 3 OH HCN

Averaged spectra H 13 CO+ HCO+ CH 3 OH HCN

Cross-correlated spectra H 13 CO+ HCO+ CH 3 OH HCN

Cross-correlated spectra H 13 CO+ HCO+ CH 3 OH HCN

G 318. 95 -0. 20 (IRAS 14567 -5846) HCO+ 60 m Core? 90 m

G 318. 95 -0. 20 (IRAS 14567 -5846) HCO+ 60 m Core? 90 m Extended emission? Wing 30 m

G 318. 95 -0. 20 (IRAS 14567 -5846) Ø The methanol masers in G

G 318. 95 -0. 20 (IRAS 14567 -5846) Ø The methanol masers in G 318. 95 -0. 20 coincide with a dense molecular core. Ø HCO+ bipolar structure = molecular outflows. Ø No UC HII region is detected. Ø G 318. 95 -0. 20 = a massive protostar? Ø CH 3 OH, HCO+ Mvir= 126(Rpc)(Dvkm/s)2= 120 – 400 M Ø ngas= 6 x 107 cm-3

Methanol masers in G 345. 01+1. 79 85. 5 GHz 86. 9 GHz All

Methanol masers in G 345. 01+1. 79 85. 5 GHz 86. 9 GHz All masers coincide in velocity and position coincide in space

Probing gas/dust conditions with methanol masers Ø Using model by Cragg et al. (2001).

Probing gas/dust conditions with methanol masers Ø Using model by Cragg et al. (2001). Ø Hot gas 200 -300 K Ø Cold dust <50 K Ø As expected for a massive protostellar core. Ellingsen et al. 2003, accepted in MNRAS

Water masers in MSF regions G 345. 01+1. 79

Water masers in MSF regions G 345. 01+1. 79

NH 3 emission (23. 7 GHz) Orion KL

NH 3 emission (23. 7 GHz) Orion KL

5. Late-type stars

5. Late-type stars

Circumstellar Shell Around R Scl Ø R Sculptoris has been inferred from SEST CO

Circumstellar Shell Around R Scl Ø R Sculptoris has been inferred from SEST CO (3 -2) observations to have a 10”-radius detached shell (Olofsson+ 1996). Ø Also, a dust shell with radius ~20” is seen in polarised scattered light (González Delgado et al 2003).

No shell emission (3 = 75 m. Jy)

No shell emission (3 = 75 m. Jy)

BIMA AGB star IRC+10216 images HCN C 3 N(9 -8) HNC Si. S(5 -4)

BIMA AGB star IRC+10216 images HCN C 3 N(9 -8) HNC Si. S(5 -4) ATCA July 2001 30 m baseline 2 pol. uncalibrated

6. Massive star formation in the LMC

6. Massive star formation in the LMC

HCO+/HCN in N 113 Chin et al. 1997 Ø SEST 58” beam Ø Tmb(HCO+)

HCO+/HCN in N 113 Chin et al. 1997 Ø SEST 58” beam Ø Tmb(HCO+) 0. 6 K Ø Flux 15 Jy Fukui et al. 2001

2002 Observations 90 m 135 m 45 m

2002 Observations 90 m 135 m 45 m

HCO+ contours over DSS image FWHM 1. 5 pc R ~ 1 pc. Dv

HCO+ contours over DSS image FWHM 1. 5 pc R ~ 1 pc. Dv ~ 5 km s-1. ØFor a virialized cloud, ignoring optical depth effects, M 200(Rpc)(Dvkm/s)2 5000 M. ØFor constant density, n. H ~ 5 x 104 cm-3.

7. SNR 1987

7. SNR 1987

12 mm continuum in SNR 1987 19 GHz continuum 3 baselines (max: 2 km)

12 mm continuum in SNR 1987 19 GHz continuum 3 baselines (max: 2 km)

8. Molecular gas in nearby galaxies

8. Molecular gas in nearby galaxies

The radio galaxy Centaurus A HCO+ absorption in Centaurus A (Wiklind & Combes 1997)

The radio galaxy Centaurus A HCO+ absorption in Centaurus A (Wiklind & Combes 1997) Observing parameters Ø 2 IFs: BW= 64 MHz 128 channels, each Ø IF 1: 89. 010 GHz IF 2: 90. 485 GHz Ø velocity range: 500 680 km/s SEST Ø EW 352: 45, 75, 120 m Wiklind & Combes 1997

HCO+ HNC

HCO+ HNC

The Circinus Galaxy Ø 10 July 2001 Ø 30 m baseline Ø HCO+(1 -0)

The Circinus Galaxy Ø 10 July 2001 Ø 30 m baseline Ø HCO+(1 -0) Ø Tsys about 350 K Ø 2 IFs, 128 MHz BW, 64 channels each Ø IF 1: 89. 110 GHz Ø IF 2: 89. 020 GHz IF 1 40 min IF 2

Recent Results at 3 and 12 mm q Pre-planetary disks around young stars (Wilner,

Recent Results at 3 and 12 mm q Pre-planetary disks around young stars (Wilner, Bourke, Wright, Jorgensen, van Dishoeck, Wong, 2002) q Planetary water masers in extra-solar systems NEXT PROPOSAL q Massive star formation in the Galactic DEADLINE : Plane (Minier, Lineweaver, Burton, Purcell, Longmore, Norris, 2003) q Search for biomolecules in Sgr B 2 (Jones, Hunt, 2002) Burton, Wong, Purcell, Hill, Longmore, Barnes, 2002 – 2003) (Minier, q Late-type stars (AGB, CSE, Si. O masers) (Olofsson, Lindqvist, Wong, 2002) JUNE th 15 q Massive star formation in the LMC (N 113: Wong, Ott, Mizuno et al. , 2000 – 2002; Water vapour masers: Beasley, Claussen, Marvel & Staveley-Smith) q SNR 1987 (Manchester et al. 2002) q Molecular gas in nearby galaxies (Koribalski et al. 2001)
