Midterm Review ICS 111 Cam Moore Information and Computer Sciences University of Hawaii, Manoa (1)

Computer Fundamentals Von Neumann Architecture Central Processing Unit Control Unit Arithmetic/Logic Unit Input Device Output Device Memory Unit Fetch, Execute cycle (2)

Two Types of Languages Machine Language • Binary • Specific to CPU High-level Programming Languages • Human readable • Java, Fortran, C++, COBOL, LISP, etc • Must be converted to Machine Language - Compiler - Interpreter (3)

High-Level Programming Languages Syntax • Strict rules about what is and isn’t allowed Semantics • The meaning of the program (What it does) (4)

Building Blocks of Programs Data – Variables • Names that refer to memory locations • Typed, what they can hold • Can change value by assignment = Instructions • Sequence of execution steps • Control Structures – loops and branches • Subroutines – named “chunks” of code (5)

Java Syntax Comments • Ignored by the computer • Very important • // - Single line • /* … */ - Multi line • /** … */ - Javadoc (6) /** * A program to display the message * "Hello World!" on standard output. * @author Cam Moore */ public class Hello. World { /** * Prints out Hello World! * @param args not used. */ public static void main(String[] args) { System. out. println("Hello World!"); } } // end of class Hello. World

Variables Program data is stored in memory Variables • Variables are not the data, but the location of the data • Variables have types <variable> = <expression> rate = 0. 07; interest = rate * principal; (7) 10001010 00110100 0111 10100100 11010010 10000110 01001111 10100000010 10100010100 111110100000 Location 1 Location 2 Location 3 10100000 x Location 4 Location 5 Location 6 Location 7 Location 8 Location 9 Location 10 Location 11 Location 12 . . . • Assignment statements Memory Location N interest

Java Primitive Types Eight primitive types • byte • short • int • long • float • double • char • boolean (8) Whole Numbers Floating Point Numbers Single Character (Unicode) true or false

Precedence Rules Highest to lowest Precedence (9) Operator Type Examples Parentheses () Unary operators ++, --, !, unary -, unary +, type-cast Multiplication and Division *, /, % Addition and Subtraction +, - Relational operators <, >, <=, >= Equality and Inequality ==, != Boolean And && Boolean Or || Ternary ? : Assignment operators =, +=, -=, *=, /=, %= Unary and assignment operators: right-to-left Rest: left-to-right

Blocks, Loops and Branches Control Structures • Control the flow of programs block while do. . while for if switch (10)

Blocks Group statements together { <statements> } Pair of curly braces { } Sequence of statements • 0 or more statements Doesn’t affect flow of control (11) Defines scope

Variable Scope: • Where a variable is usable Variables are defined in a block • Usable inside that block and all sub-blocks { int x = 3; . . . { char c = ‘!’; . . . }. . . { double c = 3 e 8; . . . }. . . • Not available outside the block } (12)

While Loop Repeat statements over and over while (<boolean-expression>) <statement> while (<boolean-expression>) { <statements> } Will loop while boolean-exression is true • Can lead to infinite loops int number = 1; while (number < 6) { // Keep going as long as number < 6 System. out. println(number); number = number + 1; // Go on to next number } (13)

do. . while Loop Similar to the while loop do <statement> // body of the loop while (<boolean-expression>); do { <statements> // body of the loop } while (<boolean-expression>); The body of the loop will run at least once (14)

The for Loop for (<initialization>; <boolean-expression>; <update>) <statement> // body of the loop for (<initialization>; <boolean-expression>; <update>) { <statements> // body of the loop } initialization done once boolean-expression is evaluated to terminate loop update is done each time through the loop <initialization>; while(<boolean-expression>) { <statements> // body of the loop <update>; } (15)

Which Loop to Use Know how many time to loop (counting) • for loop Don’t know how many times • while loop Run the body at least once • do…while loop (16)

if Statement if (<boolean-expression>) <statement-1> else <statement-2> if (<boolean-expression>) { <statements-1> } else { <statements-2> } (17) Two way branching • statement(s)-1 executed if boolean-expression is true • statement(s)-2 executed if boolean-expression is false

Multiway Branching if (<boolean-expression-1>) { <statements-1> } else if (<boolean-expression-2>) { <statements-2> } else { <statements-3> } Three-way branch • only one of the statements will execute - expression 1: true => statements-1 - expression 1: false – expression 2: true => statements-2 – expression 2: false => statements-3 (18)

switch Statement Second branching statement switch (<expression>) { case <constant-1>: <statements-1> break; case <constant-2>: <statements-2> break; . . // (more cases). case <constant-N>: <statements-N> break; default: // optional default case <statements-(N+1)> } // end of switch statement (19)

Java Exceptions Java exceptions are represented by objects of type Exception Many different subclasses of Exception • Null. Pointer. Exception • Illegal. Argument. Exception • Number. Format. Exception String str = “ 42”; int x = Integer. parse. Int(str); str = “fred”; x = Integer. parse. Int(str); The program “throws” the exception (20)

Dealing with Exceptions try. . catch try { <statements-1> } catch (<exception-class-name> <variable-name>) { <statements-2> } If statements-1 throws an exception of type exception-class-name control jumps to statements-2 Else statements-2 is skipped (21)

Arrays Very basic data structure Data structures are data items chunked together Arrays: • Items are arranged as numbered sequence - length - index starts at 0 • All the same type (22)

Array Variables String[] name. List; int[] A; double[] prices; Arrays use [] name. List[7]; A[0] = 13; prices[prices. length – 1]; Creating Arrays name. List = new String[1000]; A = new int[5]; prices = new double[100]; <array-variable> = new <base-type>[<array-length>]; (23)

Subroutines Allow us to handle complex programs Consists of instructions for a task • Grouped together • Named Can be called by the program Can be called by other subroutines Build up the complex solution (24)

Subroutine Definitions <modifiers> <return-type> <name> ( <parameter-list> ) { <statements> } modifiers • “static” and “public” return-type • The type of the returned value or void parameter-list • Information passed into the subroutine • <type> <parameter-name> pairs separated by commas (25)

Access Specifiers public • Usable by all none • Usable by “package” classes private • Usable only by the same class Choose either public or private* (26)

Calling Subroutines For static subroutines • in the same class <subroutine-name>(<parameters>); • in a different class <class-name>. <subroutine-name>(<parameters>); (27)

Parameters Mechanism for passing information to subroutines Part of the interface • Type • Number • Order Get values from outside the subroutine (28)

Formal and Actual Parameters Formal • Parameters in subroutine definition • Type • Name public static void do. Task(int N, double x, boolean test) { // statements to perform the task go here } Actual • Values set by calling subroutine do. Task(17, Math. sqrt(z + 1), z >= 10); (29)

Three Types of Variables Local • Declared inside a subroutine • Available to the subroutine only Parameters • Set outside the subroutine • Like local variables in the subroutine Global • Declared outside subroutines • Available to all* (30)

Return Values Subroutines that returns a value is called a function Functions can only return a value of a specified type <modifiers> <return-type> <name> ( <parameter-list> ) { <statements> } Java uses the return statement return <expression>; The type of the expression must match the function definition (31)

Java Packages Java groups classes into packages Packages can contain • Classes • Other packages “sub-packages” Two major packages • javax (32)

Using Classes from Packages Two ways to use a class from another package • Use the full name of the class java. awt. Color rect. Color; • Import the class package edu. uhm. ics 111; import java. awt. Color; public class Example { private static Color rect. Color; . . . } (33)
