Microsoft Ignite NZ 25 -28 October 2016 SKYCITY, Auckland

Journey to Cloud with Cloud PBX for Enterprise Voice Planning the UC Rollout that’s right for your organisation M 300 Vakhtang Assatrian APAC Skype for Business Technical Specialist Microsoft Global Team

Azure AD Cloud Identity Cloud Authentication Zero on-premises servers Azure AD Synchronised Identity Cloud Authentication Azure AD Connect Federated Identity ADFS Directory sync with password sync Federation On-premises identity Private AD Azure AD Connect Directory sync Private AD On-premise Authentication Single sign-on

Skype for Business Deployment Choices Online Cloud PBX in Office 365 PSTN services provided by Microsoft Hybrid Users online or on-premises Integration with PSTN services on-premises On Premises End-user features & customer PSTN services integrated onpremises

Skype for Business Server On Premise Single AD Forest Voice Gateway internet AD User Forest Skype for Business infrastructure

Skype for Business Server On Premise Resource Forest Sync Server Voice Gateway AD Resource Forest Directory Synchron isation One-way Trust internet AD User Forest Skype for Business infrastructure

Skype for Business Server On Premise Resource Forest | Service Provider provider Sync Server Voice Gateway AD Resource Forest Directory Synchron isation One-way Trust internet AD User Forest provider Skype for Business infrastructure

Skype for Business Server On Premise provider Single Forest | Service Provider AD User Forest Voice Gateway internet AD User Forest provider Skype for Business infrastructure

Deployment | Skype for Business Online * ** * Qo. S is supported over Express Route ** please refer to AAD Connect for Resource forest support *** please refer to feature comparison slide, more features in development

Deployment | Skype for Business Online ADFS Tenant Azure AD internet AD Azure Active Directory (AAD) connect AD User Forest Sf. B Online Edge Server Sf. B Online Front End Server

Deployment | Skype for Business Hybrid

Skype for Business Hybrid Single Forest Voice AAD Connect Voice Gateway Tenant Azure AD internet ADFS Sf. B Online Edge Server Sf. B Online Front End Server Skype for Business infrastructure AD User Forest

Skype for Business Hybrid provider Single Forest | Service Provider AD User Forest Voice AAD Connect Voice Gateway Tenant Azure AD internet AD User Forest ADFS Sf. B Online Edge Server Sf. B Online Front End Server provider Skype for Business infrastructure

Skype for Business Hybrid provider Resource Forest Sync Server AAD Connect AD Resource Forest Voice Directory Synchron isation Voice Gateway Tenant Azure AD 2 -way Trust internet AD User Forest ADFS Sf. B Online Edge Server Sf. B Online Front End Server provider Skype for Business infrastructure

Public Cloud HYBRID There are no RIGHT or WRONG choices. Choices will be based on what works best for customer Start with reviewing Usage Profiles & Workloads/Capabilities Private Cloud

Public Cloud Microsoft Federation IM&P Microsoft PSTN Conf ACP Conferencing Microsoft PSTN Local Voice Trunks Cloud PBX Private Cloud IM&P Microsoft Federation XMPP Federation Conferencing Local Voice Trunks Enterprise Voice Local Voice Trunks

Express Route Internet WAN

Personalized Greeting Message waiting indicator Reply to voicemail with call

Tenant Admin with Power. Shell Call Detail Records Call Quality Dashboard Multiple Emergency numbers Rate my Call Reporting Unassigned number handling

Call answer / initiate (by name & number) Call hold / retrieve Call History Call Delegation & Call On-behalf **Call Queuing & Routing Call Transfer (Blind, Consult & Mobile) Camp-on Caller ID Call Waiting Call forwarding & simul-ring Clients for PC, Mac & Mobile Device switching Distinctive ringing Do-not-disturb routing & call blocking Enterprise calendar call routing Financially-backed SLA Integrated dial-pad Music on Hold **Organizational Auto Attendant Qualified IP Desk Phones Skype & Federated calling Team calling Video call monitor Voice Mail **Coming to preview in October!

Express Route WAN Internet Voice Gateway PSTN Calling delivered by Microsoft On-Premise PSTN Connectivity

Existing Customer Server Pool New Customer Server Pool Cloud Connector Edition Partner Appliance Connect existing topology to Office 365 using Split Domain & migrate users to Cloud PBX. Deploy Skype for Business Server and connect it with Office 365. Packaged VMs on Customer Hardware provides PSTN connectivity components with Office 365. Partner offering where required Skype for Business Server software or VMs packaged with SBC/Gateway. Cloud PBX user’s PSTN Traffic transits pool. Customers can operate additional services on-prem (VIS, etc. ) Cloud PBX users PSTN Traffic transits VMs

Server Pool Signalling / Media Express Route Sf. B Online user Sf. B Server user WAN Internet Voice Hybrid Offering Voice Gateway Deployment integrated with Office 365 using split domain. Users log into Office 365, services delivered from cloud. Media Path PSTN calls connect through on-premises hardware. Standard Direct SIP Connectivity to Next Hop SIP Peer (Gateway/SBC/PBX). Skype for Business hybrid is a requirement to enable Cloud PBX with On. Premise PSTN Connectivity when Sf. B Server pool is deployed On-Prem Skype for Business infrastructure

Cloud Connector Sf. B Online user Express Route Signalling / Media WAN Internet Voice Gateway Voice Skype for Business software deployed on-premises. Cloud Connector Edition delivered as Packaged VMs for rapid deployment Current customers can use their existing topology / pool and reduce size of footprint. On. Prem Cloud Connector Edition Edge Server: Access Edge; SIP Stack, Media Relay, MRAS, Outbound Routing CMS Server, Mediation Server Domain Controller Server Cloud Connector Edition

No on-premises Skype For Business Deployment Qualified next-hop SIP Peer: IP-PBX, SIP Trunk, SBC or Gateway Hosts located in the DMZ CPU 500 Simultaneous Calls 64 -bit dual processor, six core, 2. 50 gigahertz (GHz) or higher 50 Simultaneous Calls Intel i 7 4790 quad core RAM 64 GB ECC RAM 32 GB DDR 3 -1600 non-ECC Four 600 GB 10 K RPM 128 M Cache SAS 6 Gbps disks, RAID 5 Three 1 Gbps Ethernet High throughput network adapters Two 1 TB 7200 RPM SATA III (6 Gbps) in RAID 0 Disk Network Two 1 Gbps Ethernet Stand-alone capacity estimated with 70% Internal Users, 30% External users Multiple Packaged VM sets can be stacked for greater scale.

Summary • • Cloud, Identity and Authentication Deployment Choices: On Prem | Online | Hybrid Usage Profiles & Workloads/Capabilities Cloud PBX is ready with On Prem PSTN Calling • Try at http: //aka. ms/E 5 Trial
