FLOWLINE SOLUTIONS / RISERTEC Flowline Solutions and Riser. Tec have developed the ultimate cost effective EWT and rapidly deployed early production solutions. Flowline and Riser. Tec offer total EPC for the required system (design, engineer, install, commission and handover) to suit Clients requirements. Flowline and Riser. Tec have partnered with world leading hose Manufacturer Manuli Hydraulics to deliver unrivalled expertise, along with the best results in design and cost effectiveness.

KEY BENEFITS OF OUR APPROACH ü ü ü ü Up to 50% less expensive than competitive systems Fast Track Development – Typically less than 4 months Combined Mooring and Production systems possible Deployed by DP vessel of opportunity Can be redeployed and moved easily Operating Pressure up to 175 Bar for 6 in hose Hoses in 300 m lengths can be joined to make flowlines of up to 6+ kms

Flexible Pipe Types – Bonded Flexible Comparison with Unbonded Flexibles/Rigid Pipeline ü ü ü ü Lightweight Construction Lower Minimum Bend Radius Kink Recoverable Hose Easily Repairable Easy to Deploy and Retrieve Floating Options Rapidly Installed High Elasticity

Hose Systems – Benefits versus Rigid Pipe § Deployment cost reduced - DP 1 Vessel § Procurement Lead Time reduced § Hose is recoverable and reusable § Dynamic Applications for hose § Reduced sensitivity to spanning and VIV § Dynamic riser installed along with flowline Project timescales vastly reduced and wider range of applications

Flowline Hose Systems – Marginal Field Example

Flowline and Hose Systems – Extended Well test

Integrated Services to Clients – Field Development § Full Field Development Solution § Design and Installation of Riser/Flowline System § Installation using specialist installation team § Interfaces are removed § Design Track record and knowledge of specialist product § Dn. V/Lloyds Certification of Design if required Ø Specialist Subcontractors Deliver Complete System Design and Installation cost effectively Ø It is possible to install long lengths of hose e. g. 6 Km+ Ø Extensive Project Performance History Ø Complete System - Design, Fabrication and Installation, Certification and Operating Procedures

Integrated Services to Clients – Field Development

Services to Clients – Field Development - Design Flowline Solutions Riser System Design Specialist § ISO 9001 -2015 Certified Design of Riser/Flowline/Moorings § International Track Record and Client Base including: Total, BP, Shell, Petronas, Petrobras, Exxon. Mobil, Conoco. Phillips § Principles (FS & RT) have worked together for over 10 years § Track record and in-depth knowledge of Manuli products and behaviour § Dn. V Certification of Design or Design Verification Report if required § Design & Manufacture PU Components and bend stiffeners in-house

Integrated Services to Clients – Field Development Flowline Solutions & Riser. Tec – The Difference ü Core Values of Integrity, Financial Discipline, Respect for People and Environment providing Excellence, Honesty and Ownership of Projects ü Our goal is to provide Projects on Time, on Budget to international specifications and standards by provision of truly integrated Engineering and Project Management Right First Time
