Magnetic Force/Field

Magnetic Force/Field

Magnetic Field • North/South Pole • Opposites attract • Unit: Tesla (T) • Field

Magnetic Field • North/South Pole • Opposites attract • Unit: Tesla (T) • Field lines point in direction that a North Pole would feel a force

Earth behaves magnetically as if a bar magnet was located near its center

Earth behaves magnetically as if a bar magnet was located near its center

Magnetic Force on a moving Charge • 1. Charge must be moving • 2.

Magnetic Force on a moving Charge • 1. Charge must be moving • 2. Velocity must have a component perpendicular to the direction of the magnetic field Direction of Force is perpendicular to both velocity and field RHR #1 Fingers = B Field Thumb = velocity or current Palm = Force

Why? (such a weird direction)

Why? (such a weird direction)

What happens near the poles where the charges are not deflected?

What happens near the poles where the charges are not deflected?

Force on a moving Charge F = B * qo(v sin θ) (N) •

Force on a moving Charge F = B * qo(v sin θ) (N) • What is the force on a 2μC charge moving at 4. 3 x 104 m/s perpendicular to a 0. 4 T magnetic field?

A proton (m= 1. 67 x 10 -27 kg, q= 1. 6 x 10

A proton (m= 1. 67 x 10 -27 kg, q= 1. 6 x 10 -19 C) is moving with a velocity, v= 6. 3 x 10 -5 m/s, and enters a region with a magnetic field of 0. 4 T. What is the radius of the circle that the charge will move through? What is the final velocity of the charge?

Force on a current in a wire: F = I l B sin(θ) •

Force on a current in a wire: F = I l B sin(θ) • A square loop (10 cm) of wire has a current of 5 A flowing clockwise and is placed in a 0. 4 T magnetic field directed into the page. What is the magnitude and direction of the force on each segment of the loop? X X X X X X X X

Torque on a loop: t = N I A B sin(φ) • A square

Torque on a loop: t = N I A B sin(φ) • A square loop (10 cm) of wire has a current of 2 A flowing clockwise and is placed in a 0. 75 T magnetic field directed to the right. What is the magnitude and direction of the torque on the loop?

A square loop (10 cm) of wire has a current of 2 A flowing

A square loop (10 cm) of wire has a current of 2 A flowing clockwise and is placed in a 0. 75 T magnetic field as shown below. What is the magnitude and direction of the torque on the loop? Top view 60 o
