LHC Injectors Upgrade project Malika Meddahi, Giovanni Rumolo J. Coupard, H. Damerau, A. Funken, B. Goddard, S. Gilardoni, K. Hanke, A. Lombardi, D. Manglunki, S. Mataguez, B. Mikulec, S. Prodon, E. Shaposhnikova, M. Vretenar With contributions from H. Bartosik, V. Kain Table of contents: • • 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review Methodology Outcomes of the 2015 Cost and Schedule review Organisational changes Baseline beam parameters evolution Injectors chain reports Schedule / Safety / Resources Summary LIU Project - Malika Meddahi, Giovanni Rumolo 3

Methodology All LIU-machine activity leaders will present: • • Outcomes of the 2015 CSR Baseline changes since 2015 CSR (e. g. beam parameters, strategy endorsed on hardware choice. . . ) Status of the work progress on the main activities Status on the mandatory LIU related CONSolidation items Summary of the Risks and Mitigations Cost (M+P) evolution Schedule Summary and next steps 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 4

March 2015 : Outcomes of the Cost and Schedule review Findings LIU is a collection of upgrade projects with a material budget of 186 MCHF (excluding LINAC 4, ) total manpower resources of 691 FTE-yrs CERN staff and 194 FTE-yrs of “associate” labor. As a project it started around 2011 and expected completion is around 2019. Yearly expense last year was about 13 MCHF; the maximum planned yearly expense is about 42 MCHF. Comments High priority has to be given to accelerate the project progress. LIU yearly material expenditure is similar to the LHC consolidation effort (CONS). The identification of the scope as part of either LIU or CONS is not complete and also sometimes arbitrary. Scope definition of LIU is not complete for the ion program and only partially complete for SPS. There is a consistent concern by work package coordinators about availability of manpower resources. Design performance for proton beams corresponds to 85% of the HL-LHC luminosity goal with the appropriate expectation that 100% will be reached during commissioning and early operation. Equipment performance requirements should be based on reaching 100% of HL-LHC luminosity. Dispatched at the level of the LIU-machines. 2016 Chamonix recommendations: • Match the LIU beam parameter goals and the HL-LHC requirements to each other. • Secure adequate human resources to support the design, testing and 17 -19 October 2016 commissioning LIU Project - Malika Meddahi, of the large number of RF and LLRF systems for the LIU / HL-LHC Cost Giovanni Rumolo and Schedule Reviewinjectors. Recommendations 5

2015 to 2016 Project Life Cycle Executing, Monitoring, Controlling Planning & Costing CSR 2015 • Develop Work Breakdown Structure • Assign resources • Gather estimates • Schedule CSR 2016 2017 Closing Commissioning Operate LS 2 Installation CSR 2018 2019 • Manage change • Follow up on tasks and enforce schedule • Manage risks and issues • Manage scope • Communicate • Manage performance CSR 2020 • • 2021 Lessons learned Handoffs Close project Achieve progressively beam specification (Operation and LIU activity leaders) Simulation, beam test studies, equipment specification, design, and procurement, installation, tests 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 6

2015 project organisation Accelerators and Technology Sector Director : Frédérick BORDRY LIU Project Leader Deputy Project Leader Linac 4 Project LIU Project Safety Officer A. FUNKEN LIU Project Team Project Leader M. VRETENAR Deputy Project Leader A. LOMBARDI J. COUPARD, A. FUNKEN, S. GILARDONI, B. GODDARD, K. HANKE, M. MEDDAHI, G. RUMOLO, M. VRETENAR http: //linac 4 -project. web. cern. ch/linac 4 -project/ LIU PSB Coordination Malika MEDDAHI Giovanni RUMOLO LIU PS Coordination Activity coordinator: K. HANKE Deputy coordinator: B. MIKULEC Activity coordinator: S. GILARDONI Deputy coordinator: H. DAMERAU Coordination meeting on Thursdays at 10: 30 https: //espace. cern. ch/liu-project/liu-psb/ Coordination meeting on Tuesdays at 15: 30 https: //espace. cern. ch/liu-project/liu-ps/ LIU SPS Coordination Activity coordinator: B. GODDARD Deputy coordinator: E. SHAPOSHNIKOVA Coordination meeting on Wednesdays at 10: 30 https: //espace. cern. ch/liu-project/liu-sps/ LIU IONS Coordination Activity coordinator: S. GILARDONI Deputy coordinator: D. MANGLUNKI Coordination meeting on Thursdays at 10: 30 https: //espace. cern. ch/liu-project/liu-ions/ LIU Planning & Installation Coordination Activity coordinator: J. COUPARD Deputy coordinator: S. MATAGUEZ Coordination meeting on Thursdays at 16: 00 https: //espace. cern. ch/LIUPLI/ 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 7

2016 project organisation Accelerators and Technology Sector Director : Frédérick BORDRY Coordination of all injectors chain activities LIU Project Leader Deputy Project Leader Linac 4 Project LIU Project Team Project Leader M. VRETENAR Deputy Project Leader A. LOMBARDI J. COUPARD, A. FUNKEN, B. GODDARD, K. HANKE, M. MEDDAHI, G. RUMOLO, R. SCRIVENS, M. VRETENAR http: //linac 4 -project. web. cern. ch/linac 4 -project/ LIU PSB Coordination Malika MEDDAHI Giovanni RUMOLO LIU PS Coordination Activity coordinator: K. HANKE Deputy coordinator: B. MIKULEC Activity coordinator: K. HANKE Deputy coordinator: H. DAMERAU Coordination meeting on Tuesdays at 16: 00 https: //espace. cern. ch/liu-project/liu-psb/ Coordination meeting on Tuesdays at 16: 00 https: //espace. cern. ch/liu-project/liu-ps/ LIU SPS Coordination Activity coordinator: B. GODDARD Deputy coordinator: E. SHAPOSHNIKOVA Coordination meeting on Wednesdays at 9: 00 https: //espace. cern. ch/liu-project/liu-sps/ LIU Project Safety Officer A. FUNKEN LIU Beam Parameters coordination Activity coordinator: G. RUMOLO Deputy coordinator: H. BARTOSIK LIU ions PS injectors coordination Activity coordinator: R. SCRIVENS Deputy coordinator: D. MANGLUNKI Coordination meetings on Thursdays at 10: 30 https: //espace. cern. ch/liu-project/liu-ions/ LIU Planning & Installation Coordination Activity coordinator: J. COUPARD Deputy coordinator: S. MATAGUEZ Coordination meeting on Thursdays at 16: 00 https: //espace. cern. ch/LIUPLI/ 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 8

2016 LIU ions organisation LIU IONS coordinator for HL-LHC project LIU IONS M. MEDDAHI, G. RUMOLO LIU Beam Parameters coordination Activity coordinator: G. RUMOLO Deputy coordinator: H. BARTOSIK LIU IONS PS Injectors coordination (Source – Linac 3 – LEIR) Activity coordinator: R. SCRIVENS Deputy coordinator: D. MANGLUNKI J. JOWETT LIU IONS PS coordination Activity coordinator: K. HANKE Deputy coordinator: H. DAMERAU LIU IONS SPS coordination Activity coordinator: B. GODDARD Deputy coordinator: E. SHAPOSHNIKOVA LIU Planning & installation coordination Activity coordinator: J. COUPARD Deputy coordinator: S. MATAGUEZ 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 9

2016 project organisation Accelerators and Technology Sector Director : Frédérick BORDRY LIU Project Resources planning S. PRODON Project Leader Deputy Project Leader LIU Project Safety Officer A. FUNKEN Malika MEDDAHI Giovanni RUMOLO LIU HSE–SEE coordinator C. Pinto Linac 4 Project LIU Project Team Project Leader M. VRETENAR Deputy Project Leader A. LOMBARDI J. COUPARD, A. FUNKEN, B. GODDARD, K. HANKE, M. MEDDAHI, G. RUMOLO, R. SCRIVENS, M. VRETENAR http: //linac 4 -project. web. cern. ch/linac 4 -project/ LIU PSB Coordination LIU PS Coordination Activity coordinator: K. HANKE Deputy coordinator: B. MIKULEC Activity coordinator: K. HANKE Deputy coordinator: H. DAMERAU Coordination meeting Tuesdays at 16: 00 https: //espace. cern. ch/liu-project/liu-psb/ Coordination meeting on Tuesdays at 16: 00 https: //espace. cern. ch/liu-project/liu-ps/ LIU SPS Coordination Activity coordinator: B. GODDARD Deputy coordinator: E. SHAPOSHNIKOVA Coordination meeting on Wednesdays at 9: 00 https: //espace. cern. ch/liu-project/liu-sps/ LIU HSE-RP coordinators R. Froeschl, H. Vincke, J. Vollaire LIU Beam Parameters coordination Activity coordinator: G. RUMOLO Deputy coordinator: H. BARTOSIK LIU ions PS injectors coordination Activity coordinator: R. SCRIVENS Deputy coordinator: D. MANGLUNKI Coordination meetings on Thursdays at 10: 30 https: //espace. cern. ch/liu-project/liu-ions/ LIU Planning & Installation Coordination Activity coordinator: J. COUPARD Deputy coordinator: S. MATAGUEZ Coordination meeting on Thursdays at 16: 00 https: //espace. cern. ch/LIUPLI/ 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 10

2016 overall project organisation Accelerators and Technology Sector Director : Frédérick BORDRY HL-LHC & LIU Executive Committee Linac 4 Project Leader M. VRETENAR Deputy Project Leader A. LOMBARDI LIU Project Leader Deputy Project Leader Malika MEDDAHI Giovanni RUMOLO HL-LHC Project Leader Deputy Project Leader Lucio ROSSI Oliver Bruning LIU Project Team J. COUPARD, A. FUNKEN, B. GODDARD, K. HANKE, M. MEDDAHI, G. RUMOLO, R. SCRIVENS, M. VRETENAR 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 11

LIU Workpackages 2016 WBS LIU PSB coordination Activity coordinator: K. HANKE Deputy coordinator: B. MIKULEC LIU PS coordination Activity coordinator: K. HANKE Deputy coordinator: H. DAMERAU Bi-weekly alternate Coordination meetings on Tuesdays at 16: 00 https: //espace. cern. ch/liu-project/liu-psb/ https: //espace. cern. ch/liu-project/liu-ps/ LIU SPS coordination Activity coordinator: B. GODDARD Deputy coordinator: E. SHAPOSHNIKOVA LIU Ion PS Injectors coordination Activity coordinator: R. SCRIVENS Deputy coordinator: D. MANGLUNKI Coordination meeting on Wednesdays at 9: 00 https: //espace. cern. ch/liu-project/liu-sps/ Coordination meeting on Thursdays at 10: 30 https: //espace. cern. ch/liu-project/liu-ions/ LIU-PSB 1 Management K. Hanke, Deputy B. Mikulec LIU-PS 1 Management K. Hanke, Deputy H. Damerau LIU-SPS 1 Management B. Goddard, Deputy E. Shaposhnikova LIU-ION 1 Management R. Scrivens, Deputy D. Manglunki LIU-PSB 2 PSB Beam dynamics E. Benedetto LIU-PS 2 Beam dynamics G. Sterbini, E. Metral LIU-SPS 2 Beam dynamics E. Shaposhnikova LIU-ION 2 Beam dynamics H. Bartosik LIU-PSB 3 Magnets A. Newborough LIU-PS 3 Magnets D. Bodart LIU-SPS 3 Magnets J. Bauche LIU-ION 3 Magnets B. Bodart LIU-ION 4 LIU-PSB 4 RF systems A. Findlay LIU-PS 4 RF systems H. Damerau, C. Rossi, A. Blas, A. Butterworth LIU-SPS 4 RF systems P. Baudrenghien, E. Montesinos, W. Hofle, T. Bohl, A. Butterworth LIU-PSB 5 Power Convertors S. Pittet LIU-PS 5 Power Converters S. Pittet LIU-SPS 5 Power Convertors S. Pittet LIU-ION 5 Power Convertors LIU-PSB 6 Beam instrumentation J. Tan LIU-PS 6 LIU-SPS 6 L. Jensen LIU-ION 6 LIU-PSB 7 Beam Intercepting Devices D. Grenier, Alt. A. Masi Beam instrumentation LIU-PS 7 LIU-SPS 7 Beam loss control V. Kain LIU-ION 7 Ion dumps & stoppers A. Perillo Marcone P. Cruikshank LIU-ION 8 Vacuum System J. Hansen B. Goddard LIU-ION 9 N. A. LIU-PSB 8 Vacuum System J. Hansen LINAC 4 to PSB transfer line W. Weterings and PSB injection systems PSB Extraction system LIU-PSB 10 J. Borburgh and PSB-PS transfer line LIU-PSB 9 Beam A. Guerrero instrumentation Beam Intercepting F-X. Nuiry Devices LIU-PS 8 Vacuum System J. Hansen LIU-SPS 8 LIU-PS 9 Injection Electron cloud mitigation deployment Beam transfer systems Radio Frequency for ions W. Hofle J. M. Cravero Beam instrumentation E. B. Holzer for ions J. Borburgh LIU-SPS 9 Extraction and LIU-PS 10 transfer J. Borburgh LIU-SPS 10 Vacuum System J. A. Ferreira Somoza LIU-ION 10 Controls A. Dworak P. Lelong, J. Devine LIU-PSB 11 Controls J. Betz LIU-PS 11 Controls M. Gourber-Pace LIU-SPS 11 Controls M. Gourber-Pace LIU-ION 11 Electrical Systems LIU-PSB 12 Electrical Systems J. Devine LIU-PS 12 Electrical Systems J. Devine LIU-SPS 12 Electrical Systems J-P. Sferruzza LIU-ION 12 Cooling and Ventilation S. Deleval LIU-PSB 13 Cooling and Ventilation S. Moccia LIU-PS 13 C. Bertone LIU-SPS 13 M. Battistin LIU-ION 13 I. Rühl LIU-ION 14 Civil Engineering L. A. Lopez-Hernandez R. F. Morton LIU-ION 15 Radiation Protection R. Froeschl LIU-PSB 14 Installation, Transport and handling C. Bertone, J-L. Grenard Cooling and Ventilation Installation, LIU-PS 14 Transport and handling C. Bertone Cooling and Ventilation Installation, LIU-SPS 14 Transport and handling Installation, Transport C. Bertone and handling LIU-PSB 15 Civil Engineering L. A. Lopez. Hernandez LIU-PS 15 Civil Engineering LIU-PSB 16 Radiation Protection R. Froeschl LIU-PS 16 Radiation Protection J. Vollaire LIU-SPS 16 Radiation Protection H. Vincke LIU-ION 16 Machine Interlocks R. Mompo, J. Uythoven LIU-PSB 17 Machine Interlocks B. Puccio LIU-PS 17 Machine Interlocks B. Puccio LIU-SPS 17 Machine Interlocks J. Uythoven LIU-ION 17 Alarms N. A. LIU-PSB 18 Alarms N. A. LIU-PS 18 Alarms S. Grau LIU-SPS 18 Alarms N. A. LIU-ION 18 Access Systems, Doors N. A. LIU-PSB 19 Access Systems, Doors N. A. LIU-PS 19 R. Nunes LIU-SPS 19 T. Ladzinski LIU-ION 19 Survey T. Dobers P. Bestmann Specific machine and LIU-ION 20 commissioning coordinators D. Manglunki / G. Bellodi LIU-ION 21 Dismantling N. A LIU-ION 22 Source developments D. Küchler / G. Bellodi LIU-ION 23 Operation G. Bellodi / D. Manglunki Access Systems, Doors LIU-PSB 20 Survey T. Dobers LIU-PS 20 Survey Commissioning and LIU-PSB 21 Operation B. Mikulec LIU-PS 21 LIU-PSB 22 Dismantling K. Hanke LIU-PS 22 Dismantling Half-Sector Test, LIU-PSB 23 Stripping Foil Test B. Mikulec L. A. Lopez-Hernandez T. Dobers Access Systems, Doors LIU-SPS 20 Survey Commissioning and R. Steerenberg Operation K. Hanke LIU-SPS 15 Civil Engineering LIU-SPS 21 Commissioning and K. Cornelis, V. Kain Operation LIU-SPS 22 Dismantling B. Goddard Complete LIU Work Breakdown Structure : EMDS Id 1146814 - LIU-PM-QA-0007 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 12

2015 to 2016 LIU activity Coordination Meeting summary notes and all documentations in INDICO (conference tool management) and EDMS (Engineering Data Management System) 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 13

2016 LIU / groups coordination Since January 2016, reflecting the LIU executing phase: LIU management meeting one group, reoccurring every 3 months, as needed. Scope of the meeting: review the planned DEPT/GROUP activities for the LIU project and cover the following questions: • Does DEPT/GROUP have all needed information from LIU (all requests? specifications? Timeline? ) • Are DEPT/GROUP preparatory activities within the expected timeline to meet the LIU installation schedule ? • Has all the LIU required work declared in PLAN? • Are the LIU EVM timeline and budget correct? • Are the DEPT/GROUP CONSolidation items links to the operation of LIU approved, in time and within specification? • Are all dependencies on other groups defined? 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 14

2016 LIU / groups coordination 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 15

2016 LIU beam parameters meetings Motivation: • LIU beam parameters calculated under a set of assumptions o o • Necessary for both protons and ions to: o o • To be validated/checked with simulation and/or machine studies Linked to the baseline programme and deliverables Steer the necessary LIU simulations and machines studies, and analyse the resulting impact on the LIU parameter throughout the injectors chain When necessary adjust/revise the parameter tables and release new versions for official use (with due communication to HL-LHC colleagues and following endorsement by LIU/HL-LHC executive committee) Meetings ~once a month 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 16

LIU ion beam parameters updates Since 2015 C&SR: - Post LS 2 operational scenario clarified - Extensive LEIR study program in Nov. - Dec. 2015, continuing in 2016 - Important results, used as foundation for the post LS 2 LIU beam parameters projection - Documentation: - LIU beam specs in answer to HL-LHC requirements – EDMS 1581381 April 2016: LIU Technical Design Report - Vol. II : Ions was published – EDMS 1626950 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 17

2015 to 2016 LIU ions beam parameters 2016 achieved N (x 108 ions/b) e (mm) Bl(ns) Number of bunches 2. 2 1. 5 518 2015 LIU reach (as at CSR) had to be clarified 2016 LIU reach 1. 7 1. 3 1280 HL-LHC request 2. 1 1. 3 1248 Very close to HL-LHC request - - Provide 85% of the desired integrated luminosity – up to ~95% if we assumed higher LHC performance efficiency (e. g. 62%, as achieved in 2015, instead of 50%) SPS slip stacking remains a high risk item 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 18

2015 to 2016 LIU ions beam parameters Since 2015 C&SR recommendations: Updates to baseline (following internal and external reviews) • • • ⇒ - Finemet cavities fully endorsed for both PSB (to replace all RF systems) and PS (for longitudinal feedback) Decision to rely on SPS scrubbing and applying a-C coating to one sextant only Inclusion of SPS longitudinal impedance reduction Increase of the SPS intensity limitation due to beam loading and longitudinal instability Detailed analysis of all performance limitations (simulations and machine studies), including exploitation of the new hardware where possible • • • PSB brightness line with Linac 4 PS space charge and intensity limitation Beam losses and stability in the SPS 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 19

2015 performance reach Budget PS SPS Beam losses 5% 10% Emittance blow-up 5% 10% white area accessible LIU reach HL-LHC request Based on 2012 experience • Present baseline • • • 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo Linac 4 + 160 Me. V PSB injection 2 Ge. V PS injection energy 200 MHz SPS RF upgrade Electron cloud mitigation Upgrade of protection devices & SPS beam dump 20

Performance reach: evolution Budget PS SPS Beam losses 5% 10% Emittance blow-up 5% 10% white area accessible HL-LHC request Based on 2012 experience • Present baseline • • Linac 4 + 160 Me. V PSB injection 2 Ge. V PS injection energy 200 MHz SPS RF upgrade Scrubbing + partial (staged) SPS a. C coating • Upgrade of protection devices & SPS beam dump SPS longitudinal impedance reduction - added after recommendation from last C&S review with the goal of matching LIU baseline with HL-LHC 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 21

Performance reach: evolution white area accessible HL-LHC request Budget PS SPS Beam losses 5% 10% Emittance blow-up 5% 10% Based on 2012 experience • Present baseline • Linac 4 + 160 Me. V PSB injection Critical points being addressed with machine studies • 2 Ge. V PS injection energy • Space charge • 200 MHz SPS RF upgrade o Brightness in PSB • Scrubbing + partial (staged) SPS o Transfer of long bunches to PS (longitudinal blowa. C coating up in PSB to 3 e. Vs) • Upgrade of protection devices & o Brightness in PS SPS beam dump • PS intensity reach SPS longitudinal impedance • Losses in SPS (longitudinal losses due to bunch rotation reduction - added after recommendation from last C&S in PS + other effects? ) review with the goal of matching • Longitudinal instabilities and beam loading in SPS LIU baseline with HL-LHC 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 22

2015 to 2016 LIU proton beam parameters N (x 1011 p/b) e (mm) Bl(ns) 2016 achieved 1. 2 2. 5 1. 6 2015 CSR LIU reach 2. 0 1. 9 1. 6 2. 3 2. 1 1. 6 2016 LIU reach HL-LHC request Remaining high risk items to match HL-LHC parameters • PS intensity limitation • SPS losses at injection energy, underlying mechanism behind it and their scaling with intensity 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 23

Risk assessment – cost – schedule – performance Methodology in assessing the risks throughout the injectors chain Risk category LOW MEDIUM HIGH COST (% of equipment Ct. C) <5 5 -10 > 10 SCHEDULE (months) 1 1 -3 >3 PERFORMANCE (% of target bunch intensity) <5 5 -10 > 10 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 24

LIU 2016 beam parameter* tables Protons N (x 1011 p/b) e (mm) Bl(ns) Number of bunches PSB/ring 34. 2 1. 7 650 1 PS 32. 5 1. 8 205 4 + 2 SPS 2. 6 1. 9 3. 0 4 x 72 LHC 2. 3 2. 1 1. 6 10 x 288 N e (mm) Bl(ns) Number of bunches Ions (x 108 ions/b) LEIR 9. 3 0. 5 1000 2 PS 6. 8 0. 7 180 2 SPS 2. 6 1. 0 2. 5 16 x 4 LHC 1. 7 1. 3 20 x 64 LHC Injectors Upgrade (LIU) Project Description, LIU-PM-RPT-0015 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review * In each machine beam parameters are LIU Project - Malika Meddahi, Giovanni Rumolo given at injection and after RF capture 25

Injectors chain work progress Full report will be given in the following presentations: • • • Linac 4 Project – Alessandra Lombardi LIU-ion PS injectors – Richard Scrivens LIU-PSB – Klaus Hanke LIU-PS – Heiko Damerau LIU-SPS – Brennan Goddard 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 26

Schedule More in Julie Coupard presentation Main LHC Injectors Upgrade (LIU) installations during LS 2 delayed and lengthened by 6 months o Studies, work on surface and hardware design/production during Run 2 o Installation/cabling work during (E)YETS LIU beam commissioning during Run 3 : Protons: during Run 3 - Ions: ready by end 2021 LS 2 Proton run TS-(E)YETS Beam commissioning LS 3 Pb-Pb run 17 -19 October 2016 LS 4 LIU / HL-LHC Cost and Schedule Review Long Shutdown LIU Project - Malika Meddahi, Giovanni Rumolo LS 5 27

Project Safety Management LIU SAFETY OBJECTIVES • Ensure that the present level of Safety for the people and the environment is maintained during all project phases (simulations, design, prototyping, installation, commissioning, operation and dismantling) and whenever it is possible or required, is improved. • Demonstrated the above point through the LIU Safety Files More in Anne Funken presentation 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 28

Overall Cost to Completion LIU project [MCHF] Machine LIU-PSB LIU-SPS LIU-IONS LIU-MGT Total LIU 2015 Ct. C 2016 Ct. C 186 180 2015 Ct. C 22, 855 67, 339 76, 801 7, 350 11, 944 186, 289 2016 Ct. C 23, 470 66, 380 72, 225 2, 645 15, 515 180, 235 Ct. C Variation 615 -959 -4, 576 -4, 705 3, 571 -6, 054 More in the presentations of Heiko Damerau, Klaus Hanke, Brennan Goddard, Richard Scrivens, Sylvie Prodon. To note: • Ct. C expressed in 2015 prices • 2015 CSR recommended areas of cost reduction implemented • M to P vital for the work progress 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 29

Overall Cost to Completion • • Implementation of the 2015 CSR recommendations on cost reduction => re-baseline 1 st Sept. 2016 55% 2016 budget spent – committed: 107% – of 17. 5 MCHF 36% spent of total Ct. C Planned value per year (Material only) Year 2016 • More in Sylvie Prodon presentation 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 30

Project progress tracking through EVM project structure: Automated EVM reports sent to PL and LIU machine activity leader 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 31

Overall Cost to Completion LIU dashboard 14. Oct. 2016 Schedule Variance (SV) = Earned Value (EV) – Planned Value (PV) Cost Variance (CV) = Earned Value (EV) – Actual Cost (AC) 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review More in Sylvie Prodon presentation LIU Project - Malika Meddahi, Giovanni Rumolo 32

Manpower: 2015 to 2016 C&SR evolution C&SR 2015 C&SR 2016 Total need for fellows (FTE) 142 198 Total CERN staff FTE 709 790 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 33

Summary • • • High priority was successfully put to accelerate the project progress – importance of Fellows, adequately supervised by experienced staff. Acknowledge support from all Department Heads and Group Leaders Need to continue on this rising PV path, with another acceleration throughout 2017 – additional corresponding resources needed (more Fellows and CERN staff) Scope definition has been clarified for LIU-ions program, and a robust baseline implemented, based on an intense study program launched in Nov. 2015 LIU proton beam parameters and HL-LHC are aligned - with the associated risks. Result of an extensive theoretical/simulation/experimental studies and anticipated installation of upgraded equipment Rigorous financial follow-up in place to monitor the project progress and steer it as needed. 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 34

Goals and means for the LIU Increase intensity/brightness in the injectors to match HL-LHC requirements Þ Inject H- into the PSB at 160 Me. V (replace Linac 2 with Linac 4, re-design injection into PSB) Þ Raise injection energy in PS to 2 Ge. V (increase field in PSB magnets, replace main power supply, change transfer equipment, re-design PS injection) Þ Double RF power in SPS (new 200 MHz power plant, rearrange 200 MHz system, power 2 nd 800 MHz cavity, new low-level) Þ Enable PSB/PS/SPS to accelerate and manipulate higher intensity beams (electron cloud mitigation, impedance reduction, protection devices and dumps, feedbacks, etc. ) Þ Upgrade the injectors of the ion chain (Linac 3, LEIR, PS, SPS) to produce beam parameters at the LHC injection that can meet the luminosity goal Increase injectors’ reliability and lifetime to cover HL-LHC run (until ~2035!) closely related to CONSolidation Þ Upgrade/replace ageing equipment (power supplies, magnets, RF…) Þ Improve radioprotection measures (shielding, ventilation…) 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 36

Present 50 Me. V Linac 2 160 Me. V Output energy 1. 4 Ge. V 2. 0 Ge. V 26 Ge. V 450 Ge. V 7 Te. V LIU Mandate - DG-DAT-2010 -5 PSB LIU (2021) Linac 4 PSB PS PS SPS LHC / HL-LHC The LHC Injectors Upgrade should plan for delivering reliably to the LHC the beams required for reaching the goals of the HL-LHC. This includes LINAC 4, the PS booster, the PS, the SPS, as well as the heavy ion chain. The project co-ordinator will have the responsibility for the project management (WBS, technical co-ordination and integration, manpower and budget agreement with the departments as well as budget and timescale control). They will report on a regular basis to the 17 -19 October 2016 Director of Accelerators and Technology. The executive role for manpower and budget for the LIU Project - Malika Meddahi, LIU / HL-LHC Cost 37 Giovanni Rumolo projects/studies remains with the technical groups in the departments. and Schedule Review

2016 beam parameter** table: protons Standard scheme N (x 1011 p/b) e (mm) Bl(ns) Number of bunches PSB/ring 34. 2 1. 7 650 1 PS 32. 5 1. 8 205 4 + 2 SPS 2. 6 1. 9 3. 0 4 x 72 LHC 2. 3 2. 1 1. 6 10 x 288 BCMS scheme N (x 1011 p/b) e (mm) Bl(ns) Number of bunches PSB/ring 17. 1 1. 3 650 1 PS 16. 2 1. 4 135 2 x 4 SPS 2. 6 1. 5 3. 0 5 x 48 LHC 2. 3 1. 7 1. 6 11 x 240 LHC Injectors Upgrade (LIU) Project Description, LIU-PM-RPT-0015 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review ** In each machine beam parameters are LIU Project - Malika Meddahi, Giovanni Rumolo given at injection and after RF capture 38

Performance reach: evolution white area accessible • High risks HL-LHC request • PS longitudinal instabilities • SPS longitudinal losses (PS bunch rotation + intensity effects) • Medium risks • PS space charge at the limit + new beam parameters at PSB-PS transfer • SPS longitudinal instabilities • SPS transverse instabilities • SPS e-cloud (scrubbing or staged a-C coating) • Low risks • PSB brightness within margin • PS TFB for headtail and e-cloud instabilities • SPS dump and protection devices 17 -19 October 2016 LIU / HL-LHC Cost and Schedule Review LIU Project - Malika Meddahi, Giovanni Rumolo 39
