Lightel Technologies, Inc.

Background • Operation started Jan. 2000 • Based in Seattle, WA • Manufacturing in US and China • Business: Photonics equipment & Optical components • Markets: Telecom, CATV, Sensors, FTTx, and Defense US Headquarters includes Administration, Sales, R&D, Design and Domestic Production

Video Microscope Customers include: • ABC Television • Alcatel-Lucent • Bell Canada • Boeing • Canadian Broadcasting Company • Cisco • Comcast • Google • IBM Corp. • ITW Chemtronics • NASA • Northrop Grumman • NTT • Time Warner Cable • US Army • Virgin Mobile

Video Microscopes • CI-1000 • CI-1100 • DI-1000 • View. Conn®

CI-1000 The CI-1000 was Lightel’s first portable microscope. Well known, and still very popular, more than 4, 500 CI-1000 have been sold to date.

CI-1000 Packages LCD version USB version CI-1000 -A 2 CI-1000 -B 2 1 Probe with - 1 LCD monitor module - 1 AC adapter/battery charger - 1 Rechargeable battery pack - 1 tip for female FC/PC, SC/PC - 1 tip for female LC - 1 Carrying case 1 Probe with - 1 USB video capture module& software - 1 tip for female FC/PC, SC/PC - 1 tip for female LC - 1 Carrying case

CI-1100 The CI-1100 is Lightel’s successor to the CI-1000. With many of the same features which have made the CI-1000 so popular, the CI-1100 has a sleek new ergonomic design and an improved tip attachment method.

CI-1100 -A 2 The CI-1100 -A 2 package includes the CI 1100 probe, a 3. 5” fold-up LCD monitor, AC adapter/battery charger, case and 4 standard tips. Specifications Probe Magnification 400 X (w/ 9” monitor) Field of View ~ 400µm x 300µm (625µm x 480µm available) Resolution 0. 5µm detectable Focus Manual adjustment, 2 mm max travel Light source Blue LED Dimensions 35 mm diameter x 175 mm length (without cap) Weight 200 g Monitor Display 3. 5” TFT-LCD, 960 x 240 pixels Controls Adjustable brightness and contrast Dimensions 105 mm x 90 mm x 45 mm (folded) Weight 255 g (without battery) Power supply 9. 6 V battery pack or AC power supply Battery life 4 hours Charger/AC adapter US, EU, UK and Australian versions available Operating Temperature 0°C to 50°C Storage Temperature -20°C to 70°C

The CI-1000 -USB 2 adapter is available for use with the CI-1100 -A 2 package. This will enable you to use the CI-1100 probe either with it’s LCD monitor or with your Windows® based computer. * Included with each adapter is Lightel’s free Connector. View image capture software which enables easy viewing and documentation. *For use with Windows XP, Vista or Windows 7 PCs with a USB 2. 0 port.

DI-1000 The DI-1000 is Lightel’s new all-digital video microscope. The DI-1000, with digital zoom and a direct USB 2. 0 connection provides an inspection and a documentation scope in a single easy-to-use package. It can be the ideal companion for today’s ever smaller laptops and netbooks.

DI-1100 -B 2 The DI-1100 -B 2 package includes the DI-1100 probe, software CD, case and 4 standard tips. The case is designed to easily fit into a standard laptop bag. Specifications Probe Magnification 400 X (w/ 9” monitor) Field of View ~ 400µm x 300µm (625µm x 480µm available) Resolution 0. 5µm detectable Focus Manual adjustment, 2 mm max travel Light source Blue LED Dimensions 35 mm diameter x 175 mm length (without cap) Weight 200 g Operating Temperature 0°C to 50°C Storage Temperature -20°C to 70°C

View. Conn® View. Conn is the first, and only, hand-held, all-in-one inspection and cleaning device. View. Conn’s integrated operation allows users to quickly and easily inspect, clean and reinspect, ensuring connectors are truly clean prior to mating. View. Conn’s large 3. 5” display provides clear, sharp images.

Specifications View. Conn® Plus VC-6200 -PL View. Conn (VC-6200) Field of View ~ 425µm x 320µm Resolution 0. 5µm detectable Focus Manual adjustment, 2 mm max travel Light source Blue LED Display 3. 5” TFT-LCD, 960 x 240 pixels Controls Adjustable brightness and contrast Power supply 4 AA rechargeable batteries or AC power supply Battery life 4 hours Charger & AC adapter US, EU, UK and Australian versions available Dimensions 170 mm x 95 mm x 30 mm (without cover) Weight 350 g (without battery) Probe (CI-1100 -HS) Field of View ~ 400µm x 300µm Resolution 0. 5µm detectable Focus Manual adjustment, 2 mm max travel Light source Blue LED Power supply View. Conn via 4 -pin jack Dimensions 35 mm diameter x 175 mm length (without cap) Weight 200 g Operating Temperature 0°C Storage Temperature -20°C to 50°C to 70°C

View. Conn® Plus Save Time The View. Conn Plus dual microscope design lets you easily inspect both male and female mated connector pairs without the time consuming need to change tips.

View. Conn’s Accessory Holder will securely hold optional cleaning devices, or …

View. Conn with VC 6 -OPM View. Conn offers an integrated power meter option. Two versions are available for standard and higher power ranges. The power meter plugs into View. Conn’s 4 -pin socket (the same one used by the probe) and is powered by View. Conn. The power meter can store up to 999 readings and download them through its own USB output

Connector. View. TM software All Lightel video microscopes with USB 2. 0 output come with Lightel’s Connector. View. TM software for viewing and capturing connector endface images on your Windows® PC. Connector. View numbers each captured image individually and can be set to display the fiber cleaning zones automatically.

Connector. View. TM Plus software Lightel’s optional Pass/Fail analytical software available for all Lightel video microscopes with USB 2. 0 connections. Connector. View Plus will automatically analyze the connector condition and provide a report. It can be used with single mode and multimode, male and female, PC and APC connectors.

Microscope Features Comparison CI-1000 -A 2 CI-1100 -A 2 CI-1000 -B 2 DI-1000 View. Conn® View. Conn Plus Eye-safe video inspection √ √ √ Hand Held √ √ √ CE Approved √ √ √ Ro. HS Compliant √ √ √ LCD Display √ √ √ USB connectivity * √ √ PC and APC connector viewing √ √ √ Male connector viewing √ √ √ Female connector viewing √ √ √ Carrying case √ √ √ * * Ruggedized cover √ √ Built-in Cleaning module √ √ Digital zoom √ Two optical modules Connector. View Plus Pass / Fail software Integrated Optical Power Meter * Optional * * *
