LEWIS ENVIRONMENTAL UPGRADING AMD FOR FRACKING WHOS LEWIS

LEWIS ENVIRONMENTAL UPGRADING AMD FOR FRACKING WHO’S LEWIS ENVIRONMENTAL… • COMPANY HAS SEVERAL PATENTS - HEAVY METAL(S) REMOVAL AND CYANIDE DESTRUCTION. • PATENT PENDING - SHALE GAS WATER RECYCLING AND UPGRADING AMD FOR FRESH WATER DRILLING. MISSION STATEMENT… TO PROVIDE ITS CUSTOMERS WITH “SINGLE SOURCE” WATER MANAGEMENT BY IMPLEMENTING “GREEN “ SERVICES AND TECHNOLOGIES ENABLING RESOURCE RECOVERY, WATER RECYCLING AND ECONOMIC SAVINGS. Cost Effective Solutions For …. Today’s Problems

LEWIS ENVIRONMENTAL Customers Who Have Used Our Products And Services • Crane Naval Base Cost Effective Solutions For …. Today’s Problems

LEWIS ENVIRONMENTAL Two Major Issues And Opportunities Intersect… PENNSYLVANIA HAS OVER ABANDONED Pennsylvania’s Need 250, 000 To Clean Up Acid MINE DISCHARGES AND RUNOFFS… Mine Drainage Discharges DRILLERS NEED 9 BILLION GALLONS OF FRESH & WATER EACH YEAR (25 MILLION GALLONS /DAY). Gas Drillers Need For Alternate Fresh BENEFITS OF UTILIZING THIS RESOURCE: Water Supplies 1 - REDUCES COST TO THE DRILLERS; 2 – ELIMINATES WITHDRAWAL RESTRICTIONS IN Working SUMMER; AND together, both win! 3 - IMPROVES THE ENVIRONMENT. Cost Effective Solutions For …. Today’s Problems

LEWIS ENVIRONMENTAL Cost Effective Solutions For …. Today’s Problems

LEWIS ENVIRONMENTAL UPGRADED ACID MINE DRAINAGE NEW “GREEN” FRESH WATER SOURCE… • ENVIRO-MINE PROCESS (EMP) – PROPRIETARY TECHNOLOGY (PATENT PENDING) UTILIZES ADVANCED CHEMISTRY AND ADSORBENT MATERIALS. • REMOVES HEAVY METALS; IRON, ZINC AND ALUMINUM • REMOVES SULFATES VIA CHEMICAL REMOVAL AND CATALYTIC REDUCTION. • PRODUCES HIGH PURITY WATER FOR DRILLING OR DISCHARGE. LOW SUSPENDED SOLIDS, IRON <1 PPM AND SULFATES < 100 PPM Cost Effective Solutions For …. Today’s Problems

LEWIS ENVIRONMENTAL Cost Effective Solutions For …. Today’s Problems

LEWIS ENVIRONMENTAL HOW THE ENVIRO-SHALE PROCESS WORKS H 2 O Fe Zn Fe CARBON Zn CARBON H 2 O CARBON THE ACID WATER IRON MINE AND DRAINAGE COMES ZINCINARE CONTACT STREAM ADSORBED IS WITH ACID MINE DRAINAGE UPGRADED ON THE CARBON’S LEWIS FOR DISCHARGE CARBON SURFACE STREAM WITH IRON AND ZINC Cost Effective Solutions For …. Today’s Problems

LEWIS ENVIRONMENTAL THIS TREATMENT PROCESS WORKS WITH BOTH PASSIVE AND ACTIVE AMD SITES. HIGH SHEAR OXIDIZING UNIT TO CONVERT IRON LEWIS’ CARBON FILTERS Cost Effective Solutions For …. Today’s Problems

LEWIS ENVIRONMENTAL ACID MINE DRAINAGE TREATMENT RESULTS AMD Feed Lewis Carbon Filters Sulfate Reduction Step Date 1 Fe 115 Sulfate 850 Fe 0. 10 Sulfate 800 Fe 0. 10 Sulfate 25 2 60 825 0. 10 760 0. 10 18 3 35 900 0. 10 810 0. 10 30 4 140 850 0. 10 810 0. 10 22 5 75 800 0. 10 780 0. 10 28 6 70 800 0. 10 780 0. 10 20 Cost Effective Solutions For …. Today’s Problems

LEWIS ENVIRONMENTAL EMP PROCESS EFFLUENT MEET’S DRILLERS QUALITY TO SUPPLEMENT FRESH WATER FOR FRACKING. Cost Effective Solutions For …. Today’s Problems

LEWIS ENVIRONMENTAL REVENUE COMPARSION: AMD VS FRESH WATER AMD($)AND FRESH ($) CLOSER CHEAPER OPERATING COST THAN TRUCKING FRESH WATER FEES ($3/1000 GALS)BY 29%. 750, 000 WATER UTILITIES & CHEMICALS 6, 000 ELIMINATES WITHDRAWAL TRANSPORTATION (TRUCKING) 13, 800, 000 27, 600, 000 LABOR (3 Men, 312 RESTICTIONS. Days, 25/HR) 187, 200 TOTAL OPERATING COST $19, 987, 200 $ 28, 350, 000 IMPROVES OUR WATERWAYS. 300, 000 GPY PROCESSED UPGRADED AMD IS UPGRADED AMD SOURCES OFFER DRILLERS A NET SAVINGS OF $8, 362, 800 (+29% REDUCTION) IN WATER COSTS OVER 50 WELLS DRILLED WITH 30 MILES LESS TRAVEL TIME. Cost Effective Solutions For …. Today’s Problems

LEWIS ENVIRONMENTAL SUMMARY… LEWIS’ PATENT PENDING TECHNOLOGY IS MORE THAN AN ENVIRONMENTAL SOLUTION… IT ENABLES DRILLERS TO REDUCE COSTS AND DRILL WITHOUT FEAR OF RESTRICTIONS. BOTTOM LINE … IT’S A SMART BUSINESS DECISION! BEN FRANKLIN SHALE GAS GRANT WILL ENABLE LEWIS ENVIRONMENTAL TO COMMERCIALIZE THIS TECHNOLOGY WITH FIELD DEMONSTRATION. Cost Effective Solutions For …. Today’s Problems
