LABMAN Trash To Treasure Presenter: Shayne Cardwell

What We Do � Promote the mutual understanding and bonds among students, faculty and staff. � Coordinate learning and awareness events regarding computers and technology. � Provide educational and technical assistance to members in need. � Promote the awareness of alternative operating systems. � Work with the community to expand our understanding of technology.

Recycled Machines

What Can Be Done � Cluster Technology � Rendering Farm � Simultaneous Task Completion � Security Auditing For Research � Storage Farm � Open Source Routing � Smoothwall � Vyatta

Big Intimidating Task Computation Hybrid pictures

Big Intimidating Task Computation Hybrid pictures continued

Cluster. Knoppix Clustering with Linux

Cluster. Knoppix � � Cluster. Knoppix is a derivative of Knoppix, based on Debian Cluster. Knoppix aims to provide the same core features and software as Knoppix, but adds the open. Mosix clustering capabilities also Designed to be a complete Linux distribution, running the largest possible array of desktop user applications. Knoppix provides this facility without actually “installing” the operating system onto local storage media

CHAOS � � � CHAOS is not intended to be fully-laden with application software; CHAOS is designed to be a compact Linux and open. Mosix distribution that is secure and highly distributable. CHAOS does not interfere with the host operating system, running entirely from RAM it also frees the CDROM boot media Well suited as a minimized “drone node” distribution. Biggest advantage of using CHAOS is its focus on security and deployment methodology

CHAOS � � CHAOS is the first Linux and open. Mosix distribution to add native network security to the cluster deployment Every node in the cluster does its own packet filtering, and establishes IPSEC tunnels as required This is performed transparently, requiring no user intervention. CHAOS is capable of PXE booting new nodes

Gluster Storage Platform Storage Systems

Gluster Storage Platform • • A complete storage operating system/platform built on Gluster. FS cluster file system that can be easily installed on industry standard commodity hardware Efficient installer that enables quick install and boot of first server, with disk formatting done post install, and supports remote install of subsequent servers Integrated easy to use and feature rich web-based management UI that makes installation and configuration of large clustered storage systems quick and simple. Key management interface features are: • Volume manager • Resource manager • Server/disk manager • Log viewer Built in, pre-configured support for 10 Gig. E and Infiniband (Open Fabrics) making it easy to utilize these hi-speed server interconnects

Advantages Of Gluster Storage Platform � � � � � Open Source Petabyte-Scale Clustered Storage Scalability Performance High Availability Easy Deployment & Management Optimized for Virtual Servers Kernel Independent Quick, Flexible Setup Flexible Modular Design

Minimum Requirements for Gluster Storage Platform • • 1 GB USB Disk as Install Media 1 or more storage servers (or virtual machines) with minimum configuration as follows: Disk 8 GB • Memory 1 GB • Intel/AMD 64 bit hardware • 1 Gig. E or 10 Gig. E or Infiniband •

Mirror Visual Example

Open Source Routing

Open-Source Firewall Project Smoothwall Express

Capabilities � Supports LAN, DMZ, and Wireless networks, plus External. � � � External connectivity via: Static Ethernet, DHCP Ethernet, PPPo. E Port forwards, DMZ pin-holes Outbound filtering Timed access Simple to use Quality-of-Service (Qo. S) Traffic statistics � � Per interface Per IP totals for weeks and months � � � IDS via automatically updated Snort rules UPn. P support Blacklist

CLI Support

VPN Setup

Open-Source Routing Vyatta

Vyatta � � Who or What is Vyatta? Why consider Vyatta?

An Epic Battle CISCO VS.

Cost

Virtualization � � optimized to run in virtual environments to manage traffic and enforce policies Examples � Consolidation - Inter-VM Security � Hypervisor / Platform Protection � Consolidation - SMB/Branch Resource Maximization � Consolidation - Datacenter Resource Maximization � Live Migration - Redundancy, Failover & Testing � Application Density - Horizontal Virtualization � Cloud Security - Datacenter to Cloud VPN � Cloud Security - Cloud to Cloud VPN & Routing

An Epic Battle CISCO VS

THE END
