LAB Specific Heat of a Metal Prelab question

LAB: Specific Heat of a Metal

Prelab question: Table 1: Specific Heats of Metals A calorimeter containing 100. 0 m. L of room. Metal Specific temperature water (23. 2 C) Heat warms up to 48. 1 C when a (J/g ºC) 225 g sample of unknown Aluminum 0. 91 metal is placed inside. The Iron 0. 46 initial temperature of the metal was 100. 0 C. Lead 0. 13 a) What is the specific heat of this metal? Silver 0. 23 Tin 0. 21 b) Identify this metal from the Titanium list of possibilities in Figure 1. Zinc 0. 54 0. 39

Prelab question: A calorimeter containing 100. 0 m. L of room-temperature water (23. 2 C) warms up to to 48. 1 C when a 225 g sample of unknown metal is placed inside. The initial temperature of the metal was 100. 0 C. a) What is the specific heat of this metal? Tmetal = Tf-Ti = 48. 1 C – 100. 0 C = -51. 9 C mmetal = 225 g Twater = Tf-Ti = 48. 1 C - 23. 2 C = 24. 9 C

Prelab question: A calorimeter containing 100. 0 m. L of room-temperature water (23. 2 C) warms up to to 48. 1 C when a 225 g sample of unknown metal is placed inside. The initial temperature of the metal was 100. 0 C. a) What is the specific heat of this metal? qcal = mwater cwater ∆Twater qcal = (100 g)(4. 18 J/g C)(24. 9 C) qcal = 10, 408. 2 J qrxn = -10, 408. 2 J = (225 g)(c)(-51. 9 C) c = 0. 891 J/g C

Prelab question: A calorimeter containing 100. 0 m. L of roomtemperature water (23. 2 C) warms up to to 48. 1 C when a 225 g sample of unknown metal is placed inside. The initial temperature of the metal was 115 C. b) Identify this metal from the list of possibilities in Figure 1. cexperimental=0. 891 The sample must be aluminum. Table 1: Specific Heats of Metals Metal Specific Heat (J/g ºC) Aluminum 0. 91 Iron 0. 46 Lead 0. 13 Silver 0. 23 Tin 0. 21 Titanium 0. 54 Zinc 0. 39

In groups, write procedures for this lab. Do not start the lab until your procedures have been approved by your instructor. PURPOSE: To determine the specific heat of an unknown metal and use this value to identify the unknown metal when given a list of possibilities MATERIALS: • Beaker, 600 m. L • Boiling stones • Crucible tongs • Graduated cylinder, 100 -m. L • Hotplate • Metal (bolt or sinker) • Styrofoam cups (2) • Thermometer

Sample procedures: 1. Add a few boiling stones and 250 -m. L of tap water to a 400 -m. L beaker; heat the water until the water is boiling gently using the hot plate (DO NOT turn the hot plate to max. DO STEP 2 WHILE WAITING FOR WATER TO BOIL 2. Obtain a piece of metal from your teacher and write the SHAPE in your data table (ex. Screw or the Sinker). 3. Record the mass of your metal. 4. Using tongs, carefully place your metal in the water that is gently boiling on the hot plates. Allow the metal to heat up for 5 -10 minutes. Continue to the next steps while you wait. 5. Setup a makeshift calorimeter using 2 styrofoam cups (one as the base, one as the top, which has a small hole in the top for thermometer). 6. Measure 75. 0 -100. 0 m. L of cool distilled water in a graduated cylinder and pour this water into your calorimeter. Record the exact amount (nearest 0. 1 m. L) as the mass of your water (since the density of water = 1. 0 g/m. L, the volume = mass. EXAMPLE, 50. 0 m. L = 50. 0 grams of water). 7. Measure the temperature (to ONE DECIMAL PLACE) of the water in the calorimeter. Record this as the initial temperature of the water in your data table. 8. Check thermometer of the hot water bath and record this temperature (to ONE DECIMAL PLACE) as the initial temperature of the metal. 9. DO THIS STEP QUICKLY: Using tongs, remove metal from hot water and immediately place it in the calorimeter. 10. Monitor the temperature of the water in the calorimeter. Carefully use thermometer to gently stir the water. Record the highest temperature (to ONE DECIMAL PLACE) as the final temperature of the metal and as the final temperature of the water in your data table 11. Remove the metal from the cup, dry the metal, and repeat the trial 2 more times. 12. Clean your designated lab area, return all materials, and check in with your teacher before returning to your desks.

What will you turn in? • Each group will turn in their procedures. • Each individual will turn in the following: – Data table(s): clearly organized/labeled/etc. – Calculations: • Determine specific heat of sample – Show all work & round to SF at end – All numbers must have units • Identify metal • Percentage error – Discussion/conclusion: restate purpose, summarize procedure, state results (c, metal & % error), discuss a minimum of 3 sources of error and explain how each would affect your overall result (Ultimately, how might each error affect your calculated specific heat value? ) Table 1: Specific Heats of Metals Metal Specific Heat (J/g ºC) Aluminum 0. 91 Iron 0. 46 Lead 0. 13 Silver 0. 23 Tin 0. 21 Titanium 0. 54 Zinc 0. 39
