Korea Rail Network Authority Republic of Korea Contents

Korea Rail Network Authority, Republic of Korea

Contents 1 Introduction Organizations - KRNA Overview of KOREA’s High Speed Rail development Background of Development 2 3 Definition of development targets Major Accomplishment of Development Design Program Core Parts Test Equipment Installation of test bed, test and verification 4 Conclusion Korea Rail Network Authority

Organizations Government MLTM (Ministry of Land, Transport and Maritime Affairs) KRNA (Korea Rail Network Authority) Planning & Innovation H/Q Management Support & Safety R/O Seoul Metropolitan Construction Yeongnam Honam Engineering Chungcheong Facilities & Business Development Gangwon Korea Rail Network Authority

Organizations Conventional Lines HSR Lines Korea Rail Network Authority

Overview of Korea’s High Speed Rail development Korea Rail Network Authority

Overview of Korea’s High Speed Rail development u April. 2004. - The 1 st phase of 300 km/h Gyeongbu high speed rail (Seoul ~ Dongdaegu) u Nov. 2010. - The 2 nd phase of 300 km/h Gyeongbu high speed rail (Dongdaegu ~ Busan) u Dec. 2014. - Two additional high speed rail network (350 km/h) (Honam & Seoul metropolitan high speed rail) Korea Rail Network Authority

Background of Development HEMU-430 X TGV ICE u World’s high speed railway market : 300 km/h → 350 km/h → 400 km/h → ? ? ? km/h u To improve the speed : rolling stock & catenary system u 400 km/h Next-Generation high speed train (HEMU-430 X) : KRNA ↔ KRRI(Korea Railroad Research Institute) Korea Rail Network Authority

Definition of development targets Target l The Design Criteria l The Design Program to build the system - basic design on the system - catenary system specification and the detail design l Design Program to design 400 km/h Catenary system - De. CATS 400(Detail design of high speed catenary system 400 km/h) Overlap section Neutral section Korea Rail Network Authority

Definition of development targets Target l 400 km/h Catenary system requires : - tension increasing → contact wire & messenger wire change l Core component should be developed - tensioning device, fitting, movable bracket, dropper and steady arm. etc. l Interface with the rolling stock - allowable uplift force should be increased - system height, static and dynamic characteristic of steady arm. etc. HEMU-430 X Pantograph modeling Korea Rail Network Authority

Definition of development targets Target l Performance of core components and parts of 400 km/h catenary system - identify the durability - configure the data base on electrical properties l Evaluating measured values l Verifying through the simulation l Applying to the other projects fitting Mast and bracket Korea Rail Network Authority

Definition of development targets Target l Actual car test is the best method for final performance assessment of the developed catenary system - install separate test bed - upgrade existing high speed rail to 400 km/h level l Test bed for static and dynamic test in KRRI l Plan to install a 56 km-long test bed on Honam high speed rail l Test run for speed increase (on the 2 nd phase of Gyeongbu high speed rail) - verify the rolling stock performance and dynamic characteristics → Test bed in KRRI Korea Rail Network Authority

Major accomplishment of development De. CATS 400 l KRNA succeeded in independently developing a De. CATS 400 - applicable, convenient and appropriate to 400 km/h Catenary parameter l Check point - the plural number of designers to perform effective, rapid and precise design. <System Structure> <De. CATS 400 Mounting diagram on screen> <Data base Structure> Korea Rail Network Authority

Major accomplishment of development Key point l Enhanced strength, conductivity and Easily manufactured l Durable to withstand the design load and Convenient for fabrication l Test at independent international test agent - ILAC (International Laboratory Accreditation Cooperation) - KOLAS (Korea Laboratory Accreditation Scheme). etc. <Development of core parts> Korea Rail Network Authority

Major accomplishment of development Process of Contact wire (trial manufacture) Raw materials Alloy melting 1250℃ Cu-Mg-Fe-P trial manufacture Adding element (Cr, Zr, Mg, Fe. P. etc. ) Molten material treatment Tension test Wire drawing Extrudable material (150 mm 2) (28 mmΦ) Billet casting Korea Rail Network Authority

Major accomplishment of development Key point l Test equipment to prove and verify the core parts independently was developed. l Performance tests of trial manufactured core parts. Conductivity (IACS %) Tensile Strength 0. 40~0. 45 wt. % Mg 0. 0 83 Wt. % Mg Conduct ivity 0. 6 49 Tensile Strength (MPa) <Fabrication of test equipment> <Various test results (Creep, Strength, Conductivity etc) > Korea Rail Network Authority

Major accomplishment of development 3 step of test l Test track has been installed at KRRI. - verify the static & dynamic characteristics of catenary system & rolling stock l The speed increase test on 2 nd phase of Gyeongbu high speed rail. - 2 days per week for a month from Nov 29 till Feb 3, 2013 l. A test bed installation on Honam high speed rail. Korea Rail Network Authority

Major accomplishment of development Speed increase test l Increasing the speed from 350 km/h to 400 km/h by 10 km/h interval. l The max and min contact force (UIC code). l Video monitoring. <20 Hz Low pass Filter at 380 km/h> <Variation of mean contact force><Speed and current graph at 401㎞/h > <381 km/h Monitor screen> Korea Rail Network Authority

Conclusion l Full scale performance test - Verify the system stability and dynamic characteristics of developed material - From March 2014 on Honam high speed rail l Establishing the design & construction guideline for 400 km/h catenary system l Providing a milestone in independently developing a 400 km/h catenary system. l The data on R&D to be integrated in database l Enhance the competitiveness with core components so as to introduce our state-ofthe-art catenary system to the global market. Korea Rail Network Authority

Thank You ! Korea Rail Network Authority
