KLMH Chapter 8 Timing Closure VLSI Physical Design

© KLMH Chapter 8 – Timing Closure 8. 1 Introduction 8. 2 Timing Analysis

Introduction © KLMH 8. 1 System Specification Partitioning Architectural Design ENTITY test is port

Introduction © KLMH 8. 1 · IC layout must satisfy geometric constraints and timing

Introduction © KLMH 8. 1 Components of timing closure covered in this lecture: ·

Introduction © KLMH 8. 1 · Timing optimization engines must estimate circuit delays quickly

Introduction © KLMH 8. 1 · Timing closure is the process of satisfying timing

Timing Analysis and Performance Constraints © KLMH 8. 2 8. 1 Introduction 8. 2

Timing Analysis and Performance Constraints © KLMH 8. 2 Sequential circuit, “unrolled” in time

Timing Analysis and Performance Constraints © KLMH 8. 2 · Main delay concerns in

Static Timing Analysis © KLMH 8. 2. 1 · STA: assume worst-case scenario where

8. 2. 1 Static Timing Analysis © KLMH Combinational circuit as DAG (0. 15)

8. 2. 1 Static Timing Analysis © KLMH Compute AATs at each node: where

8. 2. 1 Static Timing Analysis © KLMH Compute RATs at each node: where

Static Timing Analysis s A 0 R -0. 35 S -0. 35 (0) A

Delay Budgeting with the Zero-Slack Algorithm © KLMH 8. 2. 2 · Establish timing

Delay Budgeting with the Zero-Slack Algorithm © KLMH 8. 2. 2 Input: timing graph

Delay Budgeting with the Zero-Slack Algorithm © KLMH 8. 2. 2 Forward Path Search

Delay Budgeting with the Zero-Slack Algorithm © KLMH 8. 2. 2 Backward Path Search

Timing-Driven Placement © KLMH 8. 3 8. 1 Introduction 8. 2 Timing Analysis and

Timing-Driven Placement © KLMH 8. 3 · Timing-driven placement optimizes circuit delay · Let

Net-Based Techniques © KLMH 8. 3. 1 · Net weights are added to each

Net-Based Techniques © KLMH 8. 3. 1 · Dynamic net weights: (re)computed during placement

Embedding STA into Linear Programs for Placement © KLMH 8. 3. 2 · Construct

Embedding STA into Linear Programs for Placement © KLMH 8. 3. 2 · For

Embedding STA into Linear Programs for Placement · Then, for all v Ve: ·

Embedding STA into Linear Programs for Placement © KLMH 8. 3. 2 · Optimize

Timing-Driven Routing © KLMH 8. 4 8. 1 Introduction 8. 2 Timing Analysis and

Timing-Driven Routing © KLMH 8. 4 · Timing-driven routing seeks to minimize: - Maximum

Timing-Driven Routing © KLMH 8. 4 · For any spanning tree T over G,

Timing-Driven Routing © KLMH 8. 4 2 3 2 2 3 3 6 6

The Bounded-Radius, Bounded-Cost Algorithm © KLMH 8. 4. 1 · Trades off radius for

Prim-Dijkstra Tradeoff © KLMH 8. 4. 2 · Prim-Dijkstra Tradeoff based on Prim’s algorithm

Prim-Dijkstra Tradeoff © KLMH 8. 4. 2 4 4 7 11 7 s 0

Minimization of Source-to-Sink Delay © KLMH 8. 4. 3 · Iteratively forms a tree

Minimization of Source-to-Sink Delay © KLMH 8. 4. 3 · In the critical-sink Steiner

Physical Synthesis © KLMH 8. 5 8. 1 Introduction 8. 2 Timing Analysis and

Physical Synthesis © KLMH 8. 5 · Physical synthesis is a collection of timing

Gate Sizing © KLMH 8. 5. 1 · Let a gate v have 3

Gate Sizing © KLMH 8. 5. 1 a b v. A v d C(d)

Buffering © KLMH 8. 5. 2 · Buffer: a series of two serially-connected inverters

Buffering © KLMH 8. 5. 2 v. B f C(f) = 1 g C(g)

Netlist Restructuring © KLMH 8. 5. 3 · Netlist restructuring only changes existing gates,

Netlist Restructuring © KLMH 8. 5. 3 · Cloning can reduce fanout capacitance a

Netlist Restructuring © KLMH 8. 5. 3 Redesigning the fanin tree can change AATs

Netlist Restructuring © KLMH 8. 5. 3 Redesigning fanout trees can change delays on

Netlist Restructuring © KLMH 8. 5. 3 Swapping commutative pins can change the final

Netlist Restructuring © KLMH 8. 5. 3 VLSI Physical Design: From Graph Partitioning to

Netlist Restructuring © KLMH 8. 5. 3 Boolean restructuring uses laws or properties, e.

Performance-Driven Design Flow © KLMH 8. 6 8. 1 Introduction 8. 2 Timing Analysis

Performance-Driven Design Flow © KLMH 8. 6 Baseline Physical Design Flow 1. Floorplanning, I/O

Performance-Driven Design Flow © KLMH Video Pre/Postprocessing Codec DSP Control + DSP Audio Pre/Postprocessing

8. 6 Performance-Driven Design Flow VLSI Physical Design: From Graph Partitioning to Timing Closure

Performance-Driven Design Flow VLSI Physical Design: From Graph Partitioning to Timing Closure Chapter 8:

Performance-Driven Design Flow © KLMH 8. 6 Chip Planning and Logic Design Performance-Driven Block

Performance-Driven Design Flow © KLMH 8. 6 Block-level or Top-level Global Placement With Optional

Performance-Driven Design Flow © KLMH 8. 6 Physical Synthesis Timing Correction Timing-Driven Restructuring Boolean

Performance-Driven Design Flow © KLMH 8. 6 Routing Legalization of Sequential Elements Timing-Driven Routing

Performance-Driven Design Flow © KLMH 8. 6 Sign-off passes Manufacturability, Electrical, Reliability Verification passes

© KLMH Summary of Chapter 8 – Timing Constraints and Timing Analysis · Circuit

© KLMH Summary of Chapter 8 – Timing-Driven Placement · Gate/cell locations affect wire

© KLMH Summary of Chapter 8 – Timing-Driven Routing · Timing-driven routing has several

© KLMH Summary of Chapter 8 – Physical Synthesis · Traditionally, place-and-route have been
